- Page 1 AC7870 4K HDMI extender set...
-
Page 2: Table Of Contents
5.0 Warning and points of attention ................6 6.0 Warranty conditions ....................7 1.0 Introduction Congratulations with the purchase of this high-quality ACT product! This product has undergone extensive testing by ACT’s technical experts. Should you experience any problems with this product, you are covered by ACT warranty. -
Page 3: Panel Descriptions
ENGLISH 2.0 Panel descriptions Front Panel Transmitter unit RJ45 Green LED = CAT5e linked RJ45 Yellow LED = Data transmission Back panel Transmitter unit Link Green LED = Power on/off Link Blue LED = TX/RX linked Power DC 5.0V 2.0A... - Page 4 ENGLISH Front panel Receiver unit EDID Function Press and hold 2 Copy receiver monitor EDID to transmitter. seconds RJ45 Green LED = CAT5e linked RJ45 Yellow LED = Data transmission Back panel Receiver unit Link Green LED = Power on/off Link Blue LED = TX/RX linked Power...
-
Page 5: Installation Diagram
ENGLISH 3.0 Installation diagram: Please note that the ( chainable ) receiver unit cannot work standalone and always need the transmitter unit. Point to Point application One to Multiple Display application By Daisy chain ( AC7871 chainable receiver sold seperately) -
Page 6: Technical Specifications
460g ( transmitter + receiver ) 5.0 Service and support This user manual has been carefully written by ACT’s technical experts. If you have problems installing or using the product, please fill out the support form at the website https://support.act-connectivity.com/ 6.0 Warning and points of attention... -
Page 7: Warranty Conditions
A power socket is needed which should be close and easy accessible from the device. Repairing of the device should be done by qualified ACT staff. Never try to repair the device yourself. The warranty immediately voids when products have undergone self- repair and/or by misuse. - Page 8 ACT warranty. Products are not covered by the ACT warranty when exposed to incorrect/improper use, external influences or when opening the service parts of the product by parties other than ACT. ACT may use refurbished materials for repair or replacement of your defective product. ACT cannot be held responsible for changes in network settings by internet providers.
