MOIXA Smart Battery Maintenance Manual

Hide thumbs Also See for Smart Battery:
Table of Contents

Advertisement

Quick Links

Moixa Smart Battery
Technical File part 03E:
Maintenance Manual
DC READY
, MOIXA
are registered trademarks, logos, illustrations are property of
®
®
Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
| 1
info@moixa.com
www.moixa.com
Moixa Technology Ltd,
One Fellmongers Path,
London SE1 3LY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Battery and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MOIXA Smart Battery

Summary of Contents for MOIXA Smart Battery

  • Page 1 Maintenance Manual info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 2 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 3 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 4 Moixa Smart Battery unit info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.

  • Page 5: Table Of Contents

    P.47 info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.

  • Page 6: 01 Tools Required

    Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 7 Replace the communications Dongle plugged into the USB socket of the Pi. Replace the cover and the battery modules. Turn on the Unit. For WiFi you will need to then set the Wifi password on the Moixa Smart Battery by logging in – as described in Section 03E.09...
  • Page 8 Male to female USB adapter info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 9 Pig tail info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 10 WIFI and 3G dongle is USB connected to the right side of the “PI” board info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 11 Connect the USB adapter and the 3G antenna info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.

  • Page 12: 03 Upgrade Unit From Wifi To Tp Link Connection

    03E.03 Upgrade unit from WiFi to TP link connection Description: We need to update an existing Moixa Smart Battery unit from using a WiFi con- nection to using a ethernet over power line connection to provide a more reliable data connection.
  • Page 13 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 14 14 | upgrade unit from wifi to tp link 3.If no mains socket is available imediately next to the Moixa Smart Battery, then add one on a new or existing circuit, this can be a spur. Plug in the TP link unit into the new socket and run the ethernet cable into the Moixa unit - you will need to remove the cover to do this as below.
  • Page 15 Locate the Ethernet port on the raspberry Pi. Remove the WiFi Dongle from the USB socket in the Pi. Tape it securely to the inside of the Moixa unit - incase WiFi is needed in the unit in future, or put in plastic bag and tape to the inside of the unit.
  • Page 16 Press submit on the Moixa app to send details of the job to the Moixa team. Example TP link diagram on following page.
  • Page 17 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.

  • Page 18: 04 Swap Sd Card In Moixa Smart Battery

    03E.04 Swap SD card in Moixa Smart Battery Description: We need to update the firmware on the Moixa Smart Battery system, and as it is offline we need to do this with a manual SD card swap. This will involve:...
  • Page 19 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 20 Check that the unit is online and reliably sending data. Ring Moixa technical team, report that work is complete and request that they login to the unit to check that it is working correctly. Press submit on the Moixa app to send details of the job to the Moixa team. info@moixa.com www.moixa.com...

  • Page 21: 05 Replace Battery Modules On Moixa Smart Battery Unit

    Press submit on the Moixa app to send details of the job to the Moixa team. Repack the old batteries in the packing from the new ones, apply the provided label and either drop at a UPS location or call the Moixa team to book a pickup. Timing: Approx 40 mins will be required for this work.
  • Page 22 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 23 Check that the unit is online and reliably sending data. Ring Moixa technical team, report that work is complete and request that they login to the unit to check that it is working correctly. Press submit on the Moixa app to send details of the job to the Moixa team. info@moixa.com www.moixa.com...

  • Page 24: 06 Recharge Battery Modules On Moixa Smart Battery Unit

    Press submit on the Moixa app to send details of the job to the Moixa team. Timing: Approx 1.5 hours will be required for this work.
  • Page 25 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 26 Press submit on the Moixa app to send details of the job to the Moixa team. info@moixa.com www.moixa.com...

  • Page 27: 07 Swap Moixa Smart Battery Unit For A Replacement

    03E.07 Swap Moixa Smart Battery unit for a replacement Description: The Moixa unit has a fault that cannot be fixed in the field, or that takes more time than is available to a field engineer to fix, and so the unit needs to be swapped for a replacement.
  • Page 28 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 29 Remove the cover from the rotary isolator, disconnect the Moixa unit from the terminals of the isolator, remove the screw holding back the base of the Moixa unit to the wall, loosen the two screws on which the Moixa unit hangs, remove the Moixa unit and put to one side info@moixa.com...
  • Page 30 Check that the unit is online and reliably sending data. Ring Moixa technical team, report that work is complete and request that they login to the unit to check that it is working correctly. Press submit on the Moixa app to send details of the job to the Moixa team. info@moixa.com www.moixa.com...
  • Page 31 Ring Moixa technical team and request that they login to the unit to be able to see the data live from the unit. Working with the Moixa team amend the location of the clamps until reliable data is being produced.

  • Page 32: 08 Check Non-Invasive Meter Locations

    Ring Moixa technical team and request that they login to the unit to be able to see the data live from the unit. Working with the Moixa team amend the location of the clamps until reliable data is being produced.
  • Page 33 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 34 Install type 2 info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 35 Install type 3 info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 36 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 37 Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 38 The unit should now connect to the Moixa serv- er and start sending data. Ring Moixa technical team and request that they login to the unit to be able to see the data live from the unit.
  • Page 39 3.Place the Moixa Smart Battery in AP (Access Point) mode. To do this press in the “BYPASS” switch using a pencil or other small object, do this very carefully as the switch is fragile.
  • Page 40 40 | connect battery to wifi Select the Moixa Wi-Fi network from your Wi-Fi network chooser. This will be in the format maslow-UnitSerialNo. When prompted for a password enter “MaslowPass”. Once your device has connected to the Moixa Smart Battery, open a web browser and navigate to the following page: http://10.74.8.254/...

  • Page 41: 10 Updating Sub-Pic

    Shut down the Maslow, Isolate the mains connection, remove the batteries, remove the cover Unplug the Pi from the mainboard. Power the Moixa unit from the battery ex- tender cable. Connect the PICKIT3 to the mainboard and program the PIC Replace the PI, cover, and battery unit and restart the Maslow –...
  • Page 42 MASLOW. info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 43 Remove Batteries carefully and place within reach (2x) info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 44 Remove the plastic pi restraining screws (2x) info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 45 Turn the MASLOW off. info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 46 Press submit on the Moixa Installer App to record the work info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 47 We use a custom forms app, we have created a series of forms that need to be used to report work done on the Moixa Smart Battery, and installs. This needs to be installed on your phone or tablet prior to work commencing.
  • Page 48 After enabling this, just open the app to join the other organization. info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
  • Page 49 | 49 info@moixa.com www.moixa.com Moixa Technology Ltd, One Fellmongers Path, DC READY , MOIXA are registered trademarks, logos, illustrations are property of ® ® London SE1 3LY Moixa Energy Holdings Ltd. Registered in England and Wales. © Moixa Technology Ltd 2016.
