- Page 1 BBM 7000 ■ User’s manual EN / Digital Audio Baby Monitor ■ Návod k obsluze CZ / Digitální audio chůvička ■ Návod na obsluhu SK / Digitálna audio opatrovateľka ■ Használati útmutató HU / Digitális audió babaőrző...
- Page 2 .............................. 3 ............................. 19 ............................. 35 ............................. 51...
-
Page 3: Table Of Contents
Digital Audio Baby Monitor Table of Contents Introduction ..............................4 Safety instructions and important notes ......................4 Description of the accessories ..........................6 Description of the baby unit ..........................7 Description of the parent unit ..........................8 Installation location of the baby unit and parent unit ..................9 Power source ..............................9 Using the baby monitor ..........................11 General information about using the baby monitor ..................12... -
Page 4: Introduction
Introduction ■ Thank you for selecting the Bayby BBM 7000 Digital Audio Baby Monitor. This digital baby monitor is a great child care accessory that enables you to hear your baby when you are not in the same room. Nevertheless, it is important to understand that it cannot serve as a substitute for responsible adult supervision. - Page 5 Digital Audio Baby Monitor ■ Before connecting the power adapter to a power socket, make sure the voltage stated on its rating label corresponds to the voltage in the power socket. Position the power cord of the power adapter so that it will not be tripped over.
-
Page 6: Description Of The Accessories
Digital Audio Baby Monitor Description of the accessories 1 Parent unit* 3 Power adapter (2 pcs) The adapters are identical. 2 Baby unit Note*: The parent unit comes with two type AAA rechargeable batteries (2× 1.2 V / 550 mAh). -
Page 7: Description Of The Baby Unit
Digital Audio Baby Monitor Description of the baby unit 1 Power On LED indicator light 4 Socket for connecting the plug on the power adapter (not shown), 2 Button for turning the baby unit on and off it is located at the rear of the baby unit. 3 Microphone... -
Page 8: Description Of The Parent Unit
Digital Audio Baby Monitor Description of the parent unit 1 Connection/On LED indicator light 6 Socket for connecting the plug on the power adapter (not shown), 2 Volume LED indicator light it is located at the bottom of the parent unit. 3 Increase volume button 7 Loudspeaker (not shown), 4 Button for turning the parent unit on and off... -
Page 9: Installation Location Of The Baby Unit And Parent Unit
Digital Audio Baby Monitor Installation location of the baby unit and parent unit Baby unit ■ Locate the baby unit A2 within reach of a power socket on an even, dry and stable surface in the room where you want to monitor your child. We recommend an elevated location (e.g. chest of drawers or a shelf) at a sufficient distance away from equipment and devices that could cause signal interference. - Page 10 Digital Audio Baby Monitor Attention: For safety reasons, the parent unit A1 when powered from an external power source can only be put into operation with rechargeable batteries inserted inside. ■ Internal power source and its use – For powering the parent unit from an internal power source, use the supplied Ni-MH type AAA batteries (2×...
-
Page 11: Using The Baby Monitor
Digital Audio Baby Monitor Note: The interval after which the parent unit A1 automatically turns off depends on the mode in which the parent unit A1 is, the battery capacity, battery age, etc. – In the event that you are planning not to use the baby monitor for an extended period of time, take the batteries out of the parent unit A1 and store them out of the reach of children. -
Page 12: General Information About Using The Baby Monitor
Digital Audio Baby Monitor Setting the volume intensity ■ Buttons C3 and C5 can be used to increase and decrease the volume on the parent unit A1. The volume setting is confirmed by the volume LED indicator C2 turning on for a short time, and an acoustic signal will be sounded. -
Page 13: Troubleshooting
Digital Audio Baby Monitor Troubleshooting Problem Solution LED indicator light B1 Check that the power adapter A3 is connected to a working power socket and does not light up when the that the plug on the power cord is properly inserted into socket B4. baby unit A2 is turned on. -
Page 14: Cleaning And Maintenance
For cleaning, do not use abrasive cleaning products, solvents, thinners, etc. Never submerge the baby monitor or its power adapters A3 in water or rinse under running water. Technical specifications Model number ..............BBM 7000 Frequency broadcast band ..........1 880–1 900 MHz Transmission power ............20 dBm (100 mW) Range in open space ............ - Page 15 Digital Audio Baby Monitor Value and precision ............Unit Manufacturer’s name or trade mark, commercial registration number and address ....Dongguan everest industrial Co, Ltd, No. 2 Xingyi road, Shangjiao community, ChangAn Town, 523878 Donguang Guangdong, Peopleś republic of China Model identifier ..............
-
Page 16: Explanation Of Symbols Used On The Product, Its Accessories And Packaging
Digital Audio Baby Monitor Explanation of symbols used on the product, its accessories and packaging This symbol indicates that this appliance meets all the basic requirements of EU directives related to it. This symbol indicates that the product has protection class II. This symbol indicates the polarity of the power cord connectors. -
Page 17: Instructions And Information About The Handling Of Used Packaging
Instructions and information about the handling of used packaging Dispose of used packaging material at a site designated for waste in your municipality. BAYBY hereby declares that radio device model number BBM 7000 is in compliance with directive 2019/1782/EU. A valid declaration of conformity can be found at www.bayby.com. - Page 18 Digital Audio Baby Monitor Authorized service centres Please visit our website www.bayby.com for detailed information about authorised service centres.
