1
CHARGING PROCEDURE
1. CHARGING YOUR BATTERY PACK
Connect the battery charger to the power supply and
the indicator light should turn to green. Then, slide the
charger base on the battery pack to make connections
and the indicator light will turn red to show that the
charging has started. It will remain red until the battery
is fully charged.
2
INSTALLING THE BATTERY PACK
2. TO INSTALL THE BATTERY PACK
After recharging, insert the battery pack into the
battery port. A simple push and
slight pressure will be sufficient until a click is heard.
Check to see if the battery is fully secured.
20
HT19-401-003-22
VOLT
Cordless Sprayer
3
BEFORE PUTTING INTO OPERATION
2
1
3. CONNECTING THE LANCE TO THE HANDLE
1) Insert the lance into the handle as shown.
2) Thread the cap onto the handle and tighten
securely.
MAX
2
1
