dallmeier DVE-4 Configuration

Streamer and encoder

Advertisement

Configuration
English
Streamer and Encoder
DVE-4 / DVE-8 / DVE-16
Rev. 1.0.0 / 2014-02-19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVE-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for dallmeier DVE-4

  • Page 1 Configuration English Streamer and Encoder DVE-4 / DVE-8 / DVE-16 Rev. 1.0.0 / 2014-02-19...
  • Page 2 Third-party trademarks are named for information purposes only. Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identification of third-party trademarks and indication of the respective holder of rights. In case that protected rights are not indicated separately, this circumstance is no reason to assume that the respective trademark is unprotected.
  • Page 3: Table Of Contents

    DVE-4 / DVE-8 / DVE-16 Table of Contents Introduction ....................4 Validity ......................4 Documents ......................4 Typographical Conventions................4 Safety Instructions..................5 General Notes....................7 Appropriate Use ....................7 Performance Features ..................7 Warranty ......................7 Login and Language ..................8 Login .......................8 Language ......................9 Configuration ....................10 Device Parameters ..................10 5.1.1...
  • Page 4: Introduction

    DVE-4 / DVE-8 / DVE-16 Introduction Validity This document is valid for the configuration of the devices DVE-4, DVE-8 and DVE-16. The descriptions in this document are based on the following versions: • Firmware version V1.1.0 Illustrations in this document may differ from the actual product.
  • Page 5: Safety Instructions

    System Components Only use internal components that have been tested and approved by Dallmeier. Inap- propriate internal components may cause malfunctions, damages and data loss and may result in the loss of warranty.
  • Page 6 DVE-4 / DVE-8 / DVE-16 Lightning Storms To avoid damage to the device by electrical surge during lightning storms, unplug the de- vice from the mains power supply (pull out the power plug). This is also recommended, when the device has been unused for a long period of time.
  • Page 7: General Notes

    General Notes Appropriate Use The DVE-4, DVE-8 and DVE-16 devices are analog video encoder for 4, 8 or 16 channels. It is able to receive and encode video data via their BNC entries and simultaneously stream them via Ethernet (unicast or multicast) to a receiver.
  • Page 8: Login And Language

    If you do not know the IP address of the device or not using the device for the first time, you can use the Dallmeier software “PService” in order to find out the IP address of the device. It is recommended to change the device’s registered factory IP address.
  • Page 9: Language

    DVE-4 / DVE-8 / DVE-16 Language The user interface language can be specified in the login dialog.  Set the connnection to the device as described above. Fig. 4-2  Select from the dropdown box on the top right the required language.
  • Page 10: Configuration

    DVE-4 / DVE-8 / DVE-16 Configuration After the required analog cameras were connected to the respective device, the settings can be configured.  Login to the web interface of the device as described above. The user interface is displayed depending on the setting.
  • Page 11: Device Name

    DVE-4 / DVE-8 / DVE-16 5.1.1 Device Name The name and number of the device can be changed.  Open the Basic Information dialog via Remote Configuration > Device Parameters > Device Information. Fig. 5-3  Enter in the Device Name field an new name for the device if required.
  • Page 12: Camera Settings

    DVE-4 / DVE-8 / DVE-16 Time Server If the NTP option is activated, the current time can be obtained from a time server.  Enable the NTP option.  Enter the IP address of the time server in the Server Address field.
  • Page 13: Video Settings

    DVE-4 / DVE-8 / DVE-16 Fig. 5-5  Select from the Channel No. drop down box the required camera. The current live image from the camera is displayed. Left above date and time is displayed at the bottom right the camera name.
  • Page 14: Motion Detection

    DVE-4 / DVE-8 / DVE-16  Select from the Channel No. drop down box the required camera.  Make the required settings.  Activate under Copy to Camera the required cameras for which these settings are to be transferred.  Click Save.
  • Page 15 DVE-4 / DVE-8 / DVE-16 Fig. 5-8  Repeat the previous step for additional areas if required.  Set the sensitivity of the motion detection with the Sensitivity slider if required (the farther to the right the more sensitive).  Click Save.
  • Page 16 DVE-4 / DVE-8 / DVE-16 The Edit Scheduler Time dialog is displayed. Fig. 5-10  Select the required weekday.  Set the Start Time and the End Time for the Period 1.  Repeat the previous step for further day periods if required.
  • Page 17: Video Loss

    DVE-4 / DVE-8 / DVE-16 Fig. 5-12  Enable in the Normal Linkage area the Audible Warning option if required.  Activate an Alarm Output if required.  Enable at Trigger channel cameras that should be activated when a motion detection event.
  • Page 18 DVE-4 / DVE-8 / DVE-16 The Edit Scheduler Time dialog is displayed. Fig. 5-14  Select the required weekday.  Set the Start Time and the End Time for the Period 1.  Repeat the previous step for further day periods if required.
  • Page 19: Private Zones

    DVE-4 / DVE-8 / DVE-16 Fig. 5-16  Select in the Normal Linkage area the Audible Warning option if required.  Enable an Alarm Output if required.  Click Save. 5.2.5 Private Zones The Privacy Mask dialog allows to hide certain areas of the camera image.
  • Page 20: Tamper Alarm

    DVE-4 / DVE-8 / DVE-16 Fig. 5-18  Click Draw Area.  Drag with the mouse by drag and drop an area above the for the private zone required area in the live image of the camera.  Repeat the previous step for other areas if required.
  • Page 21 DVE-4 / DVE-8 / DVE-16  Select from the Channel No. drop down box the required camera.  Activate the Enable Tamper-proof check box.  Click Draw Area.  Drag with the mouse by drag and drop an area above the for the tamper-proof required area in the live image of the camera.
  • Page 22 DVE-4 / DVE-8 / DVE-16 The Edit Scheduler Time dialog is displayed. Fig. 5-21  Select the required weekday.  Set the Start Time and the End Time for the Period 1.  Repeat the previous step for further day periods if required.
  • Page 23: Text Overlay

    DVE-4 / DVE-8 / DVE-16 Linkage The Linkage Method tab allwos to specify whether an audible warning sound to be trig- gered.  Select the Linkage Method tab. Fig. 5-23  Select in the Normal Linkage section the Audible Warning option if required.
  • Page 24: Holiday Settings

    DVE-4 / DVE-8 / DVE-16  Enter the required texts in the text boxes.  Drag with the mouse the text fields in the camera image to the required position.  Activate under Copy to Camera the required cameras for which these settings are to be transferred.
  • Page 25: Network Settings

    DVE-4 / DVE-8 / DVE-16 Network Settings The device’s IP address can be changed in the TCP/IP dialog. It can also be configured to use DHCP (automatic assignment of network settings through a server).  Open the TCP/IP dialog via Remote Configuration > Network Settings > TCP/IP.
  • Page 26 DVE-4 / DVE-8 / DVE-16 Fig. 5-28  Select from the Alarm Input No. drop down box the required alarm input.  Select from the Alarm Type drop down box the required type: NC = normally closed NO = normally opened ...
  • Page 27: Alarm Outputs

    DVE-4 / DVE-8 / DVE-16  Enable in the Normal Linkage section the Audible Warning check box.  Click Save. 5.4.2 Alarm Outputs The four alarm outputs can be configured.  Open the Alarm Output Settings dialog via Remote Configuration >...
  • Page 28: User Management

    DVE-4 / DVE-8 / DVE-16 Fig. 5-31  Select from the Exception Type drop down box the required exception.  Select Audible Warning as Normal Linkage.  Enable an Alarm Output if required.  Click Save. User Management The user management allows the management of user structures. In addition to the ad- ministrator with all permissions the user management allows to define different access and configuration rights for two different local user groups (user/operator).
  • Page 29: New User

    DVE-4 / DVE-8 / DVE-16  Click Modify. The Modify user dialog is displayed. Fig. 5-33  Enter a new Password.  Confirm the password.  Click OK. 5.6.2 New User A distinction is made between two local user groups: Operator and User. For these default permissions are configured.
  • Page 30 DVE-4 / DVE-8 / DVE-16 The Add user dialog is displayed. Fig. 5-35  Enter an new user in the User Name field.  Enter a Password for the new user.  Confirm the password.  Select from the Level drop down box the required user status.
  • Page 31: Delete User

    DVE-4 / DVE-8 / DVE-16 The new user is displayed in the User Information dialog. Fig. 5-37 5.6.3 Delete User  Open the User Information dialog.  Select the required user.  Click Delete.  Confirm the subsequent info dialog.
  • Page 32: Reboot

    DVE-4 / DVE-8 / DVE-16 5.7.1 Reboot Proceed as follows in order to reboot the device:  Click Reboot.  Confirm the subsequent info dialog. The device is rebooting. 5.7.2 Reset The default settings of the device can be restored to the network configuration or the device can also be completely reset to factory settings.
  • Page 33: Export Configuration

    DVE-4 / DVE-8 / DVE-16  Click Import. The configuration settings are restored and the device is restarted. 5.7.4 Export Configuration Settings and parameters can be exported to a configuration file. This can be re-imported as described above.  Click Export in the Export Config. File section.
