Summary of Contents for Smartwares DIC-22815
- Page 1 DIC-22815 / DIC-22805...
- Page 2 Table of Contents English ........................
-
Page 3: Installation Safety
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. 5. The adapter must match the outlet. Never modify the plug in any way. Unmodified plugs and matching outlets will reduce risk of electric shock. DIC-22815 _ DIC-22805... -
Page 4: Parts Description
2.2 Product overview 2.2.1 Indoor monitor 1. Indoor monitor unit 2. Power on/off 3. Power indicator 4. Charging indicator 5. Control panel 6. Microphone 11. Adapter 2.2.2 Doorbell 7. Microphone 8. Night sensor 9. Outdoor camera 10. Call button DIC-22815 _ DIC-22805... -
Page 5: Installation
Smartwares Installation | 3 3 Installation 3.1 Doorbell installation When installing the outdoor unit, make sure that the location of installation is dry. It is important that the electronics do not get wet. DIC-22815 _ DIC-22805... - Page 6 – If the outdoor unit does not have an external power supply the battery can be re- moved to charge it manually. (Picture 8) 1. Charging LED 2. Charging interface – The battery box can be opened to replace damaged or non-working batteries. (Pic- ture 8) DIC-22815 _ DIC-22805...
-
Page 7: Monitor Installation
Smartwares Installation | 3 3.2 Monitor installation DIC-22815 _ DIC-22805... -
Page 8: Control Buttons
4.1.1 Use of the control buttons – Button to communicate: – Button to monitor: Note: The monitor function is not available when the doorbell is operated by battery, it is only available when the power adapter is connected. DIC-22815 _ DIC-22805... - Page 9 Use | 4 – Opening the door (with electric door opener): Note: An electric door opener (12V, 500mA) is not included, our items DB5005 or DB5005L can be used, they are separately available. – Opening the gate: DIC-22815 _ DIC-22805...
-
Page 10: Screen Icons
Press the ok/menu button to select the highlighted submenu. 1. Camera pairing 2. Image setting 3. Volume control 4. Music setting 5. Play back 6. Rec/snap 7. Time setting 8. Unlock time setting 9. Exit DIC-22815 _ DIC-22805... - Page 11 – The image of the camera will be shown on the display if pairing is successful. 4.3.1.2 Additional monitor (DIC-22805) There can be an extra monitor (DIC-22805, separately available) connected to the sys- tem. To link this to the system, follow the steps below: DIC-22815 _ DIC-22805...
-
Page 12: Image Setting
Color setting – Press left or right to select the color setting. – Press ok button to confirm. – Then press left or right to adjust the color level. – Press ok button to confirm and exit. DIC-22815 _ DIC-22805... -
Page 13: Volume Control
– When pressing the ok button on a selected folder or file a submenu of the delete option will pop-up. – Select yes or no with the left or right button. – When yes is selected and after confirmation with the ok button, the file or folder will be deleted. DIC-22815 _ DIC-22805... -
Page 14: Unlock Time Setting
– Press direction buttons to select the unlock time icon ,press ok button to get into the submenu. – Use the left and right button to select between 100mS, 1S, 5S or 10S. – Confirm and exit by pressing the ok button. DIC-22815 _ DIC-22805... - Page 15 Smartwares Use | 4 4.3.9 Exit – Use the exit icon to go back one step in the menu or leave the menu completely to the monitor mode. DIC-22815 _ DIC-22805...
-
Page 16: Cleaning And Maintenance
– Do not use any carboxylic cleaning agents or petrol, alcohol or similar. These at- tack the surfaces of the devices. Besides, the vapors are hazardous to your health and explosive. Do not use any sharp edged tools, screw drivers, metal brushes or similar for cleaning. DIC-22815 _ DIC-22805... -
Page 17: Technical Data
DC/AC 8~24V (battery: 3.7V/2000mAH 18650) Consumption current 300±50mA Screen size 4,3 inch (diagonal) Resolution 480x272(RGB) Supply voltage DC 5V/1A (battery: 3.7V/1500mAH) Indoor monitor Consumption current 350±50mA Charging time <2 hours Image format JPEG Video format SD card SDHC 2GB-32GB DIC-22815 _ DIC-22805... - Page 18 Ask your local authorities for information re- garding the point of recollection. Support You can find all available information and spare parts at www.smartwares.eu Please read manual before use, and store it carefully for future use and maintenance. DIC-22815 _ DIC-22805...
-
Page 19: Declaration Of Conformity
Declaration of Conformity | 8 8 Declaration of Conformity Hereby, Smartwares Europe declares that the radio equipment type DIC-22815 is in compliance with Directive 2014/53/EU The full text of the EU declaration of conformity is available at the following internet address: www.smartwares.eu/doc...
