GEZE
EN Installation and Commissioning
Instructions with Wiring Diagram
SECULOGIC
TZ300
Emergency Exit System
Door Control Unit
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SECULOGIC TZ300 and is the answer not in the manual?

Questions and answers

Related Manuals for GEZE SECULOGIC TZ300

Summary of Contents for GEZE SECULOGIC TZ300

  • Page 1 GEZE EN Installation and Commissioning Instructions with Wiring Diagram SECULOGIC TZ300 Emergency Exit System Door Control Unit...

  • Page 2: Table Of Contents

    SECULOGIC TZ300 Contents About this document ............................3 Product description ......................................3 Related documents .......................................3 Key to symbols ........................................3 Abbreviations ........................................4 Safety and responsibility ............................5 General safety instructions ..................................5 Target readership and qualifications..............................5 Product liability ......................................5 Installation and assembly ...........................6 Preconditions ........................................6 Installing the flush-mounted door control unit ..........................6...

  • Page 3: About This Document

    These instructions describe the installation and commissioning of the GEZE TZ300 door control unit. Product description The GEZE door control unit is part of the SecuLogic emergency exit system. It is designed for controlling and monitoring electrically interlocked emergency exit doors. It secures doors along emergency exit routes against unauthorized access.

  • Page 4: Abbreviations

    About this document SECULOGIC TZ300 Abbreviations Abbreviation Meaning AKRR Feedback contact interlocked (actuated by the anchor) BLE220 Flashlight Fire detection system Latch lock FTÖ Emergency exit door opener GCDU100 Single-door unit GCDU200 Door unit GCFP401 Fingerprint GCRR200 RFiD card reader...

  • Page 5: Safety And Responsibility

    In addition, GEZE recommends a monthly inspection of the emergency exit system for visible damage and faults by the owner. Any identified damage or faults must be rectified immediately by a GEZE service technici- an or a GEZE-authorized service provider.

  • Page 6: Installation And Assembly

    SECULOGIC TZ300 Installation and assembly WARNING! Risk of death through electric shock. Installation and assembly must be performed only by GEZE-approved specialist personnel. Check that all cables are voltage-free before installation. Preconditions Cables are routed according to GEZE cabling diagram à...
  • Page 7 SECULOGIC TZ300 Installation and assembly Lay mains cable and ribbon cable in the flush-mounted sockets. Connect cable to terminal blocks according to wiring diagram. Connect and fit the PSU. Connect the key switch door control module with the ribbon cable.
  • Page 8 Installation and assembly SECULOGIC TZ300 Fit the terminal blocks to the back of the door control unit. Fit the door control unit. Fit the green adhesive frame. Test the unit’s function.

  • Page 9: Fitting The Surface-Mounted Door Control Unit

    SECULOGIC TZ300 Installation and assembly Fitting the surface-mounted door control unit Door control unit TZ300SN Terminal blocks Open the housing.
  • Page 10 Installation and assembly SECULOGIC TZ300 Fit the wall-mounting bracket near the door (height of emergency button: 850 mm – 1200 mm from floor surface). Take off the mains connection cover. Connect the 230 V cable to the screw terminals of the PSU and refit the cover.

  • Page 11: Replacing The Lock Cylinder

    SECULOGIC TZ300 Replacing the lock cylinder The lock cylinder must fulfil the following requirements: Profile half-cylinder, 40 mm (30/10) à Eight-way adjustable à When the plant is in operation, disable tamper switch. To do this, turn key to left for ten seconds. Right LED lights up green.

  • Page 12: Commissioning

    Commissioning SECULOGIC TZ300 Commissioning Preconditions Doors with electrical locks along escape routes must be taken into operation after the manufacturer has certified their suitability for the intended purpose. In addition, the correct installation and correct function of the electri- cal lock must be verified by a specialist.

  • Page 13: Fire Detection System (Bma), Hazard Alert System (Gma), Smoke And Heat Extraction System (Rwa)

    SECULOGIC TZ300 Commissioning 4.3.5 Door alarm If the pre-alarm time is exceeded, the door alarm is triggered. This must then be reset with the built-in key switch or with a new short-term release command. If the door is closed while the door alarm is active, it locks and can be unlocked again only after the alarm has been reset (except when the emergency button is pressed or emergency unlocking is triggered).

  • Page 14: Operation

    Operation SECULOGIC TZ300 Operation Emergency exit label Key switch Control unit with emergency button “Locked” LED “Door state” LED “Alarm” LED Indicator Colour Meaning Locked Green Unlocked Green flashing (every second) Short-term release Door closed Green Door open Yellow Alarm...

  • Page 15: Controlling Door Control Unit Tz300 With The Key Switch

    SECULOGIC TZ300 Operation Controlling door control unit TZ300 with the key switch Unlocking the door When the system is unlocked, the locking elements are disabled and the door can be opened. Turn the key to the left and hold it for about one second.

  • Page 16: Opening Doors In Emergencies And Triggering Alarm

    Operation SECULOGIC TZ300 Unlocking the door temporarily (short-term release = 20 seconds) With the short-term release function, the door can be unlocked with the key switch for 20 seconds. When this time has expired, the door is locked again. If the door is not closed after short-term release time has expired, a pre-alarm is issued.

  • Page 17: Cancelling Alarms

    SECULOGIC TZ300 Operation Cancelling alarms Alarms of the door control unit remain active until their cause has been eliminated and the alarm is acknowl- edged at the door control unit. (Exception: emergency unlocking through BMA,GMA or RWA, after which the alarm is automatically reset after 60 seconds;...

  • Page 18: Alarm Signal

    Operation SECULOGIC TZ300 Alarm signal Misuse of the system and emergency situations are indicated by a built-in buzzer and yellow alarm LED 3. An alarm can, in principle, be acknowledged only when its cause has been removed. Alarm Alarm LED...

  • Page 19: Removing Alarms And System Faults

    SECULOGIC TZ300 Operation Removing alarms and system faults Alarm state Cause of alarm Elimination of alarm cause Pre-alarm Door not closed after unlocking period has expired. Close door. No closed signal Unlock door. Door alarm No closed signal Close door.

  • Page 20: Wiring Diagram

    Wiring diagram SECULOGIC TZ300 Wiring diagram General information Unless otherwise stated, the wiring diagrams apply to surface-mounting versions and flush-mounting versions from TS300, software version 1.0. Markings The wiring in these wiring diagrams are marked as follows: Colour Former designation...

  • Page 21: Door Control Units

    PSU of the TZ300: UP: NET220, max. 350 mA; à AP: NT19.2-24, max. 650 mA with external PSU: max. 800 mA (use only GEZE-approved PSUs) à Terminal assignment Max. cable cross-section for screw and plug-in terminals: 1 mm² Terminal Function...
  • Page 22 When connecting a BMA, GMA or RWA, remove the resistor and connect it in series with the NC contact of the BMA, GMA or RWA (see plan “Emergency unlocking through BMA, GMA or RWA”). Contact closed when door closed. When a GEZE alarm bell or siren is fitted, a jumper must be set.
  • Page 23 SECULOGIC TZ300 Wiring diagram 6.4.3 Door control unit TZ300S, TZ300SN blue For notes about the wiring diagram, see section 6.4.2...
  • Page 24 Wiring diagram SECULOGIC TZ300 6.4.4 TZ300SN, TZ300S: Door monitor without locking element For use, for example, as door monitor Function: The door can be opened at any time through the panic handle. Opening the door without authorization triggers the door alarm, which, in turn, triggers a visual and acoustic alarm through the built-in signal generators.
  • Page 25 SECULOGIC TZ300 Wiring diagram 6.4.5 Emergency unlocking through BMA, GMA or RWA For notes about the wiring diagram, see section 6.4.2...

  • Page 26: Locking Elements

    Wiring diagram SECULOGIC TZ300 Locking elements If the door has several unlocking elements, connect the coils in parallel and the feedback signal cables in series. Programming interface 6.5. 1 Holding magnet MA500 (single-leaf doors) TST300 - X101 (orange terminal strip)
  • Page 27 SECULOGIC TZ300 Wiring diagram 6.5.3 Emergency door opener TYP331U DIN right/left (single-leaf doors) X101 (orange terminal strip) FTÖ331U Locking + Locking - Door locked AKRR 24 V DC Door closed 24 V DC Caution: Sever red wire jumper (1–7) behind the terminal field of the FTÖ331U.
  • Page 28 Wiring diagram SECULOGIC TZ300 6.5.6 Emergency door opener TYP331 DIN right (two-leaf doors) X101 (orange terminal strip) Locking + Locking - Door locked 24 V DC AKRR AKRR Door closed 6.5.7 Emergency door opener TYP331 DIN left (two-leaf doors) X101 (orange terminal strip)

  • Page 29: Key Switch

    SECULOGIC TZ300 Wiring diagram Key switch 6.6. 1 Key switch SCT320 to short-term release 6.6.2 Key switch SCT220 to short-term release orange terminal strip 24 V DC Closed on right Brief unlocking input Closed on left No. 115937, UP Jung AS500, WW No.
  • Page 30 Wiring diagram SECULOGIC TZ300 6.6.4 Key switch SCT320 for external control – unlocking, locking, short-term release unlocking and acknowledging alarms Connected through SCT320 of door control unit TZ300 key switch key switch 24 V DC 24 V DC Lock SCT, KZF, acknowledge...
  • Page 31 SECULOGIC TZ300 Wiring diagram 6.6.6 Key switch with indicator SCT222 For connecting the SCT222, relay card RP220 is required in addition. red terminal strip Screw terminal Power supply unit Supply GND 24 V DC supply orange terminal strip Locking +...

  • Page 32: Access Control

    Wiring diagram SECULOGIC TZ300 Access control 6.7. 1 Numerical code lock Toplock CTI, CTI B X102 (blue) or X100 (red) X101 (orange terminal strip) Brief unlocking input 6.7.2 Numerical codelock Toplock CTS V, CTS BV Number codelock Toplock CTS V, CTS BV...

  • Page 33: Timer

    SECULOGIC TZ300 Wiring diagram 6.7.3 Access control Single-door control unit GCDU100 Door control unit GCDU200 (orange terminal strip) 24 V DC Brief unlocking input Optionally the GCDU100 can be supplied with power through the TZ300. Observe total power consumption! X100 (red terminal strip)

  • Page 34: Iq Lock Em, Lever Locks

    Wiring diagram SECULOGIC TZ300 IQ Lock EM, lever locks 6.9. 1 IQ Lock EM power from TZ300 For connecting the IQ Lock EM, relay card RP220 is required in addition. X100 (red terminal strip) Screw terminal Power supply unit Supply GND...
  • Page 35 SECULOGIC TZ300 Wiring diagram 6.9.2 IQ Lock EM power from separate PSU For connecting the IQ Lock EM, relay card RP220 is required in addition. Power supply unit No. 109637 Function: When the TZ300 is locked, the outer lever handle of the IQ Lock EM is disengaged.

  • Page 36: Appendix

    Appendix SECULOGIC TZ300 Appendix Commissioning check list 7. 1 Not fitted Power supply OK Upper edge of all emergency buttons between 850 and 1200 mm from floor surface All emergency button labels applied Cables laid according to DIN VDE 0833, tamper-protected...

  • Page 37: Glossary Of Terms

    SECULOGIC TZ300 Appendix Glossary of terms Direct unlocking (according to EltVTR) Safety-relevant interruption of the power supply to the electrical lock through an NC contact when the emer- gency button is pressed. Unlocking (according to EltVTR) Non-safety-relevant interruption of the power supply to the electrical lock, for example with a key switch.

  • Page 38: Data Sheets

    Appendix SECULOGIC TZ300 Data sheets 7.3. 1 Door control unit TZ300 UP Technical specifications Device name Door control unit TZ300 UP Function Monitoring and controlling an emergency exit door Dimensions 55 × 55 × 37 (w × h × d) w ×...
  • Page 39 SECULOGIC TZ300 Appendix 7.3.2 Door control unit TZ300 AP Technical specifications Device name Door control unit TZ300 AP Versions TZ 300SN with built-in key switch and PSU TZ 300S with built-in key switch Function Monitoring and controlling an emergency exit door Dimensions 72 ×...
  • Page 40 SECULOGIC TZ300 7.3.3 Emergency exit sign FWS320UP Technical specifications Device name Emergency exit sign FWS320UP (non-illuminated) Function Emergency exit label Dimensions 55 × 55 × 16 (w × h × d) w × h: Emergency exit label d: Distance from support ring upper edge to fitted ribbon cable Installation In UP socket, 60 mm, depth 62.5 mm...
  • Page 41 SECULOGIC TZ300...
  • Page 42 SECULOGIC TZ300...
  • Page 43 SECULOGIC TZ300...
  • Page 44 E-Mail: office-bulgaria@geze.com GEZE GmbH Høje Taastrup Boulevard 53 E-Mail: office-india@geze.com China Niederlassung West 2630 Taastrup Nordsternstraße 65 GEZE Industries (Tianjin) Co., Ltd. Italy Tel. +45(0)46-323324 45329 Essen Shuangchenzhong Road GEZE Italia Srl Fax +45(0)46-323326 Tel. +49 (0) 201-83082-0 Beichen Economic Development Via Giotto, 4 E-Mail: danmark.se@geze.com...
