16644PLAY
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll-free number:
1-800-844-9273
or email:
customerservice@backyardproductsllc.com
Our staff is ready to provide assistance.
April through October M - F 8:00 AM to 7:00 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YardLine 4276 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Backyard Products YardLine 4276

Summary of Contents for Backyard Products YardLine 4276

  • Page 1 16644PLAY STOP! STOP! Call Us First! DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll-free number: 1-800-844-9273 or email: customerservice@backyardproductsllc.com Our staff is ready to provide assistance. April through October M - F 8:00 AM to 7:00 PM EST Saturday 8:30 AM to 4:30 PM EST November through March M - F 8:00 AM to 5:00 PM EST...
  • Page 3 Model: 4276 4369 A Backyard Products Company 6007 Customer Service 1-800-844-9273 6192 1000 Ternes Drive Monroe, MI 48162 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!! Please make sure all lumber, hardware and accessory parts are accounted for. If you are missing anything, please DO NOT RETURN to the store where purchased.
  • Page 4 Safety Checklist for Play Sets and Accessories A Backyard Products Company Observing the following statesments and warnings reduces the likelihood of serious or fatal injury  This playset has been designed for use by a maximum of eleven (11) occupants at one time having a combined weight of 1,155 pounds.  This playset is intended for use by children from (2) to (10) years of age.  On-site adult supervision for children of all ages is recommended.  Instruct children not to walk close to, in front of, behind, or between moving items.  Instruct children not to twist swing chains or ropes or loop them over the top support bar since this may reduce the strength of the chain or rope.  Instruct children to avoid swinging empty seats. ...
  • Page 5 PLAYSET MAINTENANCE Cosmetic defects that do not affect the structural integrity of the product, or natural defects of wood such as warping, splitting, checking, twisting, shrinkage, swelling or any other physical properties of wood that do not present a safety hazard, are not covered by our warranty. To help minimize these natural defects we recommend applying a sealer or stain every two or three years, or more often as the climate dictates. Power washing, sanding or other preparatory methods should be used prior to sealing or staining. Periodic maintenance is required to ensure safe enjoyment of your playset and accessories. Read and follow the Playset Checklist below to reduce the likelihood of serious or fatal injury. Use the checklists as a guide for proper playset care and maintenance. PLAYSET CHECKLIST At the beginning of each play season: Tighten all hardware. Lubricate all metallic moving parts per manufacturer's instructions. Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are loose, cracked, or missing. Check all moving parts including swing seats, ropes, cables, and chains for wear, rust, or other deterioration. Replace as needed. Check metal parts for rust. If found, sand and repaint using a nonleaded-based paint meeting the requirements of 16 CFR 1303. Check all wood members for deterioration and splinters. Sand down splinters and replace deteriorating wood members. Reinstall any plastic parts, such as swing seats or any other items that were removed for the cold season. Rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain appropriate depth. Replace as necessary. Twice a month during play season: Tighten all hardware. Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are loose, cracked, or missing. Rake and check depth of loose fill protective surfacing materials to prevent compaction and to maintain appropriate depth. Replace as necessary. Once a month during play season: Lubricate all metallic moving parts per manufacturer's instructions.
  • Page 6 PLAYGROUND SURFACING MATERIALS SECTION 4 OF THE CONSUMER PRODUCT SAFETY COMMISSION'S OUTDOOR HOME PLAYGROUND SAFETY HANDBOOK Select Protective Surfacing One of the most important things you can do to reduce the likelihood of serious head injuries is to install shock-absorbing protective surfacing under and around your play equipment. The protective surfacing should be applied to a depth that is suitable for the equipment height in accordance with ASTM Specification F 1292. There are different types of surfacing to choose from; whichever product you select, follow these guidelines: NOTE: Do not install home playground equipment over concrete, asphalt, or any other hard surface. A fall onto a hard surface can result in serious injury to the equipment user. Grass and dirt are not considered protective surfacing because wear and environmental factors can reduce their shock absorbing effectiveness. Carpeting and thin mats are generally not adequate protective surfacing. Ground level equipment - such as a sandbox, activity wall, playhouse or other equipment that has no elevated play surface - does not need any protective surfacing. Maximum fall height for this playset is 83''. Loose-Fill Materials:  Maintain a minimum depth of 9 inches of loose- fill materials such as wood mulch/chips, engineered wood fiber (EWF), or shredded/recycled rubber mulch for equipment up to 8 feet high; and 9 inches of sand or pea gravel for equipment up to 5 feet high. NOTE: An initial fill level of 12 inches will compress to about a 9- inch depth of surfacing over time. The surfacing will also compact, displace, and settle, and should be periodically refilled to maintain at least a 9- inch depth.
  • Page 7 DIMENSIONS 6’ -0’’ 14’ -0’’ 20’ -2’’ 6’ -0’’ 14’ -0’’ 14’ -8’’ 6’ -0’’ 28’ -0’’ 6’ -0’’ 6’ -0’’ 11’ -0’’ 6’ -0’’ 11’ -0’’ 14’ -0’’ 14’ -0’’ 6’ -0’’ 6’ -0’’ 26’ -8’ 32’ -2’’ MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE.
  • Page 8 TOOLS REQUIRED DRILL 1/2” & 7/16’’ SOCKETS & HAMMER ADJUSTABLE TAPE MEASURE WRENCH WRENCH PLIERS SCREWDRIVER PHILLIPS BIT CARPENTER SAFETY GLASSES 1/8” DRILL BIT SQUARE INCLUDED HARDWARE 3” Deck Screw (x9) 2-1/2” Deck Screw (x170) 5/16” Loc Nut (x10) 3/16” Tarp Washer (x6) 5/16”...
  • Page 9 3 1/4’’ HARDWARE 2 1/2’’ 2’’ 1/4 -18 T-Nut (x12) 5/16” x 1-1/2” Lag Screw (x4) (x1) Steering Wheel Spacer Small...
  • Page 10 SA6066 BOX 1 of 2 BOARD LIST (2) [PF 6325] 3’’ x 3’’ x 94-1/4’’ (1) [PF 6309] 5/8’’ x 3-3/8’’ x 35’’ (2) [PF 6324] 3’’ x 3’’ x 94-1/4’’ (1) [PF 6331] 5/8’’ x 3-3/8’’ x 31-1/2’’ (1) [PF 6323] 3’’ x 3’’ x 31-1/2’’ TOWER BEAM SUPPORT (1) [PF 6338] 3/4’’...
  • Page 11 SA6065 BOX 2 of 2 BOARD LIST (2) [PF 6297] 1-3/8’’ x 3-3/8’’ x 83’’ A-FRAME (20) [PF 6330] 1/2” x 3-5/16” x 36-3/4” SHINGLE (1) [PF 6296] 1-3/8’’ x 3-3/8’’ x 58’’ A-FRAME SUPPORT (2) [PF 6354] 5/8’’ x 3-3/8’’ x 37-3/8’’ (2) [PF 6352] 1-3/8’’...
  • Page 12 COMPONENTS Window Pane (x1) Swing Beam Bracket (x2) Beam Brace (x1) Tarp (x1) Play Handle (x2) 3/8’’ x 5-1/2’’ 2631 Bag of (x6) Swing Hangers Steering Wheel (x1) Swing Seat (x2) Standing Swing (x1)
  • Page 13 Telescope (x1) Flag Assembly (x2) Climbing Rock (x6) Anchor It (x4) Anchor It Strap (x4) Warning Plate (x1) Model: 4276 4369 A Backyard Products Company 6007 Customer Service 1-800-844-9273 6192 1000 Ternes Drive Monroe, MI 48162 IMPORTANT!! PLEASE READ BEFORE BEGINNING ASSEMBLY!! Please make sure all lumber, hardware and accessory parts are accounted for.
  • Page 14 STEP 1 2-3/8’’ PANEL A SPACE Flush PF 6347 5/8’’ x 3-3/8’’ x 31-1/2’’ 18-11/16’’ Check to make sure (4) PF 6309 5/8’’ x 3-3/8’’ x 35’’ structure is square 35-5/8’’ Install 30mm Screws 16-516’’ With Heads Flushed To Board To Avoid Protrusions.
  • Page 15 STEP 2 Check to make sure structure is square 2-1/2’’ Deck Screws 18-11/16’’ TO HOLES Flush T-Nut Small 2-1/2’’ Deck Screws Flush 2-1/2’’ Deck Screws PANEL A Flush NOTE: 2-1/2’’ Deck Screws 2-1/2’’ Deck Screws HOLE ORIENTATION T-Nut Small Flush FRAME A Flush 2-1/2’’...
  • Page 16 STEP 3 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer PF 6314 1’’ x 3-3/8’’ x 31-1/2’’ FRAME A FLIP FRAME OVER 2-1/2” Deck Screw (x4) 1. Flip frame over and Attach Frame Support Board as shown.
  • Page 17 STEP 4 2-1/2’’ Deck Screws PF 6307 5/8’’ x 3-3/8’’ x 31-1/2’’ (1) PF 6347 5/8’’ x 3-3/8’’ x 31-1/2’’ (2) PF 6310 5/8’’ x 3-3/8’’ x 8-5/16’’ PF 6307 5/8’’ x 3-3/8’’ x 31-1/2’’ T-Nut Small 2-1/2’’ Deck Screws 2-1/2’’...
  • Page 18 STEP 5 2-1/2’’ Screws 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer PF 6314 1’’ x 3-3/8’’ x 31-1/2’’ FRAME B FLIP FRAME OVER 2-1/2” Deck Screw (x4) 1. Flip frame over and Attach Frame Support Board as shown above.
  • Page 19 STEP 6 Flush 3’’ From Outside 2-1/2’’ Screws of Post Flush PANEL C Check to make sure structure is square 2-1/2’’ Screws 3’’ From 2-1/2’’ Screws outside of post To end of horizontal support. Flush 2-1/2’’ Screws Flush PANEL A Flush to outside edge of 3”x 3”...
  • Page 20 STEP 7 Flush 2-1/2’’ Screws Flush 3’’ From Outside of Post 3’’ From Outside of Post to End of Horizontal Support. 2-1/2’’ Screws 2-1/2’’ Screws FRAME A FRAME B Side View of Tower 19-1/2’’ From Outside of Post 2-1/2’’ Screws 2-1/2’’...
  • Page 21 STEP 8 2-1/2’’ Screws PF 6346 5/8’’ x 3-3/8’’ x 31-1/2’’ 2-1/2’’ Screws NOTE: HOLE LOCATION FS2831 FS2830 2-1/2” Deck Screw (x4) 2-1/2 FS2829 1. Attach Tower Support Board as shown. FS2828 1-3/4 FS2827...
  • Page 22 STEP 9 5/16-18 X 4’’ Hex Head Bolt 5/16’’Loc-Washer 5/16’’ Washer 2-1/2’’ Screws T-Nut Small PF 6352 1-3/8’’ x 3-3/8’’ x 31-1/2’’ 46-5/8’’ 2-1/2” Deck Screw (x4) 1. Attach Frame Support Board as shown.
  • Page 23 STEP 10 (1) PF 6312 1-3/8’’ x 1-3/8’’ x 31-1/2’’ Flush PF 6305 5/8’’ x 3-3/8’’ x 25-3/8’’ NOTE: 2’’ Screw per side 55-1/4’’ PRE-DRILL 1-3/4’’ Screws HOLES GOING INTO DECK SUPPORTS (1) PF 6346 5/8’’ x 3-3/8’’ x 31-1/2’’ PF 6305 5/8’’...
  • Page 24 STEP 11 (7) PF 6306 5/8’’ x 3-3/8’’ x 31-3/8’’ 1-3/4’’ Screws per board Flush Flush 2-1/2’’ Screws per joint Flush PANEL B 2-1/2” Deck Screw (x8) PANEL B INSTALL 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 1/8’’.
  • Page 25 STEP 12 30mm Screws NOTE HOLE LOCATION 2-1/2’’ Screws INSIDE VIEW 77-1/4’’ Flush 2-1/2’’ Screws 26’’ FS2831 1-3/16’’ FS2830 2-1/2” Deck Screw (x8) 30mm Deck Screw (x8) 2-1/2 FS2829 1. Attach Barrier Support Board and Safety Board as shown. NOTE: Secure Barrier Board from inside barrier as shown. FS2828 1-3/4...
  • Page 26 STEP 13 NOTE: MAKE SCREW 1-5/8’’ Screws HEADS FLUSH T-Nut Small 5/16’’Loc-Washer 5/16’’ Washer 5/16-18 X 1-3/4’’ 3’’ Screws Hex Head Bolt PF 6326 1’’ x 3-3/8’’ x 42’’ SUPPORT FS2831 FS2830 2-1/2 FS2829 FS2828 1-3/4 FS2827 3” Deck Screw (x2) 1-5/8”...
  • Page 27 STEP 14 1-3/4’’ Screws 1-3/4’’ Screws PF 6313 1-3/8’’ x 3’’ x 77-1/4’’ 1-3/4’’ Screws PF 6338 3/4’’ x 3-3/8’’ x 31-1/2’’ Flush COUNTERBORE 31-1/2’’ PF 6347 1-3/4’’ Screws 5/8’’ x 3-3/8’’ x 31-1/2’’ 1-3/4’’ Screws Flush PF 6313 1-3/8’’ x 3’’ x 77-1/4’’ 1-3/4’’...
  • Page 28 STEP 15 Install 30mm Screws With Heads Flushed To Board To Avoid Protrusions. 2-1/2’’ Screws 2-5/8’’ 2-5/8’’ 2-1/2’’ Screws 30mm Deck Screws Per Board (6) PF 6327 5/8’’ x 3-3/8’’ x 23’’ FRAME C FRAME C FS2831 1-3/16’’ 2-1/2’’ Screws FS2830 30mm Deck Screw (x32) 2-1/2”...
  • Page 29 STEP 16 Flush 1-3/4’’ Screws per board (2) PF 6349 5/8’’ x 3-3/8’’ x 29-1/2’’ PF 6312 1-3/8’’ x 1-3/8’’ x 31-1/2’’ 1-3/4’’ Screws per board NOTE: Flush PRE-DRILL HOLES GOING INTO DECK SUPPORTS 12-3/4’’ 12-3/4’’ Top View of Tower 1-3/4”...
  • Page 30 STEP 17 Flush NOTE HOLE LOCATION (7) PF 6348 5/8’’ x 3-3/8’’ x 30-7/8’’ 1-3/4’’ Screws per board 1-3/4” Deck Screw (x42) 1. Install Deck Boards as shown. NOTE: Standard gap between deck boards is 1/8’’.
  • Page 31 STEP 18 PF 6303 5/8’’ x 3-3/8’’ x 30’’ 2-1/4’’ 2-1/2’’ Screws 3/4’’ FS2831 FS2830 2-1/2 2-1/2” Deck Screw (x4) 1. Attach Spacer Board as shown. FS2829 FS2828...
  • Page 32 STEP 19 PF 6323 3’’ x 3’’ x 31-1/2’’ TOWER BEAM SUPPORT 5/16-18 X 6’’ Carriage Bolt Wood Loc-Washer 5/16’’ Washer Loc Nut 1. Attach Tower Beam Support Board as shown.
  • Page 33 STEP 20 SWING BEAM SWING HANGERS - INSTALL SWING BEAM SWING HANGERS - INSTALL Swing Beam Swing Beam PF 6299 2 5/8’’x 5-3/8’’x 93’’ Flat Washer Swing Hanger Bolt Swing Beam Flat Washer Swing Hanger Bolt Swing Hanger Swing Hanger Flat Washer Flat Washer IMPORTANT!
  • Page 34 STEP 21 PF 6298 2-11/16’’x 3’’x 62’’ A-Frame SB Support 5/16”-18 x 7” Hex Head Bolt 3’’ Screws 3’’ Screws 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 6297 1-3/8’’x 3-3/8’’x 83’’ A-Frame 5/16”-18 x 2-1/2” Hex Head Bolt 5/16”...
  • Page 35 STEP 22 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” 5/16” Washer Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 36 STEP 23 5/16”-18 x 3 1/4” Hex Head Bolt Beam Brace 5/16” Loc Washer 5/16” Washer 5/16-18 T-Nut Small NOTE: Barrier Boards Removed for Clarity. 1. Install Swing Beam Brace as shown.
  • Page 37 STEP 24 5/16”-18 x 8-1/2” Hex Head Bolt 5/16”-18 x 6” Carriage Bolt 5/16” Loc Washer 5/16” Wood Loc Washer 5/16” Washer 5/16-18 T-Nut 5/16” Washer Small 5/16” Loc Nut NOTE: Barrier Boards Removed for Clarity. 1. Install Swing Beam as shown.
  • Page 38 STEP 25 2-1/2’’ Screws per board NOTE: Window Panel Removed for Clarity. FS2831 FS2830 2-1/2” Deck Screw (x8) 2-1/2 1. Secure Barrier Boards to Swing Beam Support as shown. FS2829 FS2828 1-3/4...
  • Page 39 STEP 26 PF 6342 5/8’’ x 3-3/8’’ x 7’’ PF 6344 5/8’’ x 3-3/8’’ x 5-3/8’’ (1) PF 6347 5/8’’ x 3-3/8’’ x 31-1/2’’ 1-3/4’’ Screws 1-3/4’’ Screws 1-3/4’’ Screws Flush Flush 1-3/4’’ Screws 1-3/4” Deck Screw (x8) 1. Attach Barrier Support Boards flush to bottom of deck as shown.
  • Page 40 STEP 27 Install 30mm Screws With Heads Flushed To Board To Avoid Protrusions. 30mm Screws per board (6) PF 6303 5/8’’ x 3-3/8’’ x 30’’ 30mm Screws per board Flush Flush 2-1/4’’ 2-1/4’’ 2-1/4’’ Between PF 6303 and corner post 2-1/2’’...
  • Page 41 STEP 28 NOTE: 30mm Screws LOOK FOR (1) 3’’ Screw PRE-DRILLED HOLE PF 6321 5/8’’ x 3-3/8’’ x 6-3/4’’ SUN 5/16’’ 5/16’’ CENTERED PF 6319 5/8’’ x 2’’ x 28’’ 6-3/4’’ 6-3/4’’ (2) 30mm Deck (2) 30mm Deck Screws Screws PF 6351 1’’...
  • Page 42 STEP 29 NOTE: NOTE: SHINGLES OVERHANG RAFTERS 1” TURN ROOF ASSEMBLY ON END. CENTER AND CLAMP PF 6355 (4) 30mm Deck BEFORE INSTALLING SCREWS. Screws per board (8) PF 6330 1/2’’ x 3-5/16’’ x 36-3/4’’ SHINGLE (2) PF 6355 1-3/8’’ x 1-3/8’’ x 27-3/4’’ (1) 30mm Deck Screw per board (4) 30mm Deck...
  • Page 43 STEP 30 (3) 30mm Deck Screws (2) PF 6330 1/2’’ x 3-5/16’’ x 36-3/4’’ SHINGLE (2) 2’’ Deck (5) 30mm Deck Screws Screws per board PF 6320 5/8’’ x 3-3/8’’ x 34-3/4’’ PF 6320 5/8’’ x 3-3/8’’ x 34-3/4’’ (4) 2’’ Deck Screws (4) 2’’...
  • Page 44 STEP 31 ALIGN SCREWS Flush WITH PRE DRILLS (3) 2-1/2’’ Deck Screws Per side (5) PF 6341 5/8’’ x 5-3/8’’ x 26-7/8’’ Side View Top (4) 2’’ Deck Screws per board Flush (1) PF 6340 5/8’’ x 5-3/8’’ x 26-7/8’’ 2-1/2”...
  • Page 45 STEP 32 (1) PF 6341 5/8’’ x 5-3/8’’ x 26-7/8’’ (4) 2’’ Deck Screws Flush (2) 2’’ Deck Screws (2) 2’’ Deck Screws (1) PF 6353 5/8’’ x 3-3/8’’ x 3’’ Side View Bottom 2” Deck Screw (x6) 1. Attach rock wall board and spacer as shown.
  • Page 46 STEP 33 (2) T-Nuts (2) 1-1/4’’ Hex Head Bolts (2) 1/4’’Flat Washer Per Rock (2) 1/4’’ Loc-Washer Per Rock 1. Attach Climbing Rocks as shown.
  • Page 47 STEP 34 NOTE HOLE PF 6311 1’’ x 5-3/8’’ x 21-1/2’’ 1-7/8’’ NOTE HOLES 5’’ 9-5/8’’ (2) PF 6329 1’’ x 3-1/4’’ x 4-5/8’’ TABLE SUPPORT 1-5/8’’ Screws 2’’ 1-3/4’’ Screws 2’’ Top View of Table 1-5/8’’ Screws FS2831 per board FS2830 2-1/2 FS2829...
  • Page 48 STEP 35 (2) PF 6302 3/4’’ x 3-3/8’’ x 9-3/4’’ TABLE SUPPORT (2) PF 6300 3/4’’ x 3-3/8’’ x 15-3/4’’ BENCH SUPPORT 2-1/2’’ Screws BOTH SIDES 30mm Screws 3’’ 30mm Screws 3’’ 30mm Screws Flush BOTH SIDES 11-3/8’’ Flush 6-7/8’’ 6-7/8’’...
  • Page 49 STEP 36 PF 6333 3/4’’ x 3-3/8’’ x 15-1/2’’ PF 6333 3/4’’ x 3-3/8’’ x 15-1/2’’ 2’’ Screws Flush 2’’ Screws Flush Make Certain This Side Has Holes Closest To The Edge. 1-5/8’’ (2) PF 6332 3/4’’ x 3-3/8’’ x 13’’ ARCH 2’’...
  • Page 50 STEP 37 1-5/8’’ 2’’ Screw per side 3’’ Screw 3’’ Screw FS2831 FS2830 2-1/2 FS2829 2” Deck Screw (x4) 3” Deck Screw (x2) FS2828 1. Attach Tarp Support Frame to tower as shown. 1-3/4 FS2827 1-5/8...
  • Page 51 STEP 38 PF 6331 5/8’’ x 3-3/8’’ x 31-1/2’’ 3/4’’ Screws CENTERED 3/16’’ Tarp Washer 2-1/2’’ Screw 1-1/2’’ per joint 3/4’’ Screws 3/16’’ Tarp Washer Tarp Side View FS2831 FS2830 2-1/2 2-1/2” Deck Screw (x4) 3/4” Pan Head Screw (x6) 3/16”...
  • Page 52 STEP 39 (2) PF 6334 1-3/8’’ x 3-3/8’’ x 8’’ FLUSH (4) 1-3/4’’ Deck Screws Underdeck View (2) 30 mm 1-3/16’’ Deck Screws 2” Grade PF 6295 1-3/8’’x3-3/8’’x17-1/4’’ 30mm Deck Screw (x2) Slide Stake 1-3/4” Deck Screw (x4) 1-3/4” Truss Screw (x3) Attach slide as shown.
  • Page 53 STEP 40 (2) 1/4” Washer (2) 1/4’’ x 1-3/4” Pan Screw 22,9 cm 9” 1-3/4” Pan Screw (x4) 1. Attach Safety Handle and I.D. Tag as shown.
  • Page 54 STEP 41 SWING SWING STAND-UP SWING 8” Minimum when occupied. Adjust chains at Top. 8’’ MINIMUM Swing Seat and Stand-Up Swing Assembly Installation 1. Attach Swing Seats and Stand-Up Swing to swing beam as shown. 2. Make certain to adjust clearance from bottom of swings to the surfacing while the swing is occupied. 3.
  • Page 55 STEP 42 Roof parts removed for clarity. Spacer Flat Washer Lag Screw Steering Wheel Cap Steering Wheel Assembly 1. Choose a desired location for the Steering Wheel. 2. Mount Steering Wheel as indicated. 3. Snap Steering Wheel Cap into place.
  • Page 56 STEP 43 Telscope Assembly Mounting Screw Mounting Bracket Telescope Assembly 1. Position Mounting Bracket in desired location. 2. Attach Mounting Bracket to the unit using the Mounting Screw provided. 3. Insert the Telescope into the Mounting Bracket as shown. STEP 45 3/4’’...
  • Page 57 STEP 44 Fold up 5/16” Washer Anchor-It Strap 1-1/2” Lag Screw Anchor-It 5/16’’ x 1-1/2” Lag Screw (x4) 1. Place swing set in fi nal location and mount Anchor-It(s) at locations circled above. 2. Twist the Anchor-It into the ground until only the loop is exposed. 3.
  • Page 58 PRODUCT WARRANTY & REGISTRATION Please register online to properly initiate your product warranty & registration Benefits of registering online: ■ Quick & simple from home or mobile ■ Record your purchase in our system ■ Initiate product warranty ■ Improved customer support ■...
  • Page 59 7. “Significant color changes” to wood components is at the discretion of Backyard Products and require proof in the form of photographs or inspection by Backyard Play Systems.
  • Page 60 WARRANTY Please feel free to call our Consumer Help Line Toll Free 1-800-844-9273 Monday - Friday 8:00 AM to 6:00 PM EST Saturday 8:30 AM to 5:00 PM EST No warranty is offered on the following: (1) equipment subject to abuse, negligence, improper installation, vandalism, acts of God, unauthorized alteration or attachment to equipment other than our own: or (2) equipment subjected to improper use, service or repair by customer or any third party.
  • Page 61 A Backyard Products Company Got Questions? We’ve got answers! Call our Customer Support Representatives 1-800-844-9273 Available Monday - Friday, 7am - 5pm (CST) Weekend support available April through July Technical support from experienced customer service representatives who have actually built a swing set themselves.
