The areas discussed in this section control the system's "personality". Most areas have factory
settings that will be appropriate in many situations (these are indicated where they exist).
Remember, if you make a mistake in an entry, press the "ESCAPE" or "ESC" button. To tell the
system you have completed an entry, press the "ENTER" button. Also, remember to watch the flashing cursor
so that you make the correct response to each prompt.
AREA 00 - CHANGING PROGRAMMING ACCESS CODE
PURPOSE: To change the code that must be used to enter the programming mode to some combination
that will be secret and easy to remember. Factory setting = 000000.
SYSTEM PROMPT
PROG ACCESS CODE IS _______
AREA 01 - SETTING RELAY 2 CONFIGURATION
PURPOSE: There are six (6) different configurations in which relay 2 can be set. Below is a list of these
configurations, followed by an explanation of each. The numbers next to each configuration are
the digits which you will use to program the system. These configurations are as follows:
If the second relay is set to Control, it will activate when the resident dials the tone activation
digit for relay 2 or when terminal "AUX" on the Horizon controller board sees a contact closure
to common. If set to Shunt, it activates whenever relay 1 activates to temporarily bypass an
alarm sensor monitoring this entry. If set to Alarm, it will activate if (1) the terminal marked
"AUX" on the Horizon controller board sees a contact closure to "COMMON" when relay 1 is
de-energized (e.g., the controlled entry is forced open), (2) the terminal marked "AUX" on the
Horizon controller board sees a contact closure for more than one minute after the main relay
has de-energized (e.g., the entry is held open), or (3) the strikes-and-out feature has been
violated (see step 03 for further discussion of the strikes-and-out feature). If set to CCTV, the
resident dials the activation digit for relay 2 to activate the closed circuit TV. The relay will be
deactivated when the call is terminated (by the resident granting or denying entry or by the call
"timing out"). If set to CCTV Immediate, relay 2 will activate the closed circuit TV as soon as a
visitor dials a resident. After the tenant call is terminated (by the resident granting or denying
entry or by the call "timing out"), relay 2 will remain activated for the programmed activation
time. If set to Emergency Call (not available in Canada), relay 2 will act in the same manner
as if the system was set to CCTV Immediate. Furthermore, if status line 2 is activated by an
emergency call button (or another type of device that provides a contact closure) and the
system is currently not in programming or making a tenant call, the system will activate the
closed circuit TV attached to relay 2 and place a call to the programmed emergency call
number. When the manager (or an authorized person) answers the emergency call, the system
will connect that person to the system's speaker/microphone. Factory setting = Control.
Rev B
5 - INITIAL SYSTEM SET-UP
EXAMPLE OF
TYPICAL ENTRY
555555 + ENTER
0 = Control
1 = Shunt
2 = Alarm
Doc. 6001036
IMPORTANT NOTES
THIS IS A SIX DIGIT CODE CONSISTING
OF NUMBERS ONLY.
3 = CCTV
4 = CCTV Immediate
5 = Emergency Call (not available in Canada)
