- Page 1 TruVision 360° Camera Bracket Installation Manual P/N 1072843A-EN • REV 1.0 • ISS 25SEP14...
- Page 2 Copyright © 2014 United Technologies Corporation. Interlogix is part of UTC Building & Industrial Systems, a unit of United Technologies Corporation. All rights reserved. Trademarks and patents Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
-
Page 3: Table Of Contents
TVF-WBM TruVision 360° Camera Round Angled Back Box, Conduit Ports, Gang Box Compatible, Metal, Indoor & Outdoor TVF-CBM TruVision 360° Camera Cup Base (use with TVD-PPB for pendant mount or TVD-SNB for wall mount) TVD-SNB TruVision Dome Swan Neck Bracket... -
Page 4: Bracket Descriptions
Unpacking Please check the package contents to ensure that all parts are present and in good condition. Note: For safety purposes, the mounting surface must be able to support three times the combined weight of the bracket and camera. Bracket descriptions TruVision 360°... -
Page 5: Truvision 360° Camera Cup Base Back Box (Tvf-Cbm)
TruVision 360° camera cup base back box (TVF-CBM) Screw B Φ4 x 10mm (3 pcs) TruVision dome swan neck bracket (TVD-SNB) Expansion screw Ø 10 mm (5 pcs) Locking screw Ø 4 mm (2 pcs) TruVision dome pendant mount bracket (TVD-PPB) Expansion screw Ø... -
Page 6: 360° Camera Installation
360° camera installation To mount the 360° camera on a round back box 1. Using the three A screws and the drywall anchor, attach the back box to the wall. Note: The four other screw holes are for double gang. 2. -
Page 7: To Mount The 360° Camera On A Round Angled Back Box
Important: When mounting the camera to the back box, ensure that the ‘UP’ reference on the camera base is pointing upwards. 6. Re-attach the camera cover. 7. Tighten the cover screw in the camera cover to securely reattach cover to the camera. - Page 8 3. Connect the cables to the camera. 4. Partially screw the three B screws into the wedge back box. 5. Attach the camera to the round angled back box. Align the holes on the base of the camera with the three back box screws and rotate the camera to lock it into position on the back box.
-
Page 9: To Mount The 360° Camera On A Swan Neck Bracket
To mount the 360° camera on a swan neck bracket 1. Pull the camera cables through the TVD-SNB bracket tube and then attach the swan neck bracket to the wall with the expansion screws (A) provided. 2. Screw the cup base onto the swan neck bracket and fasten with the locking screw, as shown (A). -
Page 10: To Mount The 360° Camera On A Pendant Mount Bracket
6. Attach the camera to the cup base (A). 7. Re-attach the camera cover onto the camera (B). 8. Tighten the cover screw in the camera cover to securely reattach the cover to the camera. To mount the 360° camera on a pendant mount bracket 1. - Page 11 4. Partially screw the three B screws into the pendant bracket. 5. Connect the cables to the camera. 6. Remove the camera cover from the camera. Open the small flap on the camera cover. Using the hex wrench provided, unscrew the hex head screw (1).
-
Page 12: Specifications
9. Tighten the cover screw in the camera cover to securely reattach the cover to the camera. Specifications Dimensions Weight TVD-SNB 253 × 95 × 180 mm 490 g (1.2 lb) TVD-PPB Ø 150 × 537 mm 1169 g (2.56 lb) TVF-BBM Ø...
