Simba X-PRESS Operator's Manual & Parts List page 147

AS2972
ITEM PART NO DESCRIPTION
P02007 NUT LOCK M12
1
P02035 WASHER SPRING M10
2
P02601 WASHER FLAT M12
3
P03087 BOLT M12x50 GR. 8.8
4
P03112 BOLT M12x150 GR. 8.8
5
P12690 BOLT M10x30 GR. 8.8
6
P13248 BRAKE CHAMBER OIL/AIR
7
P13733 BLANKING CAP 3/8"
8
P14540 DUST CAP
9
P14544 AIR HOSE FITTING M22
10
P14547 AIR HOSE FITTING M22
11
P15189 BRAKED AXLE 6 STUD
12
P15214 RELAY-EMERGENCY VALVE
13
P15495 RETAINING PLATE
14
P15503 BLANKING PLUG - M16
15
P15506 STR FITTING - M16
16
P15508 CHAMBER MOUNT LH
17
P15513 CHAMBER MOUNT RH
18
P15533 M/F REDUCER - M22-M16
19
P15540 TEST POINT M16
20
P15542 FLEXI AIR HOSE - 1000mm
21
P15543 FLEXI AIR HOSE - 500mm
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
BRAKED AXLE ASSEMBLY - AIR
7. Parts and Assembly
QTY COMMENTS
8
2
16
8
8
2
2
2
1
1
1
1
1
2
4
1
1
1
2
1
1
1
X-Press
Operating Instructions
147
