- Page 1 USER INSTRUCTIONS TRIPLE SWITCHING HIGH POWERED HARNESS FOR GENESIS AND VENOM LED LIGHTS (with positioning light functions)
- Page 2 Switch Adaptor (not included, see Figure 9) will be required. Follow the instructions included with • 15 x Cable ties the Lightforce Switch Adaptor. The yellow dash • 1 x User instructions. illumination cable (item 10 in figure 1) will need to be wired to the dash light / park light.
- Page 3 Fig 1. Driving Light Harness 40 Amp Relay Driving light 4 pin connectors Battery negative ring terminal Battery positive ring terminal Ignition pickup wire Low beam pickup wire with bullet terminal (positive) High beam pickup wire with bullet terminal (negative) High beam pickup wire with bullet terminal (positive) Dashboard switch loom connector...
- Page 4 Ensure that cables do not touch the radiator or Headlight come in contact with any sharp edges connector 5. Secure all excess wire to the vehicle with cable Blue ties supplied. (See Page 6) LIGHTFORCE.COM USER INSTRUCTIONS...
- Page 5 OPTIONAL WIRING - POSITIONING CONNECTING LOW BEAM PICK UP LIGHTS (switch one) For H4: Connect the blue wire (No.6) on the H4 NOTE: This function will enable and disable the path harness to the blue wire on the main harness. positioning lights .
- Page 6 STEP 6. CONNECT TO THE BATTERY Connect the ring on the red wired battery connector to the positive battery terminal using a spanner Connect the ring on the black wired battery connector to the negative battery terminal using a spanner. Dash switch LIGHTFORCE.COM USER INSTRUCTIONS...
- Page 7 THIS PAGE IS INTENTIONALLY BLANK...
- Page 8 International Telephone: +61 8 8440 0888 | Fax: +61 8 8346 0504 All logos and images are subject to relevant trademark and copyright protection Lightforce Pty Ltd. Copyright © 2019. Data and specifications contained maybe subject to change without notice. Lightforce Australia...
