Summary of Contents for Seura Shade Series 2 SHD2-43
- Page 1 WARRANTY REGISTRATION REGISTER FOR EXTRA BENEFITS Activate within 30 days of purchase: seura.com/activate Shade Series 2 ™ SHD2-43 SHD2-55 WELCOME GUIDE SHD2-65 SHD2-75...
-
Page 3: Specifications
Specifications 43 INCH 55 INCH 65 INCH 75 INCH Model: SHD2-43 Model: SHD2-55 Model: SHD2-65 Model: SHD2-75 OPERATING TEMP. RANGE -24°F to 104°F* IDEAL OPERATING TEMP. 32°F to 104°F NON-OPERATING TEMP. -24°F to 140°F OPERATING HUMIDITY 10%-90% Relative Humidity, Non-Condensing WATERPROOF RATING IP56 Rating †... - Page 4 WARNING: READ ALL INSTRUCTIONS BEFORE ATTEMPTING TO INSTALL OR SERVICE THIS PRODUCT. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure CAUTION that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 5 AVERTISSEMENT: LIRE TOUTES LES INSTRUCTIONS AVANT D’INSTALLER OU SERVICE CE PRODUIT. Ce symbole est destiné à alerter l’utilisateur de la présence d’une «tension dangereuse» non isolée à l’intérieur de l’enceinte du CAUTION produit qui peut être d’une amplitude suffisante pour constituer un risque de choc électrique pour les personnes.
- Page 6 WARNINGS ATTENTION Never place a television set in an unstable Ne placez jamais un téléviseur dans un endroit instable. Un location. A television set may fall, causing serious téléviseur peut tomber personal injury or death. Many injuries, particularly et causer des blessures graves ou mortelles. Beaucoup de to children, can be avoided by taking simple blessures, en particulier aux enfants, peuvent être évités en precautions such as:...
-
Page 7: Fcc Supplier's Declaration Of Conformity
FCC Supplier’s Declaration of Conformity Séura Outdoor Entertainment SHD2-43, SHD2-55, SHD2-65, SHD2-75 This device complies with part 15 of the FCC Rules. Operation is subject to the follow two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 8: Important Safety Instructions
Important Safety Instructions Read these instructions. 16. The apparatus shall be connected to a MAINS socket outlet with a protective earthing connection. Where the MAINS 2. Keep these instructions. plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable. 3. -
Page 9: Consignes De Sécurité Importantes
Consignes De Sécurité Importantes Lisez ces instructions. 16. L’appareil ne doit être relié à une prise secteur dotée d’une connexion de terre de protection. Lorsque la prise du RESEAU D’ALIMENTATION Conservez ces instructions. ou une prise placée sur l’appareil est utilisée comme dispositif de 3. - Page 10 The screen is most optimally viewed at ambient temperatures of 32°F to 104°F Operation and Storage Requirements The maximum ambient temperature range for operating the device is -24°F to 104°F . The screen is most optimally viewed at ambient temperatures of 32°F to 104°F. Do not install the device in the proximity of heat sources, such as heating pipes, heaters, furnaces or other devices that radiate heat.
- Page 11 Get to know your Séura Shade Series Outdoor Display ® ™ If you have questions, call Séura at 1-800-957-3872 to speak to a design expert. Sunlight — Do not use this product Cable Management in direct sunlight. This product is When running cables from inside the compartment designed for shaded applications to the sources, allow adequate spacing at the foam...
- Page 12 Shade Series ® ™ Shade Series Outdoor Display ™ In the Box WARRANTY REGISTRATION REGISTER FOR EXTRA BENEFITS Activate within 30 days of purchase: seura.com/activate Shade Series 2 ™ SHD2-43 SHD2-55 WELCOME GUIDE SHD2-65 SHD2-75 IR Remote Power Cable Welcome Guide...
- Page 13 Parts RF Window Hinged Media Compartment Cover VESA Pattern Mounting Holes Media Connections Cable Entry with Gasket...
- Page 14 Installing Your Shade Series ™ Séura Shade Series™ is designed to be wall-mounted using the standard mounting hole pattern (VESA) on ® the back of the display. Use an outdoor-rated wall mount (sold separately) to mount to most outdoor wall surfaces.
- Page 15 Connecting Your Shade Series ™ Open the weatherproof media compartment to access all connections. To connect a source such as a streaming device or cable box, connect one end of an HDMI cable (or other, cables not included) into an HDMI port on the display and the other end into your device.
-
Page 16: Vesa Wall Mounting
VESA Wall Mounting Install your wall mount on a solid wall perpendicular to the floor. When attaching to other building materials, please contact your nearest dealer. If installed on a ceiling or slanted wall, it may fall and result in severe personal injury. We recommend that you use a Séura wall mount when mounting the display to a wall. -
Page 17: Wall Bracket
Consult with your local dealer for a wall mount that complies with the VESA pattern and weight of your display model. Refer to the instructions provided with your wall mount. Carefully attach the wall mount bracket at the rear of the display. Install the wall mount bracket on a solid wall perpendicular to the floor. If you are attaching the display to other building materials, please contact qualified personnel to install the wall mount. -
Page 18: Remote Functions
Remote Functions Power Input Source Selection Content Navigation Control Menu Controls Exit Menu Mute Turns On or Off Audio Channel Control Volume Control Last/Recall Last Channel Numerical Keypad... - Page 19 Caring for your Séura Shade Series ® ™ While Shade Series may be safely exposed to weather and moisture, the use of a Séura Outdoor Cover when not in use is recommended. Transporting the Display When transporting Shade Series, never carry it by holding or putting pressure on the screen. Screen pressure may damage the LCD or weaken the waterproof seal.
- Page 20 Product will be made available a Product; upon request and are also available on the Séura website at https://www.seura.com/warranty/. This warranty is valid only F. Alterations, modifications, including use of unauthorized with respect to Product sales in the U.S. and Canada.
- Page 21 purchase receipt or other original purchase date proof as may Toll-Free Technical Support: Please call 1-800-957-3872 to be reasonably required by Séura to verify the Product’s warranty speak with a Séura Technical Support Representative. Séura eligibility. Séura shall have no liability with respect to Products Representatives are available Monday-Friday, 8:00am-4:30pm whose serial number has been removed, defaced, replaced, or Central Time.
-
Page 22: Troubleshooting
Troubleshooting If the product is not working properly, please check the following troubleshooting solutions before you contact customer service: Challenge Possible Solution • Make sure to check that the AC power cable is connected to an outlet and the display Will Not •... - Page 24 Control Documentation and On Screen Display Menu To access the in-depth operation manual including menu options and current control documents, please visit www.seura.com/download-center For additional technical support, please contact Séura at 1-800-957-3872 during regular business hours: M-F 8:00 am - 4:30 pm, Central Time.
