ELEMENT RACK INSTRUCTIONS pg.3

Installation of the rack

For 2" racks only. Check to make sure that the
1
nut inside the rack hitch bar is aligned with the
hole in the hitch bar. Adjust with a screw driver
if necessary.
Slide the rack into the receiver hitch of
2
the vehicle.
Line the hole in the hitch bar with the hole in
3
the receiver hitch.
Place the lock washer on the hitch bolt and
4
thread it into the nut in the hitch bar. For 2"
racks tighten the hitch bolt to 60 foot pounds.
For the 1.25" racks tighten the hitch bolt to 40
foot pounds.
1 1
2
