INSTALLING THE STAINLESS STEEL HANDLE

INSTALLING THE STAINLESS STEEL HANDLE
For PKCWC12, PKCWC15 Models only For PKCWC12, PKCWC15 Models only
This wine cellar includes a stainless steel handle. To install the handle please follow the below instructions: This wine cellar includes a stainless steel handle. To install the handle please follow the below instructions:
1. Pull away the door gasket in the area where the handle is to be installed on the left side as shown below 1. Pull away the door gasket in the area where the handle is to be installed on the left side as shown below
in illustration #1. The gasket can easily displaced by hand, no tools are necessary. in illustration #1. The gasket can easily displaced by hand, no tools are necessary.
2. Align the handle with the screws installed. Tighten the screws using a Phillips head screwdriver until the 2. Align the handle with the screws installed. Tighten the screws using a Phillips head screwdriver until the
(DO NOT over tighten as this will cause damage to the handle assembly). (DO NOT over tighten as this will cause damage to the handle assembly).
3. Replace the door gasket to its original position. 3. Replace the door gasket to its original position.
1. Gasket
3. Phillips Head Screw
2. Phillips Head Screw Driver
4. Handle
www.NutrichefKitchen.com
