- Page 1 USER MANUAL Vanity TV Mirror T V SIZES 10-INCH, 19-INCH, 27-INCH MODEL NUMBERS 10.5 19.5 27.5 W W W. SEUR A .COM...
- Page 2 Thank you for selecting a Séura Television Mirror. This product has been inspected and packaged carefully before shipment. Please read this guide before beginning installation. Please keep this manual for future reference. Information in this manual is subject to change without prior notice. FCC Information This equipment has been tested and found to comply with limits for a class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 Before Installation WARNING: READ ALL INSTRUCTIONS AND REVIEW ALL DRAWING SHEETS BEFORE ATTEMPTING TO INSTALL OR SERVICE THIS PRODUCT. When installing and during use of this product, basic safety precautions should always be followed to reduce the risk of fire, electric shock and/or injury to persons including the following: •...
-
Page 4: Table Of Contents
Contents B E FORE US E Lighting and Performance ....................5 Care and Maintenance ......................5 INS TA LL ATION A ND S E T U P Display Requirements ......................6 Setup ............................7 Installation ..........................8 Making Connections....................... 9 ME N US A ND S E T TIN G S On Screen Display Menu (OSD) ..................10 INTEG R ATION A ND C ONTROL RS-232 Protocol ........................14... -
Page 5: Lighting And Performance
Lighting and Performance The environment in which the Television Mirror is installed will affect the product performance. The key factors to consider for proper installation are surroundings and ambient light. Use the following guidelines to maximize the performance of the Séura product: Type of Lighting Avoid direct natural sunlight and excessive fluorescent lighting. -
Page 6: Display Requirements
Display Requirements Operation and Storage Requirements The ambient temperature for operating the device is between 41 to 122 degrees Fahrenheit. Do not install the device in the proximity of heat sources, such as heating pipes, heaters, furnaces or other devices that radiate heat. Mount the device in such a way that it is protected against moisture. -
Page 7: Setup
DATE: • Hang mirror assembly. Ensure the brackets are interlocked and mirror NOTE: PLEASE SIGN AND DATE THIS PAGE BEFORE RETURNING TO SEURA, SIGNIFYING YOU AGREE TO ALL DETAIL VIEW TOLERANCES PROPRIETARY AND CONFIDENTIAL SPECIFICATIONS SHOWN ON ALL DRAWING SHEETS. THE BUILD PROCESS WILL NOT BEGIN WITHOUT AN TV POWER PLUG is secure. -
Page 8: Installation
DATE: product with at least two people. TOLERANCES PROPRIETARY AND CONFIDENTIAL NOTE: PLEASE SIGN AND DATE THIS PAGE BEFORE RETURNING TO SEURA, SIGNIFYING YOU AGREE TO ALL (UNLESS OTHERWISE NOTED) THE INFORMATION CONTAINED IN THIS DOCUMENT SHEET SPECIFICATIONS SHOWN ON ALL DRAWING SHEETS. THE BUILD PROCESS WILL NOT BEGIN WITHOUT AN FRACTIONAL: 1/8"... -
Page 9: Making Connections
USB extension cable. Connecting a Home Automation System With the RS-232 interface (9 pin d-subminiature connector female) you can connect a serial cable for communication with a home automation system, PC, etc. The baud rate is 115200. Visit www.seura.com for control documentation. -
Page 10: On Screen Display Menu (Osd)
On Screen Display Menu (OSD) On Screen Display Menu (OSD) In the on screen display menu (OSD) you can adapt the characteristics of your display based on personal preferences. OSD menus include Video, Audio, TV, Setup, and Parental. 1. Press on your remote control to open the OSD menu 2. - Page 11 OSD (cont.) Advanced Video Settings The Advanced Video Settings menu offers further options to refine the image characteristics of your Séura Television Mirror. Adjustment options include: MPEG NR Adaptive Luma Control Flesh Tone DI Film Mode Blue Stretch Game Mode Blue Mute Gamma Color Temperature...
- Page 12 OSD (cont.) TV Settings The TV Settings menu offers options to set up and adjust preferences using the built-in television tuner. Adjustment options include: Tuner Mode Channel Scan Channel Skip TUNER MODE Select the option for obtaining television programming: Cable, Antenna CHANNEL SCAN Select Channel Scan to begin automatic scanning of channels.
- Page 13 OSD (cont.) Parental Menu The Parental Menu offers options to restrict program viewing based on various national rating systems. To access the menu, enter the 4-digit Password using the keypad on the remote. The factory default password is “0000”. Adjustment options include: Program Block Change Password Clean All (or reset settings)
-
Page 14: Rs-232 Protocol
ETX commands must be ignored by the controller. STX and ETX must be sent as hex commands; all other data must be sent as ASCII characters. Contact Séura Technical Support for instructions on accessing the Service Menu at 800-957-3872 or techsupport@seura.com • Each command is a string of ASCII characters plus a Parameter. - Page 15 RS-232 Protocol Query Examples: Use a “?” as the parameter and the TV will return the current value for that command. There is no “OK” returned after a query. Example of a Power Query with no Unit Number. [0x02]PWD:?[0x03] Would return this status if the TV is ON: [0x02]1[0x03] Or, this status if the TV is OFF: [0x02]0[0x03]...
- Page 16 RS-232 Protocol INPUT (INP) COMMAND RESPONSE QUERY RESPONSE [0x02]INP:0[0x03] [0x02]OK[0x03] [0x02]INP:? [0x03] [0x02]0[0x03] [0x02]INP:1[0x03] [0x02]OK[0x03] [0x02]INP:?[0x03] [0x02]1[0x03] HDMI 1 TUNER [0x02]INP:2[0x03] [0x02]OK[0x03] [0x02]INP:?[0x03] [0x02]2[0x03] [0x02]INP:3[0x03] [0x02]OK[0x03] [0x02]INP:?[0x03] [0x02]3[0x03] HDMI 2 [0x02]INP:6[0x03] [0x02]OK[0x03] [0x02]INP:?[0x03] [0x02]6[0x03] COMPONENT [0x02]INP:7[0x03] [0x02]OK[0x03] [0x02]INP:?[0x03] [0x02]7[0x03] POWER (PWD) COMMAND RESPONSE QUERY...
-
Page 17: Ir Commands
0000 006d 0000 0020 000a 0047 000a 0740 000A 0047 000A 001F 000A 001F 0718 000A 0047 000A 001F 000A 001F 000A 001F 000A 001F 000A 0047 000A 001e 000a 001e 000a 001e 000a 0047 Download these codes at http://www.seura.com/download-center... -
Page 18: Troubleshooting
Troubleshooting If the product is not working properly, please check the following troubleshooting hints before you contact customer service: Symptoms Possible Solution Check the status LED. The LED should illuminate blue for a few moments when the TV is powered on, then extinguish. Please check if an input source is available and that the port of the device has been connected correctly in the Service Settings/ Blank screen Input Ports menu. -
Page 19: Ports And Media Support
* Security hardware is optional on lighted mirrors and lighted TV mirrors only Additional cost for customizations. † Mini jack connection on TV, product includes adapter cables Publish date: July 27, 2018. Information is subject to change without notice. 1230 Ontario Road Green Bay, Wisconsin 54311 © 2018 Séura 1-800-957-3872 contacts@seura.com www.seura.com... -
Page 20: Product Limited Warranty
Product will be made available upon viruses, data loss, and other potentially destructive programs. request and are also available on the Séura website at https://www.seura.com/warranty/. This warranty is valid only with respect to Product sales in the U.S. and Canada.
