- Page 1 Mobile welding fume extractor MOBILEPRO | MOBILEPRO-W3 Installation and user manual www.plymovent.com...
-
Page 2: Table Of Contents
Thus the manufacturer cannot be held responsible for any damage resulting from the application of this publication to the version actually delivered to you. This publication has been written with great care. However, the manufacturer cannot be held responsible, either for any errors occurring in this publication or for their consequences. 0000104750/140220/D MobilePro | MobilePro-W3... -
Page 3: Preface
General description Pictograms and symbols The MobilePro is a mobile filter unit with integrated fan that The following pictograms and symbols are used in this manual: provides extraction and filtration for use with an extraction arm. -
Page 4: Product Description
KUA-160/3S EA-3/S extraction arm) KUA-160/4S EA-4/S Fan speed: - 50 Hz - 2900 rpm MobilePro with extraction arm - 60 Hz - 3390 rpm Noise level 72 dB(A) according to ISO 3746 Ambient conditions Electrical data Power consumption 1,1 kW (1.5 HP) -
Page 5: Safety
- Children must be supervised not to play with the product. Operation Intended use The MobilePro works in accordance with the recirculation principle. Welding fume is extracted through the hood of the The product has been designed exclusively for extracting and connected extraction arm by the built-in fan. -
Page 6: Installation
Service, maintenance and repairs Extraction arm - Obey the maintenance intervals given in this manual. To operate the MobilePro you must install one of the following Overdue maintenance can lead to high costs for repair and extraction arms: revisions and can render the guarantee null and void. - Page 7 Put a cable gland in both holes. • Put the cable (A) through the cable glands. • Tighten the cable glands. The dashed line indicates the end position The nut is locked to the front panel, so you cannot entirely remove it 0000104750/140220/D MobilePro | MobilePro-W3...
-
Page 8: Use
Fire hazard! Do not use the product for polishing applications in combination with grinding, welding or any other application that generate sparks. Refer to chapter 3 / Use. Delay time: 10 minutes To activate: push and hold 5 seconds 0000104750/140220/D MobilePro | MobilePro-W3... -
Page 9: Maintenance
Put the dust tray back in the holder and lock it. The optimum frequency to activate the cleaning system manually depends on the intensity of use and will be a matter of experience. During the ALARM stage the fan continues to run. 0000104750/140220/D MobilePro | MobilePro-W3... -
Page 10: Troubleshooting
11. You must replace the filter cartridge immediately when it is damaged or when the ALARM light remains on during use, which indicates that the filter cartridge 10. Sticker “UP” indicates the top of the cover plate. is clogged. 0000104750/140220/D MobilePro | MobilePro-W3... -
Page 11: Spare Parts
CE declaration of conformity for machinery the facility ripped or cartridge or place it placed correctly incorrectly We, Plymovent Manufacturing B.V., Koraalstraat 9, 1812 RK Alkmaar, Netherlands, herewith declare, on No filter Loose Repair the our own responsibility, that the products: cleaning... - Page 12 ANNEX Fig. I Instructions to take the unit from the pallet Fig. II Positioning of the extraction arm ±20° ±20° ±20° 400-800 mm 400-800 mm (16-32 in.) (16-32 in.) ±20° ±20° ±20° 0000104750/140220/D MobilePro | MobilePro-W3...
- Page 13 ANNEX Fig. III Exploded view 0000117137 0000103068 0000104069 0000101751 0000101752 0000110155 0000102598 0000102762 0000102584 0805040010 0000101364 0805030010 0040900010 0000102411 0000104961 0000104768 0040900120 0040900130 0040900220 0000101413 0000101440 0000112145 0000101444 0000101409 0000104750/140220/D MobilePro | MobilePro-W3...
- Page 14 Lock kit for CART filter cartridge 0000102598 Star knob M12 0000102762 Cover plate for filter cartridge 0000104768 Indicator light red 0000104961 PC board MobilePro, incl. software 0000110155 CART-O/PTFE / Filter cartridge [MobilePro-W3 only] 0000112145 Pressure switch 1425 Pa 0040900010 Magnetic valve AC...
- Page 15 0000104750/140220/D MobilePro | MobilePro-W3 www.plymovent.com...
