Summary of Contents for Delta Children Changing Table 7517
Page 1
ASTM F2388 Safety Standards Changing Table Need Help? Please visit www.DeltaChildren.com/assembly-videos to watch our easy and effective assembly videos Consumer Care: www.DeltaChildren.com Delta Children’s Products 114 West 26th Street Style #: ___________ New York, NY 10001 Tele.212-645-9033 Lot: ___________ This product is not intended for institutional or commercial use.
Page 2
- Do not scratch or chip the finish. - Inspect the product periodically, contact Delta Children's Products for replacement parts or questions. - Do not store the product or any parts in extreme temperatures and conditions such as a hot attic or a damp, cold basement.
Page 3
PARTS: MAKE SURE THAT ALL PRE-ASSEMBLED PARTS ARE TIGHT. B. Top Rail x 3 Part # 26143 A. Side x 2 Part # 26142 C. Shelf Rail x 2 Part # 26144 E. Top Shelf - 6mm x 1 Part # 26146 D.
Page 4
PARTS: HARDWARE KITS PART#26149. No drills necessary. H. M6 x 30 mm Bolt x 14 Do not use power Part # 5463 screwdriver. Phillips Screwdriver J. Φ4x30 mm Metal Pin x 6 (Not supplied) Part # 5493 K. M4 x 15 mm Screw x 6 Part # 5902 M4 Allen Wrench Supplied Part # 1177...
Page 5
Section 1: Changing Table Assembly Step 1 Parts and tools required to complete step. B. Top Rail x 3 H. M6 x 30 mm Bolt x 7 J. Φ4x30 mm Metal Pin x 3 A. Side x 1 C. Shelf Rail x 2 M4 Allen Wrench D.
Page 6
Section 1: Changing Table Assembly Step 2 Parts and tools required to complete step. F. Bottom Shelf - 3mm x 1 E. Top Shelf - 6mm x 1 From Step 1 Lay the Left Side on the floor, rails up. Slide the Top Shelf (Part E) in the grooves on the Shelf Rails, into the groove on the Side, Slide the Bottom Shelf (Part F) in the grooves on the Lower Shelf Rails, into the grooves on the Side as shown.
Page 7
Section 1: Changing Table Assembly Step 3 Parts and tools required to complete step. From Step 2 A.Side x 1 H. M6 x 30 mm Bolt x 7 J. Φ4x30 mm Metal Pin x 3 M4 Allen Wrench Supplied Attach (1) Side (Part A) to the assembly from step 2 with (3) Φ4x30 mm Metal Pins (Part J) and (7) M6x30 mm Bolts (Part H) using the M4 Allen Wrench as shown.
Page 8
Section 1: Changing Table Assembly Step 4 Parts and tools required to complete step. From Step 3 G. Shelf Support x 3 Phillips Screwdriver (Not supplied) K. M4 x 15 mm Screw x 6 Attach (3) Shelf Support (Part G) to the Rails using (6) M4x15mm Screws (Part K). Tighten with the Phillips Screwdriver.
Page 9
Consumer Care: www.DeltaChildren.com Delta Children’s Products 114 West 26th Street New York, NY 10001 Tele.212-645-9033 Warranty: This Delta product is warranted to be free from defects for a period of 90 days from the date of purchase under normal use. This warranty extends only to the original retail purchaser and is valid only when supplied with proof of purchase, or if received as a gift, when the registration is on file with Delta.
