GE Monogram ZGP484NGRSS Dimensions And Installation Information page 2

ZGP484NGRSS (Natural Gas)
ZGP484LGRSS (Liquid Propane)
GE Monogram
and Griddle
Dimensions and Installation Information (in inches)
Electrical Requirements
Ranges must be hooked up to a 120V, 60Hz properly
grounded dedicated circuit protected by a 15-amp circuit
breaker or time-delay fuse.
Universal Utility Locations
Universal Utility Locations
23"
Gas/
6-1/2"
Electric
Locate gas and
electric as shown
Gas Supply
• The natural gas models are designed to
operate at 5" water column pressure.
For proper operation, the pressure of
the natural gas supplied to the regulator
must be between 7" and 13" water
column.
• The LP models are designed to operate
at 10" water column pressure. For
proper operation, the pressure of the LP
gas supplied to the regulator must be
between 11" and 13" water column.
For answers to your Monogram,
GE appliance questions, visit our website at
®
geappliances.com or call GE Answer Center
service, 800.626.2000.
48" All-Gas Professional Range with 4 Burners, Grill
®
8"
6"
Gas/
Electric
2"
3"
48"
GE Profile or
® ™
®
Optional Backsplash Accessories
The range requires a 12" minimum clearance to a vertical
combustible surface at the rear. A backsplash is required
for installations with less than 12" clearance. The following
backsplash accessories are available, or a custom, non-
combustible backsplash can be used.
Order one with a 48"-wide range backsplash
ZX12B48PSS–12" backsplash
ZXADJB48PSS– 30"-36" adjustable-height backsplash with
warming shelf
Side View with a Backsplash
10-1/2"
13/16"
12"
30-36"
Optional
Backsplash
Accessories
1-1/2"
35-1/4"
to
36-3/4"
to Front of
Specification Created 12/10
28-7/8"
to Front
Edge
3-3/16"
Control Panel
Depth
28-1/4" to
Beveled
Edge of Control
Panel Bullnose
27-1/2" to
Beveled Edge
- Maximum
Adjacent
Cabinet Depth
for
Flush
Installation
28-1/4"
31-1/16"
Door
to Front of
Handle
48-1/4"
with Oven Door
Open
Listed by
Underwriters
Laboratories
7" Control
Panel Height
