- Page 1 USER INSTRUCTIONS MODIFICATION OF 12V WIRING HARNESS TO SUIT THE LED215SD AND LED180SD.
- Page 2 (figure 2) INSTALLATION STEPS Take the crimp terminals provided with the LFDLH harness (figure 1, item A) Fit crimp terminals to the red and black cable of the adaptor (figure 2, item B) Fit the yellow insulators (figure 1, item B) over the crimp terminals...
- Page 3 ADAPTOR Figure 2. Blue Yellow Black ADAPTOR WIRE COLOUR IDENTIFICATION Red: Positive - connect to positive wire on harness Black: Negative - connect to negative (earth) wire on harness Yellow: Positive - LED positioning lights, connect to positive low beam light circuit Blue: Not used.
- Page 4 All logos and images are subject to relevant trademark and copyright protection. Copyright © Lightforce Australia Pty Ltd 2019. Data and specifications may be subject to change without notice. Lightforce Australia Pty Ltd shall not be liable for damage, malfunction, failure resulting from accident, misuse, misapplication, unauthorised repair, neglect, modification, unauthorised or non standard replacement parts, accessories, bulbs, batteries or voltage or operation of the product beyond its technical and or environmental specification.
