IV. ELECTRIC DIAGRAM
(For PKCWC120, PKCWC150, PKCWC180, PKCWC12, PKCWC15, PKCWC18 only)
(For PKCWCDS188, PKCWCDS185 only)
(For PKCWC240, PKCWC24 only)
8
www.NutrichefKitchen.com
DISPLAY
PLUG
Control board
YE/GN
NTC1 NTC2 electromagnetic
DISPLAY 1
PLUG
Control board
YE/GN
FAN1
LED1
LED2
LED1
LED2
FAN1
FAN2
PTC
STARTER
θ
Valve
COMPRESSOR
DISPLAY 2
FAN2
θ
θ
NTC1
NTC1
electromagnetic
Valve
OVERLOAD
PROTECTOR
PTC
STARTER
OVERLOAD
PROTECTOR
θ
YE/GN
COMPRESSOR
