- Page 1 TruVision Dome Brackets Installation Manual P/N 1072649B-EN • REV 1.0 • ISS 30SEP13...
- Page 2 Copyright © 2013 UTC Fire & Security Americas Corporation, Inc. Interlogix is part of UTC Climate Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and patents The TruVision name and logo are trademarks of United Technologies.
-
Page 3: Table Of Contents
Content Introduction 2 Bracket and cup base descriptions 2 Wall-mount installation (TVD-SNB and TVD-M2-WM) 4 5-inch dome cameras 4 3-inch dome cameras 6 2-inch dome wedge cameras 7 Flush-mount installation (TVD-M2-FM) 8 5-inch dome indoor cameras 8 Pendant-mount installation (TVD-PPB) 10 ... -
Page 4: Introduction
Introduction These are the installation instructions for the TruVision series of dome brackets and cup bases. The series brackets and cup bases are compatible with both indoor and outdoor Interlogix cameras Models For a list of the brackets and cup bases with their corresponding cameras, see “Overview: Fixed dome cameras by bracket”... - Page 5 TruVision flush-mount bracket (TVD-M2-FM) TruVision pole-mount adaptor (TVD-M-PMA) TruVision indoor dome wall-mount bracket (TVD-M2-WM) TruVision dome cup bases • TVD-CB5: Note: The rubber ring for TVD-CB5 is pre-installed in the cup base. • TVD-CB5A: Note: The rubber ring for TVD-CB5A is pre-installed in the cup base. TruVision Dome Brackets Installation Manual...
-
Page 6: Wall-Mount Installation (Tvd-Snb And Tvd-M2-Wm)
• TVD-CB3: • TVD-CB2: Converter pan (TVD-M2 WEBM) Accessories Screw Ø 4 mm (2 Expansion screw Screw Ø 4 mm Locking screw Ø 4 mm Black screw Ø 4 mm pieces) Ø 10 mm (5 pieces) (4 pieces) (2 pieces) (4 pieces) Wall-mount installation (TVD-SNB and TVD-M2- Check the section “Overview: Fixed dome cameras by bracket”... - Page 7 2. Screw the cup base onto the swan-neck bracket and fasten with the locking screw, as shown. 3. TVD-CB5 only: Using the enclosed screws, attach the cup base to the camera housing. 4. Loosen the screws on the dome enclosure (1) using the supplied hex wrench, and remove the enclosure and dome liner (2).
-
Page 8: 3-Inch Dome Cameras
3-inch dome cameras Use the TVD-SNB bracket with the TVD-CB3 cup base or TVD-M2-WM bracket. See “Bracket and cup base description” on page 2 for examples of the assembled brackets. To mount a swan-neck bracket on a wall: 1. Pull the camera cables through the TVD-SNB bracket tube and then attach the swan-neck bracket to the wall with the expansion screws (A) provided. -
Page 9: 2-Inch Dome Wedge Cameras
To mount an indoor wall-mount bracket: 1. Pull the camera cables through the TVD-M2-WM bracket tube and then attach the bracket to the wall with the expansion screws (A) provided. 2. Attach the mounting plate to the bracket. Note: The mounting plate is shipped with the dome camera. -
Page 10: Flush-Mount Installation (Tvd-M2-Fm)
3. Then screw the cup base onto the swan-neck bracket and fasten with the locking screw. 4. Loosen the screws on the dome enclosure using the supplied hex wrench and remove it. 5. Connect the cables to the dome camera. Using two screws, attach the camera base plate to the converter pan on the cup base. - Page 11 2. Using screws provided, fasten the mounting plate (A) to the in-ceiling mounting base (B). 3. Push the dome camera into the in-ceiling mounting base. Safety cable Caution: For safety reasons, use safety cables to securely attach the camera dome to the in- ceiling mounting base and to attach the in-ceiling mounting base to the building’s infrastructure.
-
Page 12: Pendant-Mount Installation (Tvd-Ppb)
Pendant-mount installation (TVD-PPB) Check the section “Overview: Fixed dome cameras by bracket” on page16 to confirm that the correct bracket is used with the camera. 5-inch dome cameras Use the TVD-PPB bracket and the TVD-CB5/TVD-CB5A cup base. See “Bracket and cup base description”... -
Page 13: 3-Inch Dome Cameras
6. Connect the cables to the dome camera. 7. Insert the dome module into the cup base. 8. Re-attach the dome liner and enclosure to the camera. 3-inch dome cameras Use the TVD-PPB bracket and the TVD-CB3 cup base. See “Bracket and cup base description” on page 2 for examples of the assembled bracket. -
Page 14: 2-Inch Dome Wedge Cameras
5. Connect the cables to the dome camera. 6. Using screws, attach the dome module to the mounting plate. 7. Re-attach the dome liner and enclosure to the camera. 2-inch dome wedge cameras Use the TVD-PPB bracket and the TVD-CB2 cup base. To mount a pendant-mount bracket on a ceiling: 1. -
Page 15: Pole-Mount Installation (Tvd-M-Pma)
5. Using 2 screws, attach the camera base plate to the converter pan. 6. Re-attach the camera enclosure to the camera. Pole-mount installation (TVD-M-PMA) Check the section “Overview: Fixed dome cameras by bracket” on page16 to confirm that the correct bracket is used with the camera. Use the TVD-M-PMA pole-mount adaptor to mount a camera on a pole. -
Page 16: Specifications
4. Loosen the screws on the dome enclosure using the supplied hex wrench, and remove the dome enclosure and liner. 5. Connect the cables to the dome camera. 6. Using the enclosed screws, attach the dome module of the camera to the bracket. 7. -
Page 17: Pipe Threading Information
TVD-CB2 Ø 124 × 57 mm 190 g (0.42 lb) Pipe threading information Pipe Threads Pitch Thread major Corresponding pipe Tapping drill size (mm) thread / in (mm) diameter size (mm) (in.) Thickness BSP. F (G) (mm) (in.) (mm) 2.309 33.249 1.309 33.7...
