Page 1
Q U I E T C O M F O R T 3 5 I I G A M I N G H E A D S E T...
Page 2
I M P ORTA N T SA F ET Y I N STR UCT IO NS Please read and keep all safety, security, and use instructions. Bose Corporation hereby declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU and all other applicable EU directive requirements. The complete declaration of conformity can be found at: www.Bose.com/compliance...
Page 3
I M P ORTA N T SA F ET Y I N STR UCT IO NS Contains small parts which may be a choking hazard. Not suitable for children under age 3. This product contains magnetic material. Consult your physician on whether this might affect your implantable medical device.
Page 4
The low power radio-frequency devices must be susceptible with the interference from legal communications or ISM radio wave radiated devices. DON’T attempt to remove the rechargeable lithium-ion battery from this product. Contact your local Bose retailer or other qualified professional for removal.
Page 5
REG U LATORY I N FO R MAT IO N Please dispose of used batteries properly, following local regulations. Do not incinerate. China Restriction of Hazardous Substances Table Names and Contents of Toxic or Hazardous Substances or Elements Toxic or Hazardous Substances and Elements Polybrominated Polybrominated Lead...
Page 6
Taiwan Importer: Bose Taiwan Branch, 9F-A1, No. 10, Section 3, Minsheng East Road, Taipei City 104, Taiwan Phone Number: +886-2-2514 7676 Mexico Importer: Bose de México, S. de R.L. de C.V., Paseo de las Palmas 405-204, Lomas de Chapultepec, 11000 México, D.F. Phone Number: +5255 (5202) 3545 Charging Temperature Range: 32°...
Page 7
Bose Connect app. In order to receive security updates via the mobile application, you must complete the product setup process in the Bose Connect app. If you do not complete the setup process, you will be responsible for installing security updates that Bose makes available via btu.bose.com Amazon, Alexa, and all related logos are trademarks of Amazon, Inc.
Page 9
LI CEN SE D I S CLOS UR E S “Work” shall mean the work of authorship, whether in Source or Object form, made available under the License, as indicated by a copyright notice that is included in or attached to the work (an example is provided in the Appendix below).
CON TE NTS WHAT’S IN THE BOX Contents ..........................14 BOSE CONNECT APP SETUP Download the Bose Connect app ................15 HOW TO WEAR Adjust the headband ..................... 16 Button orientation ......................17 Gaming microphone ...................... 18 Attach the microphone ..................18 Adjust the microphone ..................
Page 12
CON TE NTS VOICE ASSISTANT Voice assistant options ....................27 Set up your voice assistant ..................27 Access Google Assistant ....................28 Things to try ......................29 Access Amazon Alexa ....................30 Things to try ......................31 Access voice control on your mobile device............32 NOISE CANCELLATION Noise cancelling modes....................
Page 13
CON TE NTS BATTERY Charge the headset ......................39 Charging time......................39 Hear the battery level ................... 39 HEADSET STATUS Bluetooth status ......................40 Battery status ........................41 VOICE PROMPTS Available languages ....................... 42 Change the language ....................42 Disable voice prompts ....................42 CARE AND MAINTENANCE Store the headset ......................
Page 14
WHAT ’S I N T H E BOX CONTENTS Confirm that the following parts are included: Bose QuietComfort 35 II Gaming Headset Carry case Gaming microphone PC desktop controller Charging cable 3.5 mm to 2.5 mm audio cable NOTE: If any part of the product is damaged, don’t use it. Contact your authorized Bose dealer or Bose customer service.
BOSE CON N E CT AP P S ET UP The Bose Connect app lets you set up and control the headset from any mobile device, such as a smartphone or tablet. Using the app, you can choose your voice prompt language, manage headset settings, and access new features through updates.
HOW TO WE A R ADJUST THE HEADBAND Before placing the headset on your head, adjust the headband so it’s evenly centered on the top of your head. The headband should rest gently on your head. E N G...
HOW TO W E AR BUTTON ORIENTATION The inner scrims (cloth covers) of the headset earcups are marked with an L (left earcup) and R (right earcup). There are three buttons on the right earcup and one button on the left earcup. Match the right earcup with your right ear and the left earcup with your left ear.
NOTE: When the gaming microphone is connected, Bluetooth is disabled and the Bose Connect app can’t find your headset. Attach the microphone 1. Connect the gaming microphone to the 2.5 mm auxiliary port on the left earcup.
HOW TO W E AR Adjust the microphone Microphone placement is important for clear communications. Grasp the gaming microphone and adjust so it’s level with your mouth and not touching your lips. NOTE: You may need to adjust the microphone position for better sound. Check your voice level using the audio settings in your gaming system’s settings menu.
On the right earcup, slide the Power/Bluetooth switch I to the right. STANDBY Standby conserves the headset battery when the headset isn’t in use. To set up and customize the standby timer, use the Bose Connect app. POWER OFF Slide I to the left.
HEA DSET CO NT RO L S The headset controls are located on the right earcup. NOTE: The buttons are disabled when the gaming microphone is connected. MEDIA PLAYBACK AND VOLUME Volume up Multi-function button Volume down FUNCTION WHAT TO DO Play/Pause Press the Multi-function button V.
HEA DSET CO N T R O L S PHONE CALLS The Multi-function button V and microphone are located on the right earcup. Microphone Multi-function button FUNCTION WHAT TO DO Answer/End a call Press the Multi-function button V. Decline an incoming call Press and hold V for 1 second.
HEA DSET CO N T R O L S ACTION BUTTON FUNCTIONS The Action button is a programmable button that allows you to quickly and easily access Google Assistant, Amazon Alexa, or noise cancellation. The Action button is located on the back of the left earcup. NOTES: ...
HEA DSET CO N T R O L S GAMING CONTROLS Turn on noise cancellation 1. Connect the gaming microphone to the headset (see page 18). 2. On the right earcup, slide the Power/Bluetooth switch I to the right. NOTE: You can still use the headset for gaming when noise cancellation is off. Mute/Unmute the gaming microphone Slide the in-line controller down to mute the microphone.
HEA DSET CO N T R O L S PC desktop controller Use the PC desktop controller to adjust the volume and turn on mic monitoring while gaming. NOTE: For PC users only. Connect PC desktop controller to your PC 1. Connect the PC desktop controller to a USB port on your PC. 2.
Page 26
HEA DSET CO N T R O L S Mic monitoring Mic monitoring controls how much of your own voice you hear while using the headset. 1. Press the button on the controller to turn on mic monitoring. 2. Repeat to cycle between low, medium, high, and off. NOTE: To quickly turn off mic monitoring, press and hold the button on the controller.
VOI CE ASSI STA N T VOICE ASSISTANT OPTIONS You can set the headset to quickly and easily access Google Assistant, Amazon Alexa, or voice control capabilities on your mobile device. NOTES: • You can’t set the headset to access Google Assistant and Amazon Alexa at the same time.
VOI CE ASSI STA N T ACCESS GOOGLE ASSISTANT Your headset is optimized for Google Assistant, making your headset the perfect companion for getting stuff done on your travels or commute. Continue your conversations while on the go and easily access the best of Google, from Google Play Music to Google Maps.
VOI CE ASSI STA N T Things to try Press the Action button, and then say: ACTION EXAMPLES OF WHAT TO SAY Enjoy entertainment Play some music Keep in touch Text mom “see you in 5” Get answers What’s the weather this weekend? Manage your day Tell me about my day E N G...
VOI CE ASSI STA N T ACCESS AMAZON ALEXA The headset is Amazon Alexa enabled. With Alexa, you can ask to play music, hear the news, check the weather, control smart home devices, and more. Using Alexa on your headset is simple, just use the Action button, make a request, and Alexa responds instantly.
VOI CE ASSI STA N T Things to try Press the Action button, and then say: ACTION EXAMPLES OF WHAT TO SAY Talk to Alexa What can you do? Play rock music. NOTE: Amazon Music is set as the default music Play audio service.
VOI CE ASSI STA N T VOI CE ASSI STA N T ACCESS VOICE CONTROL ON YOUR MOBILE DEVICE You can use the Multi-function button V on your headset to access the native voice control on your mobile device. To access your mobile device voice control, press and hold V for 1 second. You hear a tone that indicates voice control is active.
NOTE: Each time you power on the headset, your noise cancelling mode defaults to High. SET THE ACTION BUTTON TO NOISE CANCELLATION 1. In the Bose Connect app, tap the gear icon to access Action button settings. 2. Select Noise Cancellation. Change the noise cancelling mode Press and release the Action button.
You can play audio from only one device at a time. NOTES: • For the best experience, use the Bose Connect app to set up and connect your mobile device (see page 15). • When the gaming microphone is connected, Bluetooth is disabled and the Bose Connect app can’t find your headset.
B LU E TO OT H CO NN E CT I O NS 3. Select your headset from the device list. NOTE: Look for the name you entered for your headset in the Bose Connect app. If you didn’t name your headset, the default name appears.
B LU E TO OT H CO NN E CT I O NS DISCONNECT A MOBILE DEVICE Use the Bose Connect app to disconnect your mobile device. TIP: You can also use Bluetooth settings to disconnect your device. Disabling the Bluetooth feature disconnects all other devices.
B LU E TO OT H CO NN E CT I O NS CLEAR THE HEADSET DEVICE LIST 1. Slide the Power/Bluetooth switch I to the right and hold for 10 seconds, until you hear “Bluetooth device list cleared.” NOTE: If you’re not wearing the headset, slide I to the right and hold for 10 seconds, until the Bluetooth light blinks blue.
W I R ED CO NN E CT I O NS CONNECT THE AUDIO CABLE Use the audio cable to connect a non-wireless device or if the headset battery is depleted. 1. Connect the cable to the 2.5 mm port on left earcup. 2.
BATT E RY CHARGE THE HEADSET 1. Connect the small end of the USB cable to the micro-USB port on the right earcup. 2. Connect the other end to a USB wall charger. The battery light blinks amber. When the battery is fully charged, the battery light glows green (see page 41).
HEA DSET STAT US BLUETOOTH STATUS The Bluetooth light is located on right earcup and shows the connection status of mobile devices. Bluetooth light LIGHT ACTIVITY SYSTEM STATE Blinking blue Ready to connect Blinking white Connecting Solid white (10 seconds) Connected Disconnected E N G...
Medium to full charge Blinking amber Charging Solid amber Low charge Blinking red Need to charge Solid red Charging error - contact Bose customer service TIP: You can also check the battery level of the headset using the Bose Connect app. E N G...
3. When you hear your language, press and hold the Multi-function button V to select. DISABLE VOICE PROMPTS To disable and re-enable voice prompts, use the Bose Connect app. NOTE: Disabling voice prompts doesn’t disable Google Assistant or Amazon Alexa. E N G...
CA RE A N D M A IN T E N AN CE STORE THE HEADSET The earcups rotate for easy, convenient storage. Place the headset flat into the case. 1. Rotate both earcups inward so they lay flat. Left earcup Right earcup 2.
• Wipe the outside surfaces with a soft, dry cloth. • Don’t allow moisture to get inside the earcups or the 2.5 mm port. REPLACEMENT PARTS AND ACCESSORIES Replacement parts and accessories can be ordered through Bose customer service. Visit: worldwide.Bose.com/Support/QC35gaming LIMITED WARRANTY The headset is covered by a limited warranty.
CA RE A N D M AI NTE N AN CE SERIAL NUMBER LOCATIONS The serial number is located beneath the right scrim in the back of the earcup. The scrim is the inner screen which covers and protects the components inside the earcup. To view the serial number, grab the scrim at the top edge and gently peel it away.
• Check the status lights (see page 40). • Make sure your mobile device supports Bluetooth connections (see page 34). • Download the Bose Connect app and run available software updates. • Move your device closer to the headset and away from any interference or obstructions.
Page 47
TR OUBL ES H O OTI N G PROBLEM WHAT TO DO Make sure the gaming microphone is secure (see page 18). Adjust the audio settings in your gaming system settings menu. Refer to your gaming system owner’s guide for more information. No sound while gaming If using the PC desktop controller: •...
Page 48
TR OUBL ES H O OTI N G PROBLEM WHAT TO DO Make sure the USB cable is correctly aligned with the port on the headset. Secure both ends of the USB cable. Headset won’t charge If the headset has been exposed to high or low temperatures, let the headset return to room temperature and then try charging again.
Page 49
Make sure the Action button is set to noise Action button doesn’t change the cancellation. noise cancelling mode Use the Bose Connect app to change the noise cancelling mode. Change the language of the voice prompts (see page 42). Voice prompt is set to...
Page 50
Lisez et conservez à portée de main toutes les consignes de sécurité et le mode d’emploi. Bose Corporation déclare que ce produit est conforme aux critères essentiels et autres dispositions de la directive 2014/53/UE et des autres directives européennes applicables. L’attestation complète de conformité...
Page 51
INSTRUC TI ON S I M P ORTA N T ES RE L ATI VE S À L A S É C UR I TÉ Certaines pièces présentent un risque de suffocation. Ne les laissez pas à la portée des enfants de moins de 3 ans. Ce produit contient des composants magnétiques.
Page 52
• Connectez l’appareil à une prise reliée à un circuit différent de celui auquel est branché le récepteur. • Consultez votre revendeur ou un technicien radio/TV expérimenté pour obtenir de l’aide. Toute modification non autorisée expressément par Bose Corporation est susceptible d’annuler le droit de l’utilisateur d’utiliser cet appareil.
Page 53
I N FOR M ATI ON S RÉ G L E ME N TAI R E S Mettez au rebut les piles usagées conformément aux réglementations locales. Ne les incinérez pas. Tableau des restrictions concernant les substances dangereuses en Chine Noms et quantités des substances ou éléments toxiques ou dangereux Substances ou éléments toxiques ou dangereux Chrome...
Page 54
Importateur pour Taïwan : Bose Taiwan Branch, 9F-A1, No. 10, Section 3, Minsheng East Road, Taipei City 104, Taïwan Numéro de téléphone : +886-2-2514 7676 Importateur pour le Mexique : Bose de México, S. de R.L. de C.V., Paseo de las Palmas 405-204, Lomas de Chapultepec, 11000 México, D.F. Numéro de téléphone : +5255 (5202) 3545 Plage de températures lors de la charge : 0° C à...
Page 55
Bose Connect. Pour recevoir des mises à jour de sécurité via l’application mobile, vous devez achever le processus de configuration du produit dans l’application Bose Connect. Si vous ne procédez pas ainsi, il vous incombe d’installer les mises à jour de sécurité que Bose met à votre disposition via btu.bose.com Amazon, Alexa et tous les logos associés sont des marques commerciales d’Amazon, Inc., ou de ses filiales.
Page 57
D ÉCLA R ATI ON S D E L I CE N C E “Work” shall mean the work of authorship, whether in Source or Object form, made available under the License, as indicated by a copyright notice that is included in or attached to the work (an example is provided in the Appendix below).
Page 59
SOMM AI RE CONTENU DE L’EMBALLAGE Composants livrés ......................14 CONFIGURATION DE L’APPLICATION BOSE CONNECT Téléchargement de l’application Bose Connect ..........15 PORT DES OREILLETTES Réglage du serre-tête ....................16 Orientation des touches ....................17 Microphone de jeu ......................18 Fixation du microphone ..................
Page 60
SOMM AI RE ASSISTANT VOCAL Options de l’assistant vocal ..................27 Configuration de votre assistant vocal ..............27 Accès à l’Assistant Google ..................28 Actions possibles ....................29 Accès à Amazon Alexa ....................30 Actions possibles ....................31 Accès au guide vocal sur votre périphérique mobile ........32 RÉDUCTION DES BRUITS AMBIANTS Modes de réduction des bruits ambiants ..............
Page 61
SOMM AI RE BATTERIE Charge du casque ......................39 Temps de charge ..................... 39 Annonce du niveau de la batterie ..............39 ÉTAT DU CASQUE État Bluetooth ........................40 État de la batterie ......................41 GUIDE VOCAL Langues disponibles ...................... 42 Modification de la langue ....................
Microphone de jeu Contrôleur de bureau PC Câble de charge Câble audio 3,5 mm à 2,5 mm REMARQUE : si l’un des composants est endommagé, évitez de l’utiliser. Contactez immédiatement votre revendeur Bose agréé ou le service client de Bose. Rendez-vous sur worldwide.Bose.com/Support/QC35gaming F R A...
CON F I G U R ATI ON D E L’A P P L I CAT I O N BOS E CO N NE C T L’application Bose Connect vous permet de configurer et de contrôler le casque à partir de votre périphérique mobile, notamment votre smartphone ou tablette.
P ORT D ES O RE I L L ET TE S RÉGLAGE DU SERRE-TÊTE Avant de porter le casque, réglez le serre-tête de façon à le centrer au-dessus de votre tête. Le serre-tête doit reposer délicatement sur votre tête. F R A...
PORT D ES O R E I L L ET TE S ORIENTATION DES TOUCHES Les canevas internes (protections en tissu) des écouteurs du casque portent la marque L (écouteur gauche) et R (écouteur droit). L’écouteur droit dispose de trois touches et l’écouteur gauche d’une touche.
Pour communiquer avec vos amis ou votre équipe pendant une partie, fixez le microphone de jeu à votre casque. REMARQUE : une fois le microphone de jeu raccordé, la connexion Bluetooth est désactivée et l’application Bose Connect ne peut pas détecter votre casque. Fixation du microphone 1.
PORT D ES O R E I L L ET TE S Réglage du microphone Le positionnement du microphone est un facteur important pour garantir la clarté des communications. Saisissez le microphone de jeu et réglez-le de façon à le placer face à votre bouche sans qu’il touche vos lèvres.
Le mode de veille permet d’économiser la batterie du casque lorsque celui-ci n’est pas utilisé. Pour configurer et personnaliser la minuterie de mise en veille, utilisez l’application Bose Connect. MISE HORS TENSION Déplacez le bouton I vers la gauche. REMARQUE : lorsque le casque est hors tension, la fonction de réduction des bruits ambiants est désactivée.
COM M A N D E S D U CASQ UE Les touches de commande du casque se trouvent sous l’écouteur droit. REMARQUE : les touches sont désactivées lorsque vous connectez le microphone de jeu. LECTURE MULTIMÉDIA ET VOLUME Augmentation du volume Touche multifonctions Réduction du volume FONCTION...
COM M A N D E S D U CAS Q UE APPELS TÉLÉPHONIQUES La touche multifonctions V et le microphone sont situés sur l’écouteur droit. Microphone Touche multifonctions FONCTION PROCÉDURE À SUIVRE Répondre/mettre fin à un appel Appuyez sur la touche multifonctions V. Refuser un appel Appuyez sur la touche V pendant 1 seconde.
COM M A N D E S D U CAS Q UE FONCTIONS DE LA TOUCHE ACTION La touche Action est une touche programmable qui vous permet d’accéder rapidement et facilement à l’Assistant Google, à Amazon Alexa ou à la fonction de réduction des bruits ambiants.
COM M A N D E S D U CAS Q UE COMMANDES DE JEU Activation de la fonction de réduction des bruits ambiants 1. Connectez le microphone de jeu au casque (reportez-vous à la page 18). 2. Sur l’écouteur droit, déplacez le bouton d’alimentation/Bluetooth I vers la droite. REMARQUE : vous pouvez utiliser le casque pour les jeux même lorsque la fonction de réduction des bruits ambiants est désactivée.
COM M A N D E S D U CAS Q UE Contrôleur de bureau PC Utilisez le contrôleur de bureau PC pour régler le volume et activer la capture micro pendant une partie. REMARQUE : pour les utilisateurs de PC uniquement. Branchement du contrôleur de bureau PC à votre PC 1.
Page 74
COM M A N D E S D U CAS Q UE Capture micro La fonction Capture micro vous permet de régler l’intensité de votre propre voix lorsque vous utilisez le casque. 1. Appuyez sur la touche du contrôleur pour activer la capture micro. 2.
ASSI STA NT VO CAL OPTIONS DE L’ASSISTANT VOCAL Vous pouvez configurer le casque de façon à accéder rapidement et facilement à l’Assistant Google, à Amazon Alexa ou aux commandes vocales de votre périphérique mobile. REMARQUES : • Vous ne pouvez pas configurer le casque pour accéder simultanément à l’Assistant Google et à...
ASSI STA NT VO CAL ACCÈS À L’ASSISTANT GOOGLE Optimisé pour l’Assistant Google, votre casque constitue le compagnon de voyage idéal. Poursuivez vos conversations lorsque vous êtes en déplacement et accédez facilement aux principales fonctions de Google, notamment Google Play Music et Google Maps.
ASSI STA NT VO CAL Actions possibles Appuyez sur la touche Action, puis prononcez les phrases suivantes : OPÉRATION ACTIONS Utiliser les fonctions de divertissement Mets de la musique Envoyer un texto à maman « j’arrive dans Rester en contact cinq minutes ». Obtenir des réponses Quel temps va-t-il faire ce week-end ? Programmer votre journée Quel est mon planning aujourd’hui ?
ASSI STA NT VO CAL ACCÈS À AMAZON ALEXA Le casque est compatible avec Amazon Alexa. Vous pouvez demander à Alexa de rechercher des pistes musicales et des stations d’informations spécifiques, de consulter les prévisions météorologiques, de contrôler les systèmes automatisés de votre logement, etc.
ASSI STA NT VO CAL Actions possibles Appuyez sur la touche Action, puis prononcez les phrases suivantes : OPÉRATION ACTIONS Parler à Alexa Que peux-tu faire ? Mets du rock. REMARQUE : Amazon Music est configuré comme service Écouter de la musique musical par défaut. Pour le service par défaut, utilisez l’application Alexa.
ASSI STA NT VO CAL ASSI STA NT VO CAL ACCÈS AU GUIDE VOCAL SUR VOTRE PÉRIPHÉRIQUE MOBILE Vous pouvez utiliser la touche multifonctions V de votre casque pour accéder aux commandes vocales natives de votre périphérique mobile. Pour accéder aux commandes vocales du périphérique mobile, appuyez sur la touche V pendant 1 seconde.
élevé. CONFIGURATION DE LA TOUCHE ACTION SUR LA RÉDUCTION DES BRUITS AMBIANTS 1. Dans l’application Bose Connect, appuyez sur l’icône d’engrenage pour accéder aux paramètres de la touche Action. 2. Sélectionnez Réduction des bruits ambiants.
écouter de la musique sur plusieurs périphériques mobiles en même temps. REMARQUES : • Pour une meilleure expérience, utilisez l’application Bose Connect pour configurer et connecter votre périphérique mobile (consultez la page 15). • Une fois le microphone de jeu raccordé, la connexion Bluetooth est désactivée et l’application Bose Connect ne peut pas détecter votre casque.
3. Sélectionnez votre casque dans la liste des périphériques. REMARQUE : recherchez le nom que vous avez indiqué pour votre casque dans l’application Bose Connect. Si vous n’avez pas donné un nom à votre casque, le nom par défaut apparaît. Bose QuietComfort 35 II Gaming Headset Une fois la connexion terminée, vous entendez le message « Connecté...
CON N EXI ONS B LU E TO OT H DÉCONNEXION D’UN PÉRIPHÉRIQUE MOBILE Utilisez l’application Bose Connect pour déconnecter votre périphérique mobile. CONSEIL : vous pouvez également utiliser les réglages Bluetooth pour déconnecter votre périphérique. La désactivation de la fonction Bluetooth déconnecte tous les autres périphériques.
CON N EXI ONS B LU E TO OT H EFFACEMENT DE LA LISTE DES PÉRIPHÉRIQUES DU CASQUE 1. Déplacez le bouton Alimentation/Bluetooth I vers la droite et maintenez-le dans cette position pendant 10 secondes jusqu’à ce que vous entendiez l’indication « Liste des périphériques Bluetooth effacée ». REMARQUE : si vous ne portez pas le casque, déplacez le bouton I vers la droite et maintenez-la dans cette position pendant 10 secondes jusqu’à...
CON N EXI O NS CÂB L É E S RACCORDEMENT DU CÂBLE AUDIO Utilisez le câble audio pour raccorder un appareil filaire ou lorsque la batterie du casque est épuisée. 1. Branchez le câble au connecteur 2,5 mm de l’écouteur gauche. 2.
BAT TE R IE CHARGE DU CASQUE 1. Raccordez le petit connecteur du câble USB à la prise micro-USB de l’écouteur droit. 2. Raccordez l’autre extrémité à un chargeur mural USB. Le voyant de la batterie clignote en orange. Une fois la batterie complètement chargée, le voyant de la batterie s’allume en vert (consultez la page 41).
ÉTAT D U CAS Q U E ÉTAT BLUETOOTH Le voyant Bluetooth, qui se trouve sur l’écouteur droit, indique l’état de connexion des périphériques mobiles. Voyant Bluetooth ACTIVITÉ DU VOYANT ÉTAT DU SYSTÈME Bleu clignotant Prêt pour la connexion Blanc clignotant Connexion en cours Reste allumé...
Charge faible Rouge clignotant Charge nécessaire Reste allumée en rouge Erreur de charge. Contactez le service client de Bose. CONSEIL : vous pouvez également consulter le niveau de la batterie du casque à l’aide de l’application Bose Connect. F R A...
3. Lorsque vous entendez votre langue, appuyez sur la touche multifonctions V et maintenez-la enfoncée pour la sélectionner. DÉSACTIVATION DU GUIDE VOCAL Pour désactiver et réactiver le guide vocal, utilisez l’application Bose Connect. REMARQUE : la désactivation du guide vocal ne désactive par l’Assistant Google ou Amazon Alexa.
EN T R ET I E N RANGEMENT DU CASQUE Les écouteurs pivotent pour permettre un rangement à la fois simple et pratique. Placez le casque à plat dans l’étui. 1. Faites pivoter les deux écouteurs vers l’intérieur pour les mettre à plat. Écouteur gauche Écouteur droit 2.
Le casque est couvert par une garantie limitée. Consultez notre site Web à l’adresse global.Bose.com/warranty pour en savoir plus sur la garantie limitée. Pour enregistrer votre produit, accédez à la page global.Bose.com/register. En cas d’oubli, les droits que vous confère cette garantie limitée ne s’en trouveront pas affectés.
E N T R ET I E N EMPLACEMENTS DU NUMÉRO DE SÉRIE Le numéro de série se trouve sous la grille droite à l’arrière de l’écouteur. La grille est l’écran interne qui couvre et protège les composants à l’intérieur de l’écouteur. Pour voir le numéro de série, saisissez la grille par le bord supérieur et retirez-la délicatement.
Si vous ne parvenez pas à résoudre votre problème, consultez le tableau ci-dessous pour identifier les symptômes et trouver des solutions aux problèmes courants. Si vous ne parvenez toujours pas à résoudre le problème, contactez le service client de Bose. Rendez-vous sur worldwide.Bose.com/Contact PROBLÈME...
Page 95
RÉSOLU TION D E S P R O B L È M E S PROBLÈME PROCÉDURE À SUIVRE Vérifiez que le microphone de jeu est correctement connecté (reportez-vous à la page 18). Modifiez les paramètres audio dans le menu de configuration de votre système de jeu.
Page 96
RÉSOLU TION D E S P R O B L È M E S PROBLÈME PROCÉDURE À SUIVRE Vérifiez que le câble USB est correctement aligné au connecteur sur le casque. Vérifiez que le câble USB est correctement connecté aux deux extrémités.
Page 97
Utilisez l’application Bose Connect pour modifier le mode de réduction des bruits ambiants. Modifiez la langue du guide vocal (consultez la page 42). Le guide vocal est réglé...
Page 102
欧洲进口商:Bose Products B.V., Gorslaan 60, 1441 RG Purmerend, The Netherlands 台湾进口商:Bose 台湾分公司,台湾 104 台北市民生东路三段 10 号,9F-A1, 电话:+886-2-2514 7676 墨西哥进口商:Bose de México, S. de R.L. de C.V., Paseo de las Palmas 405-204, Lomas de Chapultepec, 11000 México, D.F. 电话:+5255 (5202) 3545 充电温度范围:0° C – 45° C 放电温度范围:-20°...
Page 105
许 可 披 露 “Work” shall mean the work of authorship, whether in Source or Object form, made available under the License, as indicated by a copyright notice that is included in or attached to the work (an example is provided in the Appendix below).
BOSE CON NE C T 应 用 设 置 您可在任何移动设备(例如智能手机或平板)上通过 Bose Connect 应用设置和控制 耳机。 您可以使用此应用选择自己的语音提示语言、管理耳机设置和通过更新获得新功能。 注意: 连接游戏麦克风后, Bluetooth 将被禁用,Bose Connect 应用将无法查找您的 耳机。 下载 BOSE CONNECT 应用 1. 在移动设备上,下载 Bose Connect 应用。 B O S E C O N N E C T 2.
耳 机 控 件 PC 桌面控制器 使用 PC 桌面控制器可以在游戏时调节音量和打开麦克风监控。 注意: 仅用于 PC 用户。 将 PC 桌面控制器连接至 PC 1. 将 PC 桌面控制器连接至 PC 的 USB 端口。 2. 将游戏麦克风连接线连接至 PC 桌面控制器的端口。 调节音量 控件 操作方法 提高音量 将控制器向右旋转(顺时针) 。 降低音量 将控制器向左旋转(逆时针) 。 S C H...
Page 122
耳 机 控 件 麦克风监控 麦克风监控可以控制使用耳机时听到自己的声音的音量。 1. 按下控制器上的按钮可以打开麦克风监控。 2. 在低、中、高和关闭之间重复循环选择。 注意: 如要快速关闭麦克风监控,请按住控制器上的按钮。 S C H...
语 音 助 手 访问 GOOGLE ASSISTANT 您的耳机已针对 Google Assistant 进行了优化,因此耳机将成为您旅行或通勤时帮 您完成任务的完美伴侣。在旅途中继续您的对话,轻松访问 Google 内容,无论是 Google Play Music 还是 Google Maps 上的内容。您可以享受休闲娱乐活动、与朋友 保持联系、获取信息和管理当天事项 —— 所有这些均无需翻找手机。收听您喜欢的 歌曲,读出您的通知和信息,或者设置提醒和计时器。只需按住“操作”按钮就可 以和 Google Assistant 进行对话。 关于 Google Assistant 功能的更多信息,请访问: https://support.google.com/headphones 注意: 某些语言和国家/地区无法使用 Google Assistant。 使用左侧耳罩上“操作”按钮来控制 Google Assistant。 尝试方式...
语 音 助 手 尝试方式 按住“操作”按钮,然后说: 操作 语音示例 Play some music 享受娱乐 Text mom“see you in 5” 保持联系 What’ s the weather this weekend? 获取答案 Tell me about my day 管理行程 S C H...
语 音 助 手 尝试方式 按住“操作”按钮,然后说: 操作 语音示例 对 Alexa 说话 What can you do ? Play rock music。 播放音频 注意: Amazon Music 被设置为默认音乐服务。 要更改默认音乐服务,请使用 Alexa 应用。 Pause。 暂停音频 Volume up。 控制音量 Skip。 跳到下一首歌 How’ s my day looking? 制定行程 Remind me to “feed Jack’...
耳机的设备列表中最多可存储八台设备,并且耳机一次可以主动连接两台设备。 一次只能播放一台设备的音频。 注意: • 为了获得最佳体验,使用 Bose Connect 应用设置并连接移动设备(请参见第 15 页) 。 • 连接游戏麦克风后, Bluetooth 将被禁用, Bose Connect 应用将无法查找您的耳机。 1. 将“电源/ Bluetooth ”按钮 I 滑到右侧并按住,直至听到“Ready to connect another device.” (准备就绪,可以连接其他设备。 ) 注意: 如果您未佩戴耳机,请将 I 滑到右侧并按住,直至 Bluetooth 指示灯闪蓝灯。 2. 启用设备上的 Bluetooth 功能。...
BLUETOOTH 连 接 清空耳机的设备列表 1. 将电源/ Bluetooth 开关 I 滑至右侧并按住 10 秒,直到听到“ Bluetooth device list cleared” ( Bluetooth 设备列表已清空) 。 注意: 如果您未佩戴耳机,请将 I 滑到右侧并按住 10 秒,直至 Bluetooth 指示灯 闪烁蓝色光。 2. 从您设备的 Bluetooth 列表中删除耳机。 所有设备将被清除,并且耳机可开始连接。 S C H...
Page 150
歐盟進口商:Bose Products B.V., Gorslaan 60, 1441 RG Purmerend, The Netherlands 台灣進口商:Bose 台灣分公司,台灣 104 台北市民生東路三段 10 號,9F-A1 電話:+886-2-2514 7676 墨西哥進口商:Bose de México, S. de R.L. de C.V., Paseo de las Palmas 405-204, Lomas de Chapultepec, 11000 México, D.F. 電話:+5255 (5202) 3545 充電溫度範圍:0° C – 45° C 放電溫度範圍:-20°...
Page 153
授 權 揭 露 “Work” shall mean the work of authorship, whether in Source or Object form, made available under the License, as indicated by a copyright notice that is included in or attached to the work (an example is provided in the Appendix below).
BOSE CON N EC T 應 用 程 式 設 定 您可在任何行動裝置(例如智慧型手機或平板電腦)上透過 Bose Connect 應用程式 設定和控制耳機。 您可以使用此應用程式選擇自己的語音提示語言、管理耳機設定和透過更新取得新 功能。 注意: 連接遊戲專用麥克風後, Bluetooth 會停用,並且 Bose Connect 應用程式找 不到您的耳機。 下載 BOSE CONNECT 應用程式 1. 在行動裝置上,下載 Bose Connect 應用程式。 B O S E C O N N E C T 2.
如 何 佩 戴 按鈕方位 耳機的內基布(布罩)上標有 L (左耳罩)和 R (右耳罩) 。右耳罩上有三個按鈕, 左耳罩上有一個按鈕。 右耳罩與右耳符合,左耳罩與左耳符合。將耳機放在頭上,讓按鈕面向您背後, 並調整每個耳罩,讓墊子完全蓋著耳朵。耳機戴在頭上後,用拇指按下按鈕。 注意: 按鈕會在連接遊戲專用麥克風時停用。 T C H...
語 音 助 理 存取 GOOGLE ASSISTANT 您的耳機已針對 Google Assistant 進行了最佳化,因此耳機將成為您旅行或通勤時 幫您完成任務的完美夥伴。在旅途中繼續您的對話,輕鬆存取 Google 內容,無論是 Google Play Music 還是 Google Maps 上的內容。享受休閒娛樂活動、與朋友保持聯 絡、獲取資訊和管理當天事項 —— 所有這些均無需翻找手機即可完成。收聽您喜歡 的歌曲,讀出您的通知和資訊,或者設定提醒和計時器。只需按住「動作」按鈕就 可以和 Google Assistant 進行對話。 如需 Google Assistant 功能的更多資訊,請造訪: https://support.google.com/headphones 注意: 某些語言和國家/地區無法使用 Google Assistant。 使用左耳罩上的「動作」按鈕來控制 Google Assistant。 嘗試方式...
語 音 助 理 嘗試方式 按下「動作」按鈕,然後說: 動作 語音範例 Play some music 享受娛樂 Text mom “see you in 5” 保持聯繫 What’ s the weather this weekend? 獲取答案 Tell me about my day 管理日程 T C H...
BLUETOOTH 連 接 清空耳機裝置清單 1. 將「電源/ Bluetooth 」開關 I 滑動至右側並按住 10 秒,直至聽到「 Bluetooth device list cleared( Bluetooth 裝置清單已清空) 」 。 注意: 如果沒有佩戴耳機,將 I 滑動至右側並按住 10 秒,直至 Bluetooth 指示 燈閃爍藍色光。 2. 從裝置上的 Bluetooth 清單中刪除耳機。 所有裝置已被刪除,耳機可開始連接。 T C H...
• 荷蘭文 • 法文 • 日文 • 葡萄牙文 變更語言 1. 同時按住 H 和 z 直到聽到語音提示選取喜好語言。 2. 按下 H 或 z 瀏覽語言清單。 3. 當聽到您的語言時,按住多功能按鈕 V 進行選擇。 停用語音提示 使用 Bose Connect 應用程式來停用和重新啟用語音提示。 注意: 停用語音提示不會停用 Google Assistant 或 Amazon Alexa。 T C H...
