Configuring your public network
5 Enter the TCP/IP settings you copied from the computer when
you started the install process.
6 Click Submit.
To complete SOHO Public Network configuration, see "Release
and renew the IP configuration" on page 19.
Configuring SOHO public network for PPPoE
While less common, PPPoE is another method for an ISP to assign
addresses. Check the information and manuals sent to you by your
ISP to see if they use PPPoE. If you cannot find this information,
contact your ISP and ask. You will need your PPPoE login name
and password.
The option to use PPPoE with the WatchGuard SOHO is available with
firmware version 2.0 or later.
To configure the SOHO for PPPoE:
1 Open your Web browser and click Stop.
At this point, the Internet connection is not fully configured, and the
computer cannot load your home page from the Internet. However, the
computer can access special configuration Web pages installed on the
SOHO itself.
2 Using your Web browser, go to http://192.168.111.1.
If this does not work, see "Troubleshooting installation and network
configuration" on page 25.
3 Click Public Network.
The Public Network page appears.
4 Scroll down to PPPoE Client.
