E-MANUAL

Thank you for purchasing this Samsung product.

To receive more complete service, please register

your product at

www.samsung.com/register

Model______________ Serial No.______________

Need help?

Do you have a question about the UA55ES7500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung UA55ES7500

Page 1 E-MANUAL Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register Model______________ Serial No.______________...
Page 2 Contents Channel Menu Preference Features Basic Feature...
Page 3 Advanced Features Videos AllShare Play Photos AllShare Play Music AllShare Play Smart Hub Recorded TV AllShare Play Timeshift Samsung Apps Search Your Video Anynet+ (HDMI-CEC) Family Story Fitness Kids Web Browser Skype AllShare Play My list AllShare Play...
Page 4 Other Information...
Page 5 Connecting the TV Connecting to an Antenna <TV> The displayed image may differ depending on the model.
Page 6 Connecting to an AV Device Using a HDMI (up to 1080p) <TV> The displayed image may differ depending on the model.
Page 7 Using a Component (up to 1080p) <TV> The displayed image may differ depending on the model.
Page 8 Connecting to an Audio device Using an Optical (Digital) Connection <TV> The displayed image may differ depending on the model.
Page 9 Using a Headphone Connection for LED TV <TV> The displayed image may differ depending on the model.
Page 10 Connecting to a PC Using an HDMI/DVI Cable <TV> The displayed image may differ depending on the model.
Page 11 Using the INFO button (Now & Next guide) The display identifies the current channel and the status of certain audio- video settings. The Now & Next guide shows daily TV programme information for each channel according to the broadcasting time. Scroll to view information for a desired programme while watching the...
Page 12 Scroll to view information for other channels. If you want to move to the currently selected channel, select using your remote. Some country, if Digital Text is set to Enable, the EPG (Electronic Programme Guide) will work.
Page 13 Using the Channel Menu ™ Press the button to select the menu you want to use. Each screen will be displayed. Guide ™ Guide The EPG (Electronic Programme Guide) information is provided by broadcasters. Using programme schedules provided by broadcasters, you can specify...
Page 14 programmes you want to watch in advance so that the channel automatically changes to the selected programme channel at the specified time. Programme entries may appear blank or out of date depending on a channel status. Some country, if Digital Text set to Enable, the EPG (Electronic Programme Guide) will work.
Page 15 Using Channel View (Sche. Mgr): Displays the Schedule Manager. (-24 Hours): Viewing the list of programmes to be broadcasted before 24 hours. (+24 Hours): Viewing the list of programmes to be broadcasted after 24 hours. (Ch. Mode): Select the type of channels you want to display on the...
Page 16 Channel View window. ` Information: Displays details of the selected programme. k Page: Move to next or previous page. Watch / Enter: When selecting the current programme, you can watch the selected programme. / Displays detailed information of the selected channel. This function may not be supported depending on the country.
Page 17 Channel ™ Channel Using this function, you can delete channels, set favourite channels and edit the channel name for analogue broadcasts. The available items may differ depending on the selected antenna source. Shows all channels.
Page 18 Shows TV channels. Radio Shows radio channels. Data/Other Shows data channels and other channels. Analogue Shows analogue channels. Favourites 1 – Favourites 5 Shows all favourite channels, in up to...
Page 19 five groups. Each group has separate channels. The TV displays favourites only if you have added favourites using Edit Favourites in the Tools menu. If the highlight located in the Favourites 1 – Favourites 5 category, you can change the name of category by selecting using your remote.
Page 20 Shows the most recently viewed channels. Most Viewed Shows the most frequently viewed channels. Using the coloured and function buttons with Channel Delete Delete the selected channel(s). Information...
Page 21 Displays details of the selected channel. Page Scrolls the channel list to the next or previous page. Select Deselect Selects or deselects a channel. Tools Displays the option menu. Return Return to the previous menu.
Page 22 Using the Tools menu with the Channel Edit Favourites Lets you assign channels you watch frequently to a favorites group and remove channels from a favorites group. You access Edit Favourites Tools menu. 1. Select Edit Favourites. The Edit Favourites screen appears.
Page 23 favourite group. Also, you can select a channel in Edit Favourites screen. You can add a favourite channel to any one of the groups. To change favourites group, select using your remote. Each time you select , a favourites group will be changed.
Page 24 to the favourite group you selected. On the Channel screen, the TV displays the “ ” symbol next to the channel, indicating it is a favourite. Lock Unlock Lock a channel so that the channel cannot be selected and viewed. This function is available only when Channel Lock is set to On.
Page 25 (Appears only if you have selected an analogue channel.) Lets you assign a name of up to five characters to an analogue channel. For example, Food, Golf, etc. This makes it easier to find and select the channel. Edit Channel Number Edit the channel number by select the numbers.
Page 26 Sorting (digital channels only) Change the list ordered by channel name or number. Channel Info Displays information of channel signal. The item may differ depending on channel. Delete Delete a channel to display the channels you want. Select All Deselect All...
Page 27 Select all channels in the list. / Deselect all channels you selected. To delete a channel from a Category list on the Channel screen, follow these steps: 1. If you want to delete a channel, select a category of the channel. 2.
Page 28 You can select more than one channel. If you select the selected channel again, a mark disappears. 3. Open the Tools menu using your remote. 4. Select Delete. The message Delete the selected channels? appears. Select OK. You can delete the selected channel immediately by selecting using...
Page 29 your remote. When you delete a channel in the Recently Viewed Most Viewed category, the channel will disappear from the category list. But, the channel is not deleted. To set channels as favourites, follow these steps: 1. Select the category. 2.
Page 30 to the left of the channel. You can select more than one channel. If you select the selected channel again, a mark disappears. 3. Open the Tools menu using your remote. 4. Select the Edit Favourites. The Edit Favourites screen appears. 5.
Page 31 the favourite group. Also, you can select a channel in Edit Favourites screen. You can add a favourite channel to any one of the groups. To change favourites group, select using your remote. Each time you select , a favourites group will be changed.
Page 32 to the favourite group you selected. The TV displays the “ ” symbol next to the channel, indicating it is a favourite. Using the coloured and function buttons with Edit Favourites On the Edit Favourites screen, you can use these functions buttons: –...
Page 33 favourites group. – Change Fav. Change the favourites group. Each time you select using your remote, the favourites group changes. – Ÿ Go To Move to the Highlight to a channel number immediately by pressing the number button using your remote.
Page 34 – R Return Return to the previous menu. When you highlight a favourite channel in a favourites group on the Edit Favourites screen, you can use these options: – Delete Delete the selected channel. – Change order Change the favourite group list order.
Page 35 – Copy Copy a selected channel to other favourites groups. – Change Fav. Change the favourites group. Each time you select using your remote, the favourites group changes. – Ÿ Go To Move to the Highlight to a channel number immediately by pressing...
Page 36 the number button using your remote. – R Return Return to the previous menu. To remove a channel from a favourites group, follow these steps: 1. Select the favourite’s group category. 2. Select a channel in the favourites group. A mark appears to the left of the channel.
Page 37 You can select more than one channel. If you select the selected channel again, a mark disappears. 3. Open the Tools menu using your remote. 4. Select Delete. The message Do you want to delete the selected item(s)? appears. 5. Select OK. The message Deleted the selected item(s).
Page 38 You can delete the selected channel from the list of favourites group immediately using the function. Display Icons Used in the Channel screens : An analogue channel. : A channel selected. : A favourite channel. : A locked channel.
Page 39 Schedule Manager ™ Schedule Manager Using this function, you can set the TV to display a desired channel automatically on a day and at a time of your choice. You must set the current time first using the Time Clock function in the System...
Page 40 To use Schedule Viewing, follow these steps: 1. On the Schedule Manager screen, select using your remote. 2. A pop up screen will appear. Select Schedule Viewing. 3. Set Aerial, Channel, Repeat, and Start Time. Aerial Select the desired antenna source. Channel...
Page 41 Select Channel to view the channel numbers. Select the desired channel. You can only select memorised channels. You can also enter the channel number directly using the number buttons on the standard remote or the number function button on the Smart Touch Control.
Page 42 Mon~Fri or Everyday. If you select Manual, you can set the day you want. mark indicates a day you’ ve selected. Date: You can set a desired date. Date is available only when you select Once in Repeat. Start Time You can set the start time you want.
Page 43 selected channel is scheduled for viewing. On the Schedule Manager screen, you can view a list of Schedule Viewing. To delete an item in a list of scheduled viewing, follow these step: 1. On the Schedule Manager screen, highlight an item you want to delete. 2.
Page 44 remote. 3. Select the Cancel schedule. The Cancel selected list(s)? message appears. 4. Select Yes. The selected schedule is cancelled. If you press the INFO button for Standard Remote Control select Info for Smart Touch Control after Highlighting an item, the Information screen appears.
Page 45 Information screen, you can change or cancel the Schedule Viewing. Cancel schedule: Cancel the Schedule Viewing. Edit Schedule: Change the Schedule Viewing. Return: Return to the previous screen. To use the Schedule Recording, follow...
Page 46 these steps: (Digital channels only) Allows you to make a reservation to record a programme scheduled for broadcast. Set the current time first to use this function. 1. Select Schedule Manager. The Schedule Manager screen will be displayed. 2. Select using your remote.
Page 47 up screen will appear. 3. Select the Schedule Recording. We recommend using a USB HDD with at least 5,400 rpm, but a USB HDD of RAID type is not supported. A USB storage device cannot record until it completes the Device Performance Test.
Page 48 4. Set the Aerial, Channel, Repeat, Date, Start Time. If you want to play a recorded programme, refer to Recorded TV in the e-Manual. Channel List Using this function, you can view the channel list, programme information, favourite channel, and manage of Schedule Viewing.
Page 49 1. Press the CH LIST button for Standard or select CH List Remote Control . The Channel List Smart Touch Control screen is displayed immediately. 2. Change a channel or channel list mode. Using the coloured and function buttons with the Channel List If you press the INFO button...
Page 50 , the TV displays for Smart Touch Control details of the selected program. Programme View Channel View Displays the programme when digital channel is selected. Returns to the channel view. Ch. Mode Channel Move to the type of channels you want to display on the Channel List screen.
Page 51 Watch Information Watches the channel you select. / Displays details of the selected programme. Page Move to next or previous page. Using the Schedule Viewing in Channel List You can use Schedule Viewing Channel List to schedule a digital channel programme for viewing.
Page 52 The TV will turn on and display the digital channel programme when the programme begins. 1. Select CH LIST function using your remote. The Channel List screen appears. 2. Select a desired digital channel. 3. Select using your remote. The TV displays the programme list of the selected channel.
Page 53 programme view, and then select Information using your remote. 5. On the Information screen, select Schedule Viewing. The selected programme is scheduled. If you want to cancel Schedule Viewing, follow Steps 1 through 4, and then select Cancel schedule. Channel Status Display Icons : An analogue channel.
Page 54 : A reserved programme. : A reserved recording programme. : A locked channel.
Page 55 Memorising Channels Country Menu Channel Country Select your country so that the TV can correctly auto-tune the broadcasting channels. The PIN input screen appears. Enter your 4 digit PIN number. Auto Tuning...
Page 56 Menu Channel Auto Tuning Scans for a channel automatically and stores in the TV. Automatically allocated programme numbers may not correspond to actual or desired programme numbers. If a channel is locked using Channel Lock function, the PIN input window appears. Digital &...
Page 57 When selecting Cable Digital & Analogue or Digital: Provide a value to scan for cable channels. Manual Tuning Menu Channel Manual Tuning Scans for a channel manually and stores in the TV. If a channel is locked using the Channel Lock function, the PIN input window appears.
Page 58 This function may not be supported depending on the region. When Aerial Source is set to Air or Cable Digital Channel Tuning: Scans for a digital channel. Bandwidth function may not be supported depending on the region. 1. Select the New. 2.
Page 59 the channel list. Analogue Channel Tuning: Scans for a analogue channel. 1. Select the New. 2. Set the Programme, Colour System, Sound System, Channel and Search. 3. Select the Store. When scanning has finished, a channel is updated in the channel list.
Page 60 complete, the broadcasting stations in your area have been assigned to position numbers from P0 to P99. You can select a channel by entering the position number in this mode. (aerial channel mode) / (cable channel mode): These two modes allow you to select a channel by entering the assigned number for each aerial broadcasting station or...
Page 61 Other Features Guide Type Menu Channel Guide Type (Depending on the country) You can select a different type of Guide. Guide: Uses the guide programme provided by Samsung. Auto: Uses the guide programme provided by through digital broadcasts.
Page 62 Transfer Channel List Menu Channel Transfer Channel List (Depending on the country) The PIN input screen appears. Enter your 4 digit PIN number. Imports or exports the channel map. You should connect USB storage to use this function. Import from USB: Import channel list from USB.
Page 63 Export to USB: Export channel list to USB. This function is available when USB is connected. Fine Tune Menu Channel Fine Tune (Analogue channels only) If the reception is clear, you do not have to fine tune the channel, as this is done automatically during the search and store operation.
Page 64 weak or distorted, fine tune the channel manually. Scroll to the left or right until the image is clear. Settings are applied to the channel you’re currently watching. Fine tuned channels that have been saved are marked with an asterisk “*” on the right-hand side of the channel number in the channel banner.
Page 65 Crosstalk noise reduction Menu Channel Crosstalk noise reduction (Analogue channels only) This function reduces diagonal noise in the picture caused by signal crosstalk (interference). If your TV picture displays diagonal noise or distortion when you watch, turn on this function.
Page 66 Changing the Preset Picture Mode Picture Mode Menu Picture Picture Mode Picture modes apply preset adjustments to the picture. When your TV is connected to a PC via an HDMI to DVI cable, you can only select Entertain and Standard. Dynamic Suitable for a bright room.
Page 67 Standard Suitable for a normal environment. Natural Relax for LED TV for PDP TV Suitable for reducing eye strain. Movie Suitable for watching movies in a dark room. Entertain Suitable for watching movies and games. Only available when the TV is...
Page 68 connected to a PC via an HDMI to DVI and an HDMI to HDMI cables.
Page 69 Adjusting Picture Settings Backlight Cell Light for LED TV for PDP TV Menu Picture Backlight Cell Light Adjusts the pixel brightness. 20 is the brightest setting. Contrast Menu Picture Contrast Adjusts contrast level. Values closer to 100 mean bigger light/dark contrast.
Page 70 Brightness Menu Picture Brightness Adjusts brightness level. Values closer to 100 mean brighter screen. Sharpness Menu Picture Sharpness Adjusts sharpness of picture. Values closer to 100 mean a sharp image.
Page 71 Colour Menu Picture Colour Adjusts colour saturation level. Values closer to 100 mean more intense colours. Tint (G/R) Menu Picture Tint (G/R) Adjusts tint levels for green and red. Values closer to 100 mean greater intensity for that colour.
Page 72 To adjust picture quality, follow these steps: 1. Select an option you want to adjust. When you select an option, a slider screen appears. 2. Adjust the option value using your remote. When you change an option value, the change will affect the OSD menu also.
Page 73 via an HDMI to DVI cable, Colour Tint (G/R) is not available. You can adjust and store settings for each external device connected to the TV. Lowering picture brightness reduces power consumption.
Page 74 Changing the Picture Size Screen Adjustment Menu Picture Screen Adjustment Using this function, you can select various picture size and aspect ratio options. Picture Size Your cable box / satellite receiver may have its own set of screen sizes as well.
Page 75 you use your TV's 16:9 mode most of the time. à Œ If you have set Double ( ) mode in PIP (Picture-in-Picture), you cannot adjust the Picture Size. Auto Wide: Automatically adjusts the picture size to the 16:9 aspect ratios. 16:9: Adjusts the picture size to 16:9 for DVDs or wide broadcasting.
Page 76 Zoom: Magnifies the 16:9 wide pictures vertically to fit the screen size. 4:3: The default setting for a movie or normal broadcasting. Do not watch in 4:3 format for a long time. Traces of borders displayed on the left, right and centre of the screen may cause image retention (screen burn) which is not covered by the warranty.
Page 77 without any cut-off when HDMI (720p / 1080i / 1080p) or Component (1080i / 1080p) signals are inputted. Smart View 1: Reduces the 16:9 picture by 50% for LED TV Smart View 2: Reduces the 16:9 picture by 25% for LED TV Smart View 1 is enabled only in HDMI mode.
Page 78 The picture size can vary when you play content from Videos AllShare Play. Zoom/position Adjusts the picture zoom and position. Zoom is only available if Picture Size set to Zoom. Position is only available Picture Size is set to Wide Zoom, Zoom, or Screen...
Page 79 selecting Zoom, follow these steps: 1. Select Zoom. 2. On the Zoom/position screen, select Zoom, and then zoom in or zoom out using your remote. 3. When done, select Zoom again, and then select Close. 4. To reset the picture, press Reset. To use the Position function after selecting Wide Zoom, Zoom or Screen...
Page 80 Fit, follow these steps: 1. Select the Position. 2. On the Position screen, select Position, and then move the picture to position you want using your remote. 3. When done, select Position again, and then select Close. 4. To reset the picture position, select Reset.
Page 81 Picture Sizes available by Input Source: – ATV, AV: Auto Wide, 16:9, Wide Zoom, Zoom, – Component (480i, 480p, 576i, 576P): 16:9, Wide Zoom, Zoom, – DTV: Auto Wide, 16:9, Wide Zoom, Zoom, 4:3, Smart View 2 for LED TV –...
Page 82 – HDMI (720p, 1080i, 1080p): 16:9, Wide Zoom, Zoom, 4:3, Screen Fit, Smart View 1 Smart View for LED TV for LED TV Auto Wide function may not available depending on the country. Depending on the input source, the picture size options may vary. The available items may differ depending on the selected mode.
Page 83 1080i/1080p (1920x1080), 720p (1280x720) You can adjust and store settings for each external device you have connected to an input on the TV. Select the Source, and then adjust the settings. 4:3 Screen Size (Depending on the country) Available only when picture size is set to Auto Wide.
Page 84 desired picture size at the 4:3 WSS (Wide Screen Service) size or the original size. Each European country requires different picture size. Not available in Component or HDMI mode.
Page 85 Changing the Picture Options Advanced Settings Menu Picture Advanced Settings Using this function, you can configure advanced picture settings to create your preferred picture. Advanced Settings is available only when the Picture Mode is set to Standard Movie mode. When connecting a PC using an...
Page 86 HDMI-DVI cable, you can only make changes to White Balance Gamma. Dynamic Contrast Adjusts the screen contrast. Black Tone Select the black level to adjust the screen depth. Flesh Tone Emphasizes pink “Flesh Tone.” RGB Only Mode...
Page 87 Displays the Red, Green Blue colours so you can make fine adjustments to hue and saturation. Colour Space Adjusts the range and variety of colours (the colour space) available to create images. To adjust Colour, Red, Green, Blue and Reset, set the Colour Space Custom.
Page 88 Adjusts the colour temperature for a more natural picture. R-Offset G-Offset / B-Offset: Adjusts each colour’s (red, green, blue) darkness. R-Gain G-Gain / B-Gain: Adjusts each colour’s (red, green, blue) brightness. Reset: Resets the White Balance to its default settings. 10p White Balance Lets you control the white balance...
Page 89 by adjusting the red, green, and blue brightness in 10 point intervals. Available when the Picture Mode set to Movie. Available for all video source. Some external devices may not support this function. Interval: Select the interval to adjust. Red: Adjusts the red level. Green: Adjusts the green level.
Page 90 Reset: Resets the 10p White Balance its default settings. Gamma Adjusts the primary colour intensity. Expert Pattern Use the Expert Pattern function to calibrate the picture. If the OSD menu disappears or a menu other than the Picture menu is opened, the TV saves the calibration and the Expert Pattern screen disappears.
Page 91 Off: Turns the Expert Pattern function off. Pattern1: This test screen demonstrates the effect of your display settings on shades of grey and black. Pattern2: This test screen demonstrates the effect of your display settings on colours. After selecting Pattern1 or Pattern2, you can adjust any of the advanced settings for the desired effect.
Page 92 While the Expert Pattern is running, the TV does not output sound. Only enabled in Component, and HDMI modes. xvYCC Setting xvYCC on increases picture detail and enlarges the colour space when you are watching movies input from an external device (e.g. BD/DVD player) connected to the TV’s HDMI or Component IN jacks.
Page 93 Available only when you set Picture Mode Movie the external input to HDMI or Component. Some external devices may not support this function. Motion Lighting Reduces power consumption by reducing screen brightness when the picture on the screen is in motion. This feature is not supported in...
Page 94 mode. Only available in Standard mode. When you change the Backlight Cell Light for LED TV for PDP TV Contrast, or Brightness, the TV sets Motion Lighting to Off. Black enhancer for LED TV Adjust black colour depth to enhance picture perspective.
Page 95 Menu Picture Picture Options Using this function, you can configure additional picture settings to suit your preference. When your TV is connected to a PC via an HDMI to DVI cable, you can only make changes to Colour Tone. Colour Tone Select the colour temperature.
Page 96 Dynamic. You can adjust and store settings for each external device connected to an input on the TV. Select Source then adjust the settings. Digital Noise Filter If the broadcast signal received by your TV is weak, you can activate the Digital Noise Filter feature to reduce any static...
Page 97 Auto Visualisation: When changing analogue channels, displays signal strength. When the signal is weak, try all the options until the TV displays the best picture. Only available for analogue channels. When the bar is green, you are receiving the best possible signal. MPEG Noise Filter Reduces MPEG noise to provide...
Page 98 improved picture quality. HDMI Black Level Lets you adjust the screen depth by selecting a black level. Available only in HDMI mode. Film Mode Sets the TV so that it senses and then processes film signals from all sources automatically and adjusts the picture for optimum quality.
Page 99 / 1080i) and HDMI (1080i). Motion Plus for LED TV Removes drag from fast scenes with a lot of movement to provide a clearer picture. The Info screen on your TV displays the resolution and frequency of the incoming signal (60Hz), but not the frequency the TV is generating for the image it is displaying by using Motion Plus...
Page 100 If noise occurs on the screen, please set up the Motion Plus to Off. If Motion Plus is Custom, you can set up the Blur Reduction, Judder Reduction Reset manually. Motion Plus is Demo, you can compare the difference of on and off modes.
Page 101 reduction level from video sources when playing films. Reset: Reset the custom settings to the factory defaults. The info screen on your TV displays the resolution and frequency of the incoming video signal (60 Hz). This displayed frequency is not the frequency of the picture the TV is displaying when you have Motion...
Page 102 If noise occurs on the screen, please Motion Plus to Off. If Motion Plus is set to Custom, you can control Blur Reduction Judder Reduction manually and use Reset to reset both to their default settings. Motion Plus is set to Demo, you can compare the difference between a picture with Motion Plus On...
Page 103 Removes drag from fast scenes with a lot of movement to provide a clear picture. Reset Picture Menu Picture Reset Picture Resets your current picture mode to its default settings.
Page 104 Using the TV with Your PC Using Your TV as a Computer (PC) Display Entering the Video Settings (Based on Windows 7) For your TV to work properly as a computer display, you must enter the correct video settings after you have connected the TV to your PC.
Page 105 However, the same basic information will apply in most cases. (If not, contact your computer manufacturer or Samsung Dealer.) 1. Click “Control Panel” on the Windows start menu. 2. Click “Appearance and Themes”...
Page 106 in the “Control Panel” window. A display dialogue box appears. 3. Click “Display”. Another display dialogue box appears. 4. Click the “Settings” tab on the display dialogue box. – On the Settings tab, set the correct resolution (screen size). The optimal resolution for this TV is 1920 x 1080.
Page 107 exists on your display settings dialogue box, select “60” or “60 Hz”. Otherwise, just click “OK” and exit the dialogue box.
Page 108 Changing the Preset Sound Mode Sound Mode Menu Sound Sound Mode Sound modes apply preset adjustments to the sound. Speaker Select is set to External Speaker, Sound Mode is disabled. Standard Selects the normal sound mode. Music...
Page 109 Emphasizes music over voices. Movie Provides the best sound for movies. Clear Voice Emphasizes voices over other sounds. Amplify Increase the intensity of high-frequency sound to allow a better listening experience for the hearing impaired.
Page 110 Adjusting Sound Settings Sound Effect Menu Sound Sound Effect Speaker Select is set to External Speaker, Sound Effect is disabled. Available only when the Sound Mode is set to Standard. Virtual Surround This function provides a virtual 5.1 channel surround sound experience...
Page 111 through a pair of speakers using HRTF (Head Related Transfer Function) technology. Dialog Clarity This function allows you to increase the intensity of over background music or sound effects so that dialogue can be heard more clearly. Equaliser Equaliser displays a series of sliders.
Page 112 a slider, and then change the slider’s value. To Reset the Equaliser, select Reset. A pop-up appears asking if you want to reset. Select Yes. To exit, select Close. Balance L/R: Adjusts the balance between the left and right speaker. 100Hz 300Hz 1kHz...
Page 113 Reset: Resets the Equaliser to its default settings. 3D Audio Menu Sound 3D Audio 3D audio technology provides the immersive sound corresponding to the pop-up effect of 3D video by using audio depth control in perspective. Available only when watching 3D images.
Page 114 Broadcast Audio Options Menu Sound Broadcast Audio Options Audio Language (Digital channels only) Change the default value for audio languages. The available language may differ depending on the broadcast. Audio Format (Digital channels only)
Page 115 When sound is emitted from both the main speaker and the audio receiver, a sound echo may occur due to the decoding speed difference between the main speaker and the audio receiver. In this case, use the TV Speaker function. Audio Format option may differ depending on the broadcast.
Page 116 Audio Description (Not available in all locations) (Digital channels only) This function handles the Audio Stream for the AD (Audio Description) which is sent along with the Main audio from the broadcaster. Audio Description (Off / On): Turn the audio description function on or off.
Page 117 volume. Additional Settings DTV Audio Level (Digital channels only) This function allows you to reduce the disparity of a voice signal (which is one of the signals received during a digital TV broadcast) to a desired level. According to the type of broadcast signal, MPEG HE-AAC...
Page 118 adjusted between -10dB and 0dB. To increase or decrease the volume, adjust between the range 0 and -10 respectively. SPDIF Output SPDIF (Sony Philips Digital InterFace) is used to provide digital sound, reducing interference going to speakers and various digital devices such as a DVD player.
Page 119 You can select the Digital Audio output (SPDIF) format. The available Digital Audio output (SPDIF) format may differ depending on the input source. Audio Delay Lets you correct timing mismatches between the audio track and the video when you are watching the TV and listening to digital audio output from the TV through an external device such...
Page 120 as an AV receiver. When you select the Audio Delay function, a slider screen appears. Adjust the option value using your remote (0ms ~ 250ms). Dolby Digital Comp This function minimizes signal disparity between a dolby digital signal and a voice signal (i.e.
Page 121 between loud and soft sounds at night time. Line: Set the output level for signals greater or less than -31dB (reference) to either -20dB or -31dB. RF: Set the output level for signals greater or less than -20dB (reference) to either -10dB or -20dB. Speaker Settings Menu Sound...
Page 122 Speaker Select If you are listening to the sound track of a broadcast or movie through an external receiver, you may hear a sound echo caused by the difference in decoding speed between the TV’s speakers and the speakers attached to your audio receiver.
Page 123 are turned off. You will hear sound through the external speakers only. When the Speaker Select is set to Speaker, both the TV’s speakers and the external speakers are on. You will hear sound through both. When the Speaker Select is set to External Speaker, the volume buttons...
Page 124 If there is no video signal, both the TV’s speakers and the external speakers will be mute. Auto Volume Normal: Automatically equalizes the volume level when switching to another channel. Night: Automatically equalizes and decrease the volume level on each channel, so each channel is quieter.
Page 125 want to keep the volume low. To use the volume control of a connected source device, set Auto Volume to Off. If Auto Volume set to Normal or Night, adjusting the volume control of a connected source device may have to effect. Reset Sound Menu Sound...
Page 126 defaults.
Page 127 Connecting to the Network The Wired Network Connection There are three ways to attach your TV to your LAN using cable: For illustrations of the three kinds of wired network connections, see your paper user's manual. – You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external...
Page 128 modem using a LAN cable. – You can attach your TV to your LAN by connecting the LAN port on the back of your TV to router which is connected to an external modem. Use LAN cable for the connection. –...
Page 129 is attached to a modem or router elsewhere in your house. If you have a Dynamic Network, you should use an ADSL modem or router that supports the Dynamic Host Configuration Protocol (DHCP). Modems and routers that support DHCP automatically provide the IP address, subnet mask, gateway, and DNS values your TV needs to access the Internet so you do not have to...
Page 130 enter them manually. Most home networks are Dynamic Networks. Some networks require a Static IP address. If your network requires a Static IP address, you must enter the IP address, subnet mask, gateway, and DNS values manually when you set up the network connection. To get the IP address, subnet mask, gateway, and DNS values contact your Internet Service Provider (ISP).
Page 131 you have a Windows computer, you can also get these values through your computer. You can use ADSL modems that support DHCP if your network requires a Static IP address. ADSL modems that support DHCP also let you use Static IP addresses. The Wireless Network Connection For an illustration of the wireless...
Page 132 This TV supports the IEEE 802.11a/b/g and n communication protocols. Samsung recommends using IEEE 802.11n. When you play video over a network connection using IEEE 802.11 a/b or g, the video may not play...
Page 133 smoothly. To use a wireless network, your TV must be connected to a wireless router or modem. If the wireless router or modem supports DHCP, your TV can use a DHCP or static IP address to connect to the wireless network.
Page 134 wireless router or modem is currently being used by another device nearby, this will result in interference and communication failure. Your TV supports only the following wireless network security protocols: – Authentication Mode: WEP, WPAPSK, WPA2PSK – Encryption Type: WEP, TKIP, AES If you select the Pure High- throughput (Greenfield) 802.11n...
Page 135 Encryption type is set to WEP, TKIP on your AP (access point) or wireless router, Samsung TVs will not support a connection in compliance with new Wi-Fi certification specifications. If your wireless router or modem supports WPS (Wi-Fi Protected...
Page 136 Identification Number). WPS will automatically configure the SSID and WPA key in either mode. If your router, modem, or device is not certified, it may not connect to the TV. Connection Methods: You can set up the wireless network connection in four ways: –...
Page 137 – Using Manual Setup – Using WPS(PBC) – Using Plug & Access...
Page 138 Setting up a Wired Network Network Settings Menu Network Network Settings Set up the wired network connection so you can use various Internet services such as Smart Hub AllShare Play and perform software upgrades. Automatic Wired Network Setup You can configure your TV's wired...
Page 139 network connection automatically when connecting your TV to a network that supports DHCP. If you have connected a LAN cable, the wired network set up screen appears automatically. To set up your TV’s wired network connection automatically, follow these steps: 1.
Page 140 (Menu Network Network Settings) 2. Select Start. The network test screen appears and verifies the network connection. 3. When the connection has been verified, the "You are connected to the Internet. If you have any problems using online services, please contact your Internet service provider."...
Page 141 If the connection process fails, check the LAN port connection. If the automatic process cannot find the network connection values or if you want to set the connection manually, go to the next section, "Manual Network Setup." Manual Wired Network Setup You can configure your TV's wired...
Page 142 network connection manually when connecting your TV to a network that requires a Static IP address. Getting the Network Connection Values To view the Network connection values on most windows computers, follow these steps: 1. Right click the Network icon on the bottom right of the screen.
Page 143 click Status. 3. On the dialogue that appears, click the Support tab. 4. On the Support Tab, click the Details button. The Network connection values are displayed. To set up your TV's wired network connection manually, follow these steps: 1. Go to the Network Settings screen.
Page 144 (Menu Network Network Settings) 2. Select Start. The network connection screen appears and the verification process starts. 3. Select Stop. The verification process stops. Select IP Settings on network connection screen. The IP Settings screen appears. 4. Select the Mode, and then set the IP Mode to Manual.
Page 145 5. Go to the IP Address entry field, and then select the IP Address using the remote. 6. Enter the first portion of the Address (for example, 105) into the first entry field using your remote. When done, go to the next field. 7.
Page 146 field in the Address. If you make a mistake when entering a number, re-enter the number to correct it. 9. When done, go to the Subnet Mask fields. 10. Repeat the same entry process for Subnet Mask, Gateway, and Server. 11.
Page 147 verification process starts. When the connection has been verified, the "You are connected to the Internet. If you have any problems using online services, please contact your Internet service provider." message appears. Select OK. Network Status You can check the current network and Internet status.
Page 148 If the wired network connection failed... No network cable found. Check if your network cable is plugged in. If it is connected, make sure that the router is turned on. If it is on, try turning if off and on again. IP auto setting failed.
Page 149 1) Ensure that DHCP server is enabled on the router. 2) Unplug and re-plug- in the router. 3) Contact your Internet Service Provider for more information. Unable to connect to the network. Try the following: check if your IP address is set correctly in Settings.
Page 150 Check the DNS settings in IP Settings or contact your Internet Service Provider to access the Internet. Network setup complete, but cannot connect to the Internet. Contact your Internet Service Provider to access the Internet.
Page 151 Setting up the Wireless Network Network Settings Menu Network Network Settings Set up the wireless network connection so you can use various Internet services such as Smart Hub AllShare Play and perform software upgrades. Automatic Wireless Network Setup Most wireless networks have an...
Page 152 optional security system that requires devices that access the network to transmit an encrypted security code called an Access or Security Key. The Security Key is based on a Pass Phrase, typically a word or a series of letters and numbers of a specified length you were asked to enter when you set up security for your wireless network.
Page 153 Security Key for your wireless network, you will have to enter the Pass Phrase during the automatic or manual setup process. Depending on your router or modem, you may be able to use a WPS PIN instead. To set up your TV’s wireless network connection automatically, follow these steps:...
Page 154 1. Go to the Network Settings screen. (Menu Network Network Settings) 2. Select Start. The network function searches for available wireless networks. When done, it displays a list of the available networks. 3. In the list of networks, select a network you want to connect to and then select Next.
Page 155 Hidden (Invisible), you have to select Add Network and enter the correct Network Name (SSID) Security Key to establish the connection. 4. If the Enter security key screen appears, go to step 5. If you selected a wireless router that does not have security, go to step 7.
Page 156 keyboard on the Enter security key screen. To enter letters, highlight and select each letter. To enter numbers, highlight and select each number or press the number buttons on your remote. To shift to capital letters (or from capital letters to lower case), select the Caps Shift...
Page 157 punctuation, select . To redisplay letters, select again. You should be able to find the Pass Phrase on one of the set up screens you used to set up your router or modem. 6. When done, select Next if you entered a Security Key or WPS PIN if you entered a PIN.
Page 158 7. When the connection has been verified, the “You are connected to the Internet. If you have any problems using online services, please contact your Internet service provider.” message appears. If the network does not accept the Security Key or PIN, select Retry or select IP Settings...
Page 159 manually, select Settings. Then, go to the next section, “Manual Network Setup”. Manual Wireless Network Setup You can configure your TV's wireless network connection manually when connecting your TV to a network that requires a Static IP address or if the automatic connection process has failed.
Page 160 Getting the Network Connection Values To view the Network connection values on most Windows computers, follow these steps: 1. Right click the Network icon on the bottom right of the screen. 2. In the pop-up menu that appears, click Status. 3.
Page 161 4. On the Support Tab, click the Details button. The Network connection values are displayed. To set up your TV's wireless network connection manually, follow these steps: 1. Go to the Network Settings screen. (Menu Network Network Settings) 2. Select Start. The network function...
Page 162 searches for available wireless networks. When done, it displays a list of the available networks. 3. In the list of networks, select a network you want to connect to and then select Next. If the wireless router is set to Hidden (Invisible), you have to select Add Network...
Page 163 connection. 4. If the Enter security key screen appears, go to step 5. If you selected a wireless router that does not have security, go to step 7. 5. To set up wireless security, enter the Security Key or a WPS PIN using the keyboard on the Enter security key...
Page 164 numbers, highlight and select each number or press the number buttons on your remote. To shift to capital letters (or from capital letters to lower case), select the Caps Shift button. To display symbols and punctuation, select . To redisplay letters, select again.
Page 165 screens you used to set up your router or modem. 6. When done, select Next if you entered a Security Key or WPS PIN if you entered a PIN. The network connection screen appears and the verification process starts. 7. Select Stop. The verification process stops.
Page 166 8. Select Mode, and then set the Mode to Manual. 9. Go to the IP Address entry field, and then select the IP Address using the remote. 10. Enter the first portion of the Address (for example, 105) into the first entry field using your remote.
Page 167 field. 12. Repeat the entry process for each field in the Address. If you make a mistake when entering a number, re-enter the number to correct it. 13. When done, go to the Subnet Mask fields. 14. Repeat the same entry process for Subnet Mask, Gateway, and Server.
Page 168 15. When done, select OK. The network connection screen appears and the verification process starts. When the connection has been verified, the "You are connected to the Internet. If you have any problems using online services, please contact your Internet service provider."...
Page 169 button, you can configure your TV's wireless network connection using the WPS(PBC) button quickly and easily. To set up your TV's wireless network connection using WPS(PBC), follow these steps: 1. Go to Network Settings screen. (Menu Network Network Settings). 2. Select Start. The Network function...
Page 170 searches for available wireless networks. When done, it displays a list of the available networks. 3. Select the WPS(PBC). 4. Press the WPS(PBC) button on your router within 2 minutes. Your TV automatically acquires all the network setting values it needs and connects to your network.
Page 171 Plug & Access Network Setup Plug & Access function lets you easily connect your Samsung TV to your Samsung wireless router(sold separately) by using a USB memory stick to transfer the setup information from the router to the TV. If your...
Page 172 Plug & Access on www. samsung.com. To set up your TV's wireless network connection using Plug & Access, follow these steps: 1. Turn on the Samsung wireless router and your TV. 2. Insert a USB memory stick into the...
Page 173 (Blinking on). 3. Take the USB memory stick out of the router, and then insert it into a USB port on your Samsung TV. The memory stick downloads the connection information. 4. Wait until the connection is automatically established.
Page 174 your TV to your wireless router, a popup screen appears on the screen notifying you of the failure. If you want to try using Plug & Access again, disconnect the USB memory stick, reset the router, and then try again from Step 1. You can also choose one of the other connection setup methods.
Page 175 done. If the wireless router’s settings change or you install a new wireless router, you must perform the Plug & Access procedure again, beginning from Step 1. Network Status You can check the current network and Internet status.
Page 176 If the wireless network connection failed... Wireless network connection failed. No wireless router selected. Go to Network Settings to select your router. Unable to connect to wireless router. Try the following: check if the router is turned on, and if it is, try turning it off and on again.
Page 177 automatically or set your IP address manually by selecting Settings'. 1) Ensure that DHCP server is enabled on the router. 2) Unplug and re-plug- in the router. 3) Contact your Internet Service Provider for more information. Unable to connect to the network. Try the following: check if your IP address is set correctly in Settings.
Page 178 Connected to your local network, but cannot connect to the Internet. Check the DNS settings in Settings, or contact your Internet Service Provider to access the Internet. Network setup complete, but cannot connect to the Internet. Contact your Internet Service Provider to access the Internet.
Page 179 Managing the Network Connected Devices Wi-Fi Direct Menu Network Wi-Fi Direct Set to connect the TV to wireless mobile devices. Using this function, you can connect wireless mobile devices to your TV directly without a router. To use this function, your mobile device should be supported by the Wi-Fi Direct.
Page 180 To connect your mobile device with your TV using Wi-Fi Direct, follow these steps: 1. Turn on the Wi-Fi Direct device and activate its Wi-Fi Direct function. 2. Go to the Wi-Fi Direct screen. (Network Wi-Fi Direct) The TV starts to search devices, and then displays the devices on the Wi-Fi Direct...
Page 181 3. Turn on the Wi-Fi Direct function on your device. Select the desired Wi-Fi device. – For PBC: Press the WPS(PBC) button on your Wi-Fi device within 2 minutes. The Connecting popup appears, followed by the Connected pop-up. When it closes, you should see the device listed on the Wi-Fi Direct...
Page 182 – For PIN: Input the displayed PIN number on your device. The Connecting popup appears, followed by the Connected pop- up. When it closes, you should see the device listed on the Wi-Fi Direct screen as connected. If you want to disconnect the device, select the connected Wi-Fi device, and then select Disconnect.
Page 183 Soft AP Menu Network Soft AP Using this function, you can connect the TV to your mobile devices if your mobile device does not support Wi-Fi Direct. Soft AP screen lets you set the options for connecting Wi-Fi devices. Soft AP Turns Soft AP on or off.
Page 184 is set to On, your mobile devices can find the TV's network name in their Wi- Fi connection list. Security Key Enter a Security Key at least 8 characters long using the remote control. Select Done when finished. – If the security key is not at least 8 characters long, Done is not...
Page 185 TV, you must input the security key into the device. – If network does not operate correctly, check the security key again. An incorrect security key may cause a malfunction. AllShare Settings Menu Network AllShare Settings AllShare Play lets you play Videos, Photos, or Music located on your PC or...
Page 186 your DLNA compatible device on the TV using a network connection. It also lets you control the TV through these devices. AllShare Settings screen lists your network connected AllShare devices and their IP addresses. Through this screen, you can allow a device to access the TV, deny access, or delete the device from the AllShare list.
Page 187 displays devices if you have established networked connections to AllShare devices. Otherwise, it will be empty. To use the AllShare network function, you must install the AllShare network software on your PC. For details on set up options, refer to "Using the AllShare Play Functions".
Page 188 Enter a name for this TV. This name will be shown on network remote controls and devices using AllShare Play. A keyboard appears on the screen. Key in a name for your TV manually using your remote. When finished, select Done. To enter letters, highlight and select each letter.
Page 189 remote. To shift to capital letters (or from capital letters to lower case), select Caps Shift button. To display symbols and punctuation, select . To redisplay letters, select again.
Page 190 Setting the Time Time Menu System Time The time you set will appear when you press the INFO button for Standard or select Info Remote Control for Smart Touch Control Clock Set the clock to use the various timer features of the TV.
Page 191 If you disconnect the power cord, you have to set the clock again. Clock Mode: Set the current time manually or automatically. – Auto: The TV sets the current time automatically using the time from a digital channel. You must have the cable or an antenna connected to the TV to set the time automatically.
Page 192 station and signal, the auto time set up may not be correct. In this case, set the time manually. – Manual: Set the current time manually. Clock Set: Set the Date Time manually. You can set the current date and time using your remote. Available only when the Clock Mode is set to Manual.
Page 193 Time Zone function may not be supported depending on the region. This function is only available when Clock Mode is set to Auto. Sleep Timer Automatically shuts off the TV after a preset period of time. (30, 60, 90, 120, 150, or 180 minutes).
Page 194 On Timer On Timer so that your TV turns on automatically at a time and on a day of your choosing. You can set up three separate On Timer configurations(On Timer On Timer On Timer 3) and select the source of the content the TV plays when it turns on: an air or cable channel, a USB device, or a set-top box connected to one of the TV's inputs...
Page 195 You must set the clock before you can use the On Timer function. Setup: Select Off, Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun or Manual. If you select Manual, you can choose the days you want On Timer to turn on your TV. mark indicates days you’ve selected.
Page 196 Volume: Set the desired volume level. Change the volume level using your remote. Source: To select the source of the content that will play when the TV turns on. You can: – Select and have the TV display a specific air or cable channel. –...
Page 197 – Select a source on your TV (HDMI1, HDMI2, Component, etc.) that you have connected a set-top box to, and have the TV display a channel from the set-top box. The USB device must be connected to your TV before you can select USB.
Page 198 box attached to that source Set the set-top box to the channel you want to watch when the TV goes on. Leave the set-top box turned on. When you select a source other than Aerial Channel options will disappear. Aerial (when the Source is set to TV):...
Page 199 Select the desired channel. Music Photo (when the Source is set to USB): Select a folder in the USB device that contains music that you want played when the TV turns on automatically or a folder that contains music and a folder that contains photo files.
Page 200 follow these steps: 1. Select Music. The TV displays a single folder (the Root folder) and the type or name of the device. 2. Select the type or name of the device you want to play. A list of folders on the selected device appears.
Page 201 appears with the name of the device in the Music field. Go to Step 4. 3. Highlight a folder that contains music, highlight the Select next to it. The Timer screen re-appears with the folder name in the Music field. 4.
Page 202 5. When done, select the Close at the bottom of the screen. You must select a music file. You cannot select only a photo file. If there is no music file on the USB device or you don’t select a folder containing a music file, the Timer function does not operate correctly.
Page 203 folder cannot be selected. Each USB you use is assigned its own folder. When using more than one of the same types of USB, make sure the folders assigned to each USB have different names. We recommend that you use a USB memory stick and a multi card reader when using the Timer.
Page 204 battery, MP3 players, or PMPs made by some manufacturers because the TV can take too long to recognize these devices. If you set the On Timer to play a file saved on a USB HDD, it may take up to 40 seconds or more to play the file after the TV is turned on.
Page 205 of your choosing. You can set up three separate Off Timer configurations. (Off Timer Off Timer Off Timer You must set the clock before you can use the Timer. Setup: Select Off, Once, Everyday, Mon~Fri, Mon~Sat, Sat~Sun or Manual. If you select Manual, you can choose the days you want Off Timer to turn off...
Page 206 selected. Time: Set the time that the TV turns off automatically.
Page 207 Blocking Programmes Security Menu System Security Using this function, you can configure programme related security options. Every time you access the Security functions, the PIN screen will appear and you must enter that PIN. The PIN screen closes and the Security menu appears.
Page 208 Channel Lock Lock channels in Channel menu, to prevent unauthorized users, such as children, from watching unsuitable programme. Available only when the Source set to TV. Programme Rating Lock (Depending on the country) When turned on, the Programme Rating Lock feature can automatically...
Page 209 block programmes that you deem inappropriate for your children. You must enter a PIN (personal identification number) before you can set or change any of the Programme Rating Lock restrictions. The items of Programme Rating Lock differs depending on the country. Change PIN Change PIN screen will appear.
Page 210 enter them in the Enter New PIN. Re- enter the same 4 digits in the Confirm PIN. When the Confirm screen disappears, select Cancel. The TV has memorised your new PIN. How to watch a restricted programme or movie If the TV is tuned to a restricted programme or movie, the Programme Rating Lock...
Page 211 The screen will go blank and the message This channel is blocked by Channel lock settings. Please enter PIN to unblock. appears. Enter the PIN to unblock the programme or movie using your remote.
Page 212 Economical Solutions Eco Solution Menu System Eco Solution Energy Saving Lets you adjusts the brightness of the TV in order to reduce power consumption. If you select Picture Off, the screen is turned off, but the sound remains on. Press any button except the volume button to turn on the...
Page 213 screen. Eco Sensor To enhance your power savings, the picture settings will automatically adapt to the light in the room. If you adjust Backlight for LED TV Cell Light in the Picture for PDP TV menu, the Eco Sensor is set to automatically.
Page 214 is set to On, you can manually adjust the minimum screen brightness. If the Eco Sensor is set to On, the display brightness may change (become slightly darker or brighter) depending on the surrounding light intensity. You can control the screen’ s minimum brightness with the Min.
Page 215 To avoid unnecessary energy consumption, you can set how long you want the TV to remain on if it’s not receiving a signal. Auto Power Off The TV will automatically turn off if you don’t press a button on your remote or TV controller within 4 hours to prevent overheating.
Page 216 Picture In Picture (PIP) Menu System You can watch a programme whose signal has passed through the TV’s tuner and watch video from one external video source simultaneously. If you have a Blu-ray player connected to the TV, for example, you can watch a TV programme and the Blu-ray movie...
Page 217 at the same time by using the PIP feature. While Smart Hub Programme Rating Lock is on, you cannot use the PIP. Activate or deactivate the function. Channel Select the channel for the sub-picture screen. Size...
Page 218 Select a size for the sub-picture screen. Position Select a position for the sub-picture screen. à Œ In Double ( ) mode, you cannot select Position. Sound Select You can choose to listen to the sound from the main picture or the sub picture.
Page 219 in the mode, the function is reset to Off. When you turn your TV on, you must turn on again to watch in the mode. You may notice that the picture in screen becomes slightly unnatural when you use the main screen to view a game or karaoke.
Page 220 external video source will be in the main screen and the picture from the TV’s tuner will be in the sub- picture screen. – Main picture: Component, HDMI – Sub picture: TV...
Page 221 Other Features Language Menu System Language Teletext Language Set a desired language for teletext. English is the default in cases where the selected language is unavailable in the broadcast. Preferred Language Select a language, which will be the...
Page 222 default language when a channel is selected. Device Manager Using this function, you can set up a keyboard or mouse to use with the TV. You can view your device lists and adjust keyboard or mouse settings in this menu. Depending on the model of the USB HID keyboard and mouse may not be...
Page 223 compatible with your TV. You can connect a keyboard and mouse at the same time. Keyboard settings Lets you use a USB or Bluetooth keyboard with your TV. If you want to use a USB keyboard, connect it to the USB port. If you want to use a Bluetooth keyboard, connect it using the Bluetooth function.
Page 224 QWERTY keypad screen appears in the Browser. Select keyboard Select which keyboard to use from your keyboard list. You can only use one keyboard at a time, even if several are connected. Add Bluetooth Keyboard You can add a Bluetooth keyboard. Keyboard Options Sets the default options for the...
Page 225 keyboard language and type. – Keyboard Language: Set a language for your keyboard. – Keyboard type: Set what a type of keyboard you're using to enter text. – Switch Input Language: Select a key sequence to change switching input language. Mouse settings Lets you use a USB or Bluetooth mouse with your TV.
Page 226 mouse, connect it to the USB port. If you want to use a Bluetooth mouse, connect it using the Bluetooth function. You can use a mouse in the TV's menu in the same way you use a mouse on your PC. Select mouse Select which mouse to use from your mouse list.
Page 227 Add Bluetooth mouse You can add a Bluetooth mouse. Mouse Options Sets the default options for the mouse buttons. – Primary Button: Select the main button you want to use to click and select on screen. – Pointer Size: Set the size of the on- screen mouse pointer.
Page 228 the mouse pointer. Using the TV's menu with a mouse 1. Connect a USB or Bluetooth mouse on your TV. 2. Click a primary button you selected. Mouse Tools pop-up appears. 3. Select Smart Hub Menu 4. Use the mouse the same way you would use a mouse on your computer.
Page 229 Channel on the Smart Hub screen, click the Channel icon. To exit an entry field that does not close, click Return. To exit a menu or Smart Hub screen, click Return. To hide the mouse pointer, move it slightly off the bottom of the screen. Subtitle (On-Screen Text Messages)
Page 230 Menu System Subtitle Use this menu to set the Subtitle mode. Subtitle Switches subtitles on or off. Subtitle Mode Sets the subtitle mode. Subtitle Language Sets the subtitle language. If the programme you are watching does not support the Hearing Impaired function, Normal...
Page 231 automatically activates even if the Hearing Impaired mode is selected. English is the default in cases where the selected language is unavailable in the broadcast. Digital Text Digital Text function may not be supported depending on the region. If the programme broadcasts with digital text, this feature is enabled.
Page 232 MHEG (Multimedia and Hypermedia Information Coding Experts Group): An International standard for data encoding systems used in multimedia and hypermedia. This is at a higher level than the MPEG system which includes data-linking hypermedia such as still images, character service, animation, graphic and video files as well as multimedia data.
Page 233 applied to various fields including VOD (Video-On-Demand), ITV (Interactive TV), EC (Electronic Commerce), tele- education, tele-conferencing, digital libraries and network games. Screen Burn Protection for PDP TV To reduce the possibility of screen burn, this unit is equipped with Pixel Shift screen burn prevention technology.
Page 234 the screen. The Pixel Shift Time setting allows you to programme the time between movements of the picture in minutes. Your TV also has the following additional screen burn protection functions: – Pixel Shift – Auto Protection Time – Scrolling –...
Page 235 Pixel Shift Using this function, you can set the TV to move pixels minutely on the PDP screen in a horizontal or vertical direction to minimize after images on the screen. Available Pixel Shift settings and optimum settings: Horizontal – Available Settings: 0 – 4 (pixels)
Page 236 – Optimum settings for TV/AV/ Component/HDMI: 4 Vertical – Available Settings: 0 – 4 (pixels) – Optimum settings for TV/AV/ Component/HDMI: 4 Time (minutes) – Available Settings: 1 – 4 min – Optimum settings for TV/AV/ Component/HDMI: 4 min Pixel Shift value may differ...
Page 237 depending on the monitor size (inches) and mode. This function is not available in Screen Fit mode. Auto Protection Time If the screen displays a still image for a certain period of time you define, the TV activates the screen saver to prevent the formation of burnt in ghost images on the screen.
Page 238 This function removes after-images on the screen by illuminating all the pixels on the screen according to a pattern. Use this function when there are after images or symbols on the screen, especially when you displayed a still image on the screen for a long time. The after-image removal function has to be executed for a long time (approximately 1 hour) to effectively...
Page 239 If the after-image is not removed after you apply the function, repeat the function. Press any button to cancel this feature. Side Grey When you watch TV with the screen ratio set to 4:3, using the Side Grey function can prevent damage to the edges of the screen by adjusting the white balance on the extreme left and...
Page 240 right sides. Auto Protection Time for LED TV If the screen displays a still image for a certain period of time you define, the TV activates the screen saver to prevent the formation of burnt in ghost images on the screen. General Menu System...
Page 241 Game Mode When you have connected a game console such as a PlayStation™ or Xbox™ to the TV, you can enjoy a more realistic gaming experience if you set the Game Mode Precautions and limitations for Game Mode – Before disconnecting a game console and connecting another external...
Page 242 device, set Game Mode to Off. – If you display the TV menu in Game Mode, the screen shakes slightly. Game Mode is not available when the input source is set to TV. Game Mode only after connecting a game console. If you turn Game Mode on before you have...
Page 243 Mode is set to Movie automatically. BD Wise Provides the optimal picture quality for Samsung DVD, Blu-ray, and Home Theatre products which support Wise. When the BD Wise is set to On, the picture mode is automatically changed to the optimal resolution.
Page 244 Wise through an HDMI cable to the Menu Transparency Adjust transparency of menu box. Sound Feedback Your TV gives sound feedback when you use TV. Sound Feedback is enabled by default. Turn off Sound Feedback adjust its volume. Panel Lock Lock or unlock all the keys on the front...
Page 245 When Panel Lock is on, none of the keys on the front panel operate. Boot Logo Displays the Samsung logo when the TV is turned on. Anti Flicker Remove flickering by adjusting camera power-line frequency. Light Effect...
Page 246 LED is too bright for you. Set the Light Effect to reduce the power consumption. The colour of light may vary depending on the model. Anynet+ (HDMI-CEC) Menu System Anynet+ (HDMI-CEC) Allows you to control all connected Samsung devices that support anynet+...
Page 247 Samsung TV’s remote. For details on set up options, refer to the “Anynet+ (HDMI-CEC)” instructions. DivX® Video On Demand Menu System DivX® Video On Demand Shows the registration code authorized for the TV. If you connect to the DivX...
Page 248 registration code, you can download the VOD activation file. Once you play it using AllShare Play, the registration is completed. For more information on DivX(R) VOD, visit http://vod.divx.com.
Page 249 Support Menu e-Manual Menu Support e-Manual The e-Manual is built into your TV. Open the e-Manual to learn how to use your TV are many features. For the detailed information about the e-Manual Screen, refer to “How to view the e-Manual” in the User’s Manual.
Page 250 Self Diagnosis Menu Support Self Diagnosis Picture Test Use to check for picture problems. Picture Test displays a high definition picture that you can examine for flaws or faults. Yes: Select if the test picture does not appear or there is noise or distortion in the test picture.
Page 251 TV. Contact Samsung’s Call Centre for assistance. No: Select if the test picture displays properly. There may be a problem with your external equipment. Please check your connections. If the problem persists, refer to the external device’s user manual.
Page 252 If you hear no sound from the TV’ s speakers, before performing the sound test, make sure Speaker Select is set to TV Speaker in the Sound menu, and then try the speakers again. You will hear the melody during the test even if you have set Speaker Select...
Page 253 There may be a problem with the TV. Contact Samsung’s Call Centre for assistance. No: Select if you can hear sound from the speakers. There may be a problem with your external equipment.
Page 254 (Digital channels only) The reception quality of over-the- air HD channels is either perfect or the channels are unavailable. Signal Information displays HD channel signal strength so you can adjust your antenna to increase signal strength and receive HD channels. Reset Reset all setting to factory defaults except for your network settings.
Page 255 To reset your TV to its default settings, follow these steps: 1. Go to the Reset menu. (Support Self Diagnosis Reset) 2. The PIN input screen appears. Enter the four digit security PIN using your remote. If you have not changed the PIN, enter the default PIN, 0-0-0-0.
Page 256 Change PIN option.(System Security Change PIN) 3. When done, the PIN screen disappear. The message "All settings, except network settings, will return to factory defaults." appears. 4. Select Yes. All settings are reset. The TV will turn off and on again automatically.
Page 257 Troubleshooting If your TV seems to be having a problem, access the troubleshooting guide for a solution. Software Update Menu Support Software Update Software Update menu lets you upgrade your TV’s software to the latest version. Current Version: This is the software...
Page 258 version already installed in the TV. Upgrading to the Latest Version you can upgrade in five ways: – By USB – Online – By Channel (Depending on the country) – Alternative Software – Standby Mode Upgrade The five methods are explained in the...
Page 259 following pages. Be careful not to turn off the power until the upgrade is complete. The TV will turn off and on automatically after completing the software upgrade. When you upgrade software, all video and audio settings you have made will return to their default settings.
Page 260 By USB To upgrade the By USB, follow these steps: 1. Visit www.samsung.com. 2. Click Support at the top of the page. 3. On the Support page, enter your model number in the Find Your Product field, and then press Enter or...
Page 261 4. Under Downloads on the left side, click Get downloads. The Download Center screen appears. 5. Click Firmware on the left side of the page. 6. On the Firmware tab, click the file icon on the right, and then click Save File on the pop-up that appears.
Page 262 exe file. 8. Copy the folder to a USB flash drive. 9. Turn on the TV, and then insert the USB flash drive into the USB port of the TV. 10. In the TV’s menu, go to Support Software Update. 11.
Page 263 Online Online function lets you download the upgrade software directly from the Internet into your TV and then upgrade the software in one operation. To use Online, you must have configured your TV to connect to your network and the TV must be connected to the Internet.
Page 264 To upgrade using the Online, follow these steps: 1. Select the Online. The Connecting to Server message appears. 2. If there is a download available, the Download popup appears with a progress bar and the download starts. 3. When the download is complete, the Upgrade Query screen appears with three choices: Upgrade...
Page 265 Upgrade Later, or Don't Upgrade. – If you select Upgrade Now, the TV upgrades the software, turns off, and then turns on automatically. – If you do not make a selection in one minute or select Upgrade Later, the TV stores the new upgrade software.
Page 266 TV cancels the upgrade. By Channel (Depending on the country) Upgrade the software using the broadcasting signal. If the function is selected during the software transmission period, software will be automatically searched and downloaded. The time required to download the software is determined by the signal...
Page 267 status. Alternative Software Alternative Software option lets you upgrade using a file the TV downloaded earlier, but you decided not to install immediately, or a file downloaded by the TV in Standby Mode (See Standby Mode Upgrade the next section). To upgrade using Alternative Software,...
Page 268 follow these steps: 1. If upgrade software has been downloaded, you will see the software version number to the right Alternative Software. 2. Select Alternative Software. 3. The TV displays a message asking if you want to upgrade. Select Yes. The TV begins the upgrade.
Page 269 turns on. Standby Mode Upgrade You can set the Standby Mode Upgrade function so that the TV downloads new upgrade software when it is in Standby mode. In Standby mode, the TV is off, but its Internet connection is active. This allows the TV to download upgrade software automatically, when you are not using it.
Page 270 on internally, the screen may glow slightly. This phenomenon may continue for more than 1 hour until the software download is complete. To set Standby Mode Upgrade, follow these steps: 1. Select the Standby Mode Upgrade. 2. Select Off, 1 hour later, 2 hours later,...
Page 271 2:00 12:00 / 14:00: The TV will notify you with a pop up message when new upgrade software is available. – On: If you select On, the TV will automatically download new upgrade software when it is in Standby mode with the power off. To use the Standby Mode Upgrade function, your TV must be connected...
Page 272 Contact Samsung Menu Support Contact Samsung View this information when your TV does not work properly or when you want to upgrade the software. You can find information regarding our call centres and how to download products and software. Remote Management...
Page 273 Menu Support Remote Management Remote Management lets our Call Center access and control your Samsung Product remotely to troubleshoot a problem. Use Remote Management only when you have a problem, and contact our Call Center first, before you activate Remote Management.
Page 274 Contact support. Smart Hub Menu Support Smart Hub Smart Hub lets you connect to the Internet and enjoy a variety of Internet and multimedia contents. For more information on how to use the Smart Hub, see “Smart Hub” in the e-Manual.
Page 275 Using the 3D function Menu Picture This exciting new feature enables you to view 3D content. To fully enjoy this feature, you must need a pair of Samsung 3D Active Glasses to view 3D video. IMPORTANT HEALTH AND SAFETY...
Page 276 INFORMATION FOR 3D PICTURES. Read and understand the following safety information before using the TV’s 3D function. Warning Some viewers may experience discomfort while viewing 3D TV such as dizziness, nausea and headaches. If you experience any such symptom, stop viewing 3D TV; remove the 3D Active Glasses and rest.
Page 277 period of time may cause eye strain. If you feel eye strain, stop viewing 3D TV; remove your 3D Active Glasses and rest. A responsible adult should frequently check on children who are using the 3D function. If there are any reports of tired eyes, headaches, dizziness, or nausea, have the child stop viewing 3D TV and rest.
Page 278 for other purposes (such as general eyeglasses, sunglasses, protective goggles, etc.) Do not use the 3D function or 3D Active Glasses while walking or moving around. If you use the 3D function or 3D Active Glasses while walking or moving around you can injure yourself by running into objects, tripping, or falling.
Page 279 Select the 3D input format. If you want to experience the 3D effect fully, put the 3D Active Glasses on first, and then select the 3D Mode from the list below that provides the best 3D viewing experience. : Turns the 3D function off. Of f Of f : Changes a 2D image to 3D.
Page 280 : Displays the images for for LED TV the left and right eye alternately in rows. : Displays the images for for LED TV the left and right eye alternately in columns. : Displays the images for for LED TV the left and right eye alternately in pixels.
Page 281 frames. 3D Mode may differ depending on the input signal. Some file formats may not support are available when your PC is connected through an HDMI/DVI cable. displays the frequency (60Hz only) when the TV’s resolution is 1920 x 1080.
Page 282 3D Effect for LED TV Adjust 3D effects like perspective and depth for your preferred 3D viewing experience. Effect: Adjust the perspective and depth settings. If you select Auto, the TV adjusts the perspective and depth settings automatically in accordance with the 3D input source.
Page 283 Perspective: Adjusts the overall 3D perspective of the on-screen image. Depth: Adjusts the overall depth. 3D Perspective for PDP TV Adjusts the overall 3D perspective of the on-screen image. Depth for PDP TV Adjusts the overall depth. L/R Change Swaps the left and right pictures.
Page 284 Displays the image for the left eye only. This function is deactivated when the 3D Mode set to Of f Of f 3D Auto View for LED TV If you set the 3D Auto View On, TV will switches the TV to 3D automatically.
Page 285 remote. When you run some applications (such as Smart Hub, etc.), TV will not switch to 3D. To switch to 3D, you must exit the application first. 3D Optimisation for LED TV Automatically adjusts the picture overall to provide an optimal 3D effect. Support resolution (16:9 only)
Page 286 HDMI 3D Format Resolution Frequency (Hz) 1280 x 720p 50 / 59.94 / 60 Hz 1920 x 1080i 50 / 59.94 / 60 Hz 1920 x 1080p 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60 Hz 1280 x 720p 50 / 59.94 / 60 Hz 1920 x 1080i...
Page 287 Resolution Frequency (Hz) 1280 x 720p 50 / 59.94 / 60 Hz 1920 x 1080i 50 / 59.94 / 60 Hz 1920 x 1080P 25 Hz Videos / Photos (In AllShare Play) Refer to "Supported Subtitle and AllShare™ file formats" in the Other Information section.
Page 288 for LED 7000 Series and above The optimal resolution for 3D in the HDMI PC mode is 1920 x 1080. If the input resolution is not 1920 x 1080, the TV may not display images properly in 3D display or full screen mode.
Page 289 source. To watch in 3D, you must wear 3D Active Glasses and turn the glasses on by pressing the power button. 1. Go to the screen. (Picture 2. Select the Mode, The 3D Mode screen appears. 3. Set the 3D Mode of the image you want to view.
Page 290 Smart Hub function. 3D Mode is set to its memorised configuration value automatically when you change the input source. Some Picture functions are disabled mode. is not supported in mode. 3D Active Glasses from Samsung’s...
Page 291 previous IR type 3D products and 3D glass from other manufacturers are not supported. When the TV is initially powered on, it may take some time until the 3D display is optimized. The 3D Active Glasses may not work properly if there is any other 3D product or electronic device turned on near the glasses or TV.
Page 292 devices as far away as possible from the 3D Active Glasses. Be sure to stay within the viewing angle and optimum TV viewing distance when watching 3D pictures. Otherwise, you may not be able to see 3D effects properly. The ideal 3D viewing distance is three times or more the height of the screen.
Page 293 least six feet from the screen. We recommend sitting so that your eyes are level with the screen.
Page 294 Smart Hub Menu Support Smart Hub Using Smart Hub, you can stream movies, videos, and music from the Internet, access various for pay or free- of-charge applications and view them on your TV. Application content includes news, sports, weather forecasts, stock market quotes, maps, photos, and games.
Page 295 ™ pressing the button on the remote control. Notice Samsung Electronics takes no legal responsibility for any interruption of the Smart Hub service caused by the service provider for any reason. Application services may be provided in English only and the contents...
Page 296 your area. For more information about a Smart Hub service, visit the web site of the applicable service provider. The Smart Hub service downloads and processes data via the Internet so that you can enjoy the Internet contents on your TV screen. If the Internet connection is unstable, the service may be delayed or interrupted.
Page 297 player may turn off automatically in response to conditions on the Internet. If this occurs, check the Internet connection and try again. The services provided are subject to change by the Smart Hub service provider without notice. The Smart Hub service contents may differ depending on the player’s firmware version.
Page 298 protection can only be played through composite, a component or HDMI cable. If the TV displays these icons at the bottom left of the screen, you can use corresponding functions: Voice Control (System Voice and motion control Voice Control) Motion control (System Voice and motion control Motion control)
Page 299 : An USB or Bluetooth Mouse (the device must connected to the TV). (System Device Manager Mouse settings) To start Smart Hub for the first time, follow these steps: ™ 1. Press the button. 2. The Smart Hub screen appears. 3.
Page 300 Screens can take a few seconds to appear. 4. The Samsung Service Privacy policy screen appears. Select Agree. 5. The Update Pop-up appears. Select 6. The Service Update screen appears and installs a number of services and applications. When done, it closes.
Page 301 services. This may take some time. Smart Hub may close momentarily during the installation process. A number of screens may appear after installation. You can close them or let them close on their own. 7. To start an application, select an application using your remote.
Page 302 A number of Smart Hub applications display a numeric keypad or a QWERTY keyboard so you can enter account names, passwords, and other data. In most applications, you can toggle between the numeric keypad and the QWERTY keyboard by selecting the button.
Page 303 can use your remote to enter letters in lower or upper case, numbers, punctuation, and symbols. There are two ways to enter characters, in the ABC mode and in the XT9 mode. Method 1 : Using the keypad of ABC type.
Page 304 input mode from lower case to numbers. 2. Select 1, in numerical order on your remote. 3. Select the TTX/MIX key three times using your remote to change the input mode from numbers to upper case. 4. Select three times using your remote to input C.
Page 305 using your remote to change the input mode from upper case to lower case. 6. Input the rest of “Chang” using your remote in the same way. When done, select OK. Method 2 : Using the Keypad of XT9 type. To change to XT9 mode, follow these steps: A.
Page 306 open the Tools menu using your remote. B. On the Tools menu, select XT9 text input. C. Select On, and then select OK. Example: Inputting“105Chang”. 1. Select the TTX/MIX key three times using your remote to change the input mode from lower case to numbers.
Page 307 on your remote. 3. Select the TTX/MIX key three times using your remote to change the input mode from numbers to capitalized case. 4. Select in sequence: 2, 4, 2, 6, 4. A thin window appears at the top of the screen displaying a list of words you can enter Select “Chang”...
Page 308 If “Chang” is not displayed in the list, select to create your own the dictionary. Add your own word to your dictionary. Using the QWERTY Keypad If you have a USB or Bluetooth keyboard attached to the TV, and the screen is displaying the QWERTY keyboard, you can use the attached keyboard just like a regular keyboard.
Page 309 Type a character and the character appears on the screen. If you don't have a USB or Bluetooth keyboard attached and the QWERTY keyboard is displayed, use your remote to highlight and then select letters, numbers, and symbols on the keyboard one at a time.
Page 310 Select the 1 button to display symbols and icons. Select again to re-display letters. XT9 text input is On, words will appear in a ribbon at the top of the page. Select the button to select a word in the ribbon. Using the coloured and function buttons with the QWERTY Keypad Delete All...
Page 311 Delete all inputted character. Numeric QWERTY Toggles the keypad mode between Numeric keypad mode and QWERTY mode. When the keypad is set to QWERTY mode, you can input characters using a USB or Bluetooth keyboard connected on the TV. Settings...
Page 312 Displays the options menu. Input Language: select an input language. XT9 text input: Turns the XT9 word function on or off. Available in both Numeric Keypad and QWERTY mode when you use the remote or a mouse to select and enter characters. Enter Enter the selected character.
Page 313 Return to the previous menu. Prev Page Display the previous set of symbols/ icons. Available only when the keypad screen is in symbol/icon mode (F). µ Next Page Display the next set of symbols/ icons. Available only when the keypad screen is in symbol/icon mode (F).
Page 314 Creating an Account To establish your own, exclusive configuration of Smart Hub, create your own Samsung account. You must use an e-mail address as an ID. You can register up to 10 User Accounts. You do not need an account to use Smart Hub.
Page 315 To create an account, follow these steps: 1. On the Smart Hub screen, select using your remote. The Login screen appears. When using the Smart Touch Return R Control, press the button to close the button screen and use the button.
Page 316 The Create Account screen appears. 3. Select Samsung Account. An entry screen and keypad appear. 4. Use the keypad to enter your e-mail address. This will serve as your ID. If you have a Bluetooth or USB keyboard attached to the TV, use the keyboard to enter the e-mail address.
Page 317 password. Note that after you type in the e-mail address and password, you will need to use your remote to continue. 5. When done, select OK. The Login screen reappears. 6. Select Password. The Password screen and a keypad appear. 7.
Page 318 symbols. Select using your remote to display or hide the password as you enter it. 8. When done, select OK. 9. Select Confirm Password. The Password screen and a keypad re- appear. 10. Repeat Steps 7 and 8. 11. When done, select Create Account.
Page 319 12. Select OK. The Continue to register service ID window appears. 13. Select OK. If you don’t have existing provider accounts or do not want to register existing accounts at this time, select Cancel. You can also let the window close on its own in about a minute.
Page 320 Samsung Account. Registration makes it easier to access the provider’s web site. For registration instructions, go to Step 2 in Account Manager...
Page 321 Customizing the Home Screen Login Logout To log in to your Samsung account, follow these steps: 1. With the Smart Hub main screen displayed on your TV, select using your remote. The Login screen appears. 2. Select the ^ next to the...
Page 322 A keypad screen appears. Input your Samsung Account manually. When done, go to Step 4. If you use the Face recognition function to have the TV memorize your face, you can log in to your Samsung account using the...
Page 323 Face Recognition Mode without inputting your account name. For more detailed information about Face recognition, see the "SMART Interaction" section in the e-Manual. 3. Select your ID from the list that appears. The Login screen re- appears. 4. Select Password. The Password window and a keypad appear.
Page 324 5. Enter your password using your remote. When done, select OK. If you want Smart Hub to enter your password automatically, select Remember my password. after you have entered your password. A mark appears. Smart Hub will now enter your password automatically when you select or enter your ID.
Page 325 Sign me in automatically. A mark appears. If you forget your Samsung account password, you can reset it. Select using your remote. A popup message appears. Select OK. Smart Hub will send a guide to your e-mail address that explains how to reset your password.
Page 326 Smart Hub home screen. Account Manager Lets you register your service provider accounts, delete or deactivate your Samsung account, and register or reset face recognition. For more information about Account Manager, see "Configuring Smart Hub with the Settings Menu" in this section.
Page 327 Using the Tools menu with Smart Hub Depending on the icons and folders displayed on the Smart Hub screen, some of the functions listed below may not appear. Login Logout Log in or log out of your Samsung account. Wallpaper You can change the background image...
Page 328 on the Smart Hub home screen. Move Move function lets you change the screen position of an application or a folder. To use the Move function, follow these steps: 1. Select an application icon or a folder, and then open the Tools menu using your remote.
Page 329 2. Select the Move. A position change screen appears. 3. Move the icon using your remote. When the icon is in the position of your choice, select the icon. The application icon moves to its new location. Move to Folder Move to Folder function lets you move an application to a folder.
Page 330 To use the Move to Folder function, follow these steps: 1. Select an application, and then open Tools menu using your remote. 2. Select the Move to Folder. The Move to Folder window opens. 3. Select a folder using your remote. A move finished message appears.
Page 331 If you select an application in a folder, you can use the Move to Folder to move the application to the Smart Hub screen. To access an application in a Folder 1. On the Smart Hub screen, select a folder. The folder opens. 2.
Page 332 Delete Delete function lets you delete applications from Smart Hub. To use the Delete function, follow these steps: 1. Select an application, and then open Tools menu using your remote. 2. Select the Delete. The message Do you want to delete the selected item(s)? appears.
Page 333 3. Select OK. The application is deleted. New Folder New Folder function lets you create and name new folders. You can move applications into the folders you have created. To use the New Folder function, follow these steps: 1. Open the Tools menu using your remote.
Page 334 2. Select the New Folder in the menu. New Folder pop-up and a keyboard screen appear. 3. Using the keyboard and your remote, enter a name for the folder. 4. When done, select at the bottom of the screen. The New Folder screen closes and the...
Page 335 rename folders. To use the Rename Folder function, follow these steps: 1. Select a folder, and then open the Tools menu using your remote. 2. Select the Rename Folder. The Rename Folder window and a keyboard screen appear. 3. Enter a new name using your remote or edit the old name.
Page 336 4. When done, select OK. The Rename Folder window closes and the new or revised name appears below the folder. Depending on the application, this function may not be supported. Lock Lock function lets you lock some applications in Smart Hub so they cannot be opened without entering the password.
Page 337 Depending on the application, this function may not be supported. To use the Lock function, follow these steps: 1. Select an application, and then open Tools menu using your remote. 2. Select Lock. The Security window appears. 3. Enter your security PIN using the remote.
Page 338 PIN, enter “0-0-0-0”. 4. A confirmation message screen appears. Select OK. The message screen closes and a lock symbol appears to left of the application. Unlock Depending on the application, this function may not be supported. To use the Unlock function, follow these steps:...
Page 339 1. Select a locked application, and then open the Tools menu using your remote. 2. Select Unlock. The Security window appears. 3. Enter your security PIN using the remote. If you have not created a PIN, enter “0-0-0-0”. 4. A confirmation message screen appears.
Page 340 left of the application disappears. Information Depending on application, you can view the detailed information about the selected application. You can also lock or unlock the application on the Detailed Information screen. Configuring Smart Hub with the Settings Menu...
Page 341 To use these three functions, you must be logged into your Samsung Smart Hub account. To access the Settings menu, and then select a menu item, follow these steps: 1.
Page 342 3. Select a menu item using your remote. Account Manager Account Manager menu contains functions that let you register your service provider accounts, and delete or deactivate your Samsung account. Link to other accounts: If you have existing accounts with any of the...
Page 343 Link to other accounts function, you can associate the provider account and the provider account password with your Samsung account. If you associate the account, you will be able to log onto the account through Smart Hub easily, without entering your account name or password.
Page 344 1. In the Account Manager menu, select Link to other accounts. The Link to other accounts window appears. 2. Select an application you want to associate with your Samsung account. 3. In the pop-up that appears, select...
Page 345 Register. 4. In the Link to other accounts entry screen, enter your site ID and password using your remote. When done, select OK. This is the ID and password you normally use to access your account on this application. 5. If you have entered the ID and password correctly, the Registered successfully.
Page 346 6. If want to add another service application, and then repeat Steps 2 through 4 to associate another service application. 7. When done, select OK. Remove from TV account list: Cancels all the currently registered Service Accounts that appear on the Link to other accounts screen.
Page 347 Smart Hub. Face recognition: Registers your face in your Samsung account. For more information about Face registration, "Face recognition" in the SMART Interaction section. Transfer recognised face: Delete your...
Page 348 Service Manager Auto Ticker: You can set Auto Ticker come on when the TV powers. The Ticker application provides useful News, Weather, and Stock Market information. Before you can set the Auto Ticker on, you must download the Ticker application into Smart Hub.
Page 349 different service or not be supported. Push Notification Settings: When on, Push Notification displays a notification message when an event takes place in an application installed on Smart Hub. The TV will display the notification message and allow you to view details of the event even while you are viewing Reset Reset...
Page 350 downloaded applications, erases all user accounts and settings from the TV, and resets all Smart Hub settings to the factory default settings. It then restarts Smart Hub as if it were starting for the first time. Your account, however, remains on the Smart Hub server.
Page 351 To use the Reset function, follow these steps: 1. In the Settings menu, select Reset. Reset screen appears. 2. Enter security password using your remote. The default PIN set is “0-0-0-0.” The Smart Touch Control is not available If you forget the PIN code, press the remote control buttons in the following sequence in Standby...
Page 352 mode, which resets the PIN to “0- MUTE M 0-0-0”: (Power on). 3. After a few moments, Smart Hub automatically resets. The screen may go black, and then Smart Hub appears. In a few moments, it starts the re-initialization procedure. 4.
Page 353 section of this manual. About Smart Hub About Smart Hub menu contains functions that display information about Smart Hub. More: Lists information about Smart Hub including version number, memory usage, and the unique product ID. Terms of Service Agreement: Display Terms of Service Agreement.
Page 354 Using Samsung Apps Samsung Apps ™ Samsung Apps Samsung Apps is a store from which you can download applications to use on Samsung TV/AV equipment. You can enjoy a variety of contents such as videos, music, photos, games, useful information etc. using the...
Page 355 New applications are added regularly. Using the coloured and function buttons with Samsung Apps Login Logout Log in to or log out of your Samsung account. Filter by Price To toggle the view between All, Paid and Free. Sort...
Page 356 To sort the applications by Recommended, Name, Date Downloaded. You can sort all categories except Most Popular. View Mode Each time you select using your remote, the View Mode toggles between basic mode and thumbnail mode. Previous...
Page 357 Move to previous page. µ Next Move to next page. Tools Displays the option menu. Return Moves to previous menu. Using Samsung Apps by category The following categories are available: What's New?
Page 358 User can easily find newly (latest) registered application. Most Popular Displays the most popular applications for users. Video Includes apps that provide video media such as movies, TV shows, and short length videos. Game Includes various game apps such as...
Page 359 sudoku and chess. Sports Includes apps that provide sports content such as game results, images, and short length video. Lifestyle Includes apps that provide lifestyle media services such as music, personal photo management tools, and social networking such as Facebook and Twitter.
Page 360 Information Includes apps that provide information content such as news, financial information, stock quotes, weather, etc. Education Includes apps that provide education content such as story books, dictionary, VOD (Video on Demand) for kids etc. My Apps My Apps provides information about your available App cash coupon and...
Page 361 You can purchase App cash that you can use to buy applications through tv.samsungapps.com. Downloaded apps displays the list of free apps that are installed on the Help If you have questions about Samsung...
Page 362 Apps, check this section first. To search for an application in Samsung Apps, follow these steps: 1. On the Samsung Apps screen, select Search Samsung Apps. The Search window and keyboard appears. 2. Enter a keyword using your remote. The keyword should be part of the name of an application.
Page 363 3. When done, select at the bottom of the keyboard. 4. Wait until the search result screen displays. After Samsung Apps displays the results, you can select an application you want in the search result screen. You can find a keyword in the search history If you have searched using that keyword before.
Page 364 TV, you can use the mouse to select the Search Samsung Apps field and the keyboard to type in the keyword.
Page 365 Search ™ Search (May not be available, depending on your country.) Easily search for and access content from diverse sources (e.g. applications, Your Video, AllShare Play) 1. On the Smart Hub, select Search the top of the screen or press the Search button on your remote.
Page 366 directly, Enter search keyword. entry field. A keypad screen appears. Enter the search term using your remote. If you want to search by category, select a category below the field using your remote. Using the Search function by category Your Video Personalize your movie-watching with a customized video on demand (VOD)
Page 367 recommendation service. Most searched You can search by selecting a key word in the key word list. The key word list displays words you frequently use for searches. Top application You can search applications and services in the application list. The application list displays apps that users download frequently.
Page 368 Search history You can find the keyword in the search history list if you searched a keyword before. Using the coloured and function buttons with Search Refresh Refresh the Search function. Tools You can set general parameters for the...
Page 369 Search function or delete the search history. Return Return to the previous menu. Using the Tools menu with Search General Settings Keyword recommendation: Turns the Keyword Recommendation function on or off. Search area: Sets a search scope. The...
Page 370 default is allowed all application. To customize a search area, follow these steps: 1. On the Search screen, open the Tools menu using your remote. 2. Select General Settings. 3. Select an application in the Search area. A mark disappears from the check box.
Page 371 you remove that application from the search scope. Only checked applications are included. RETURN R 4. When done, select Search history Lets you delete previously used keywords from the search history list. Also, If you select Delete All, you can delete all your search history.
Page 372 1. On the Search screen, open the Tools menu using your remote. 2. Select Search history. 3. Select a keyword in the Keyword list. 4. Press on the standard remote or tap the touch pad on the Smart Touch Control. The keyword disappears from the list.
Page 373 Your Video ™ Your Video (May not be available, depending on your country.) Using this service from Smart Hub, you can get video recommendation, search for movies from multiple providers, and stream or purchase movies. To stream or purchase movies, you must have the vendors app installed in Smart Hub.
Page 374 need a vendor account. Using the Your Video Search Tab 1. On the Smart Hub screen, select Your Video. 2. If this is the first time you have accessed Your Video, the Privacy Notice appears. Read the notice, and then select Agree. 3.
Page 375 movies with Recommended at the top of the screen highlighted. Move the highlight from the top of the screen down to the first movie, and then scroll the movies to the right to view all the movies in the list. 4.
Page 376 shows, and From friends. 5. To select a movie, highlight it, and then press the button on the standard remote or press the touch pad on the Smart Touch Control. The movie's Data screen appears. On this screen you can view Basic Information, Director/Cast, Photos, Awards, and Related Movies.
Page 377 To go to a vendor's web site, you must have that vendor's app installed in Smart Hub. To install apps, access Samsung Apps on the main Smart Hub screen. 7. You can search for a particular movie. To search, select...
Page 378 remote. The Search Entry screen and a keyboard appear. 8. Enter the name of the movie into the Search field. As you enter characters, the Search function will display suggestions below. You can either continue entering characters, or, if your movie appears, move the highlight down and select it.
Page 379 If you are entering using a keyboard, you can either press Enter or you can move the highlight down using the down arrow key. Using the Function and Coloured Buttons on the Search Tab Login Logout To login to your Smart Hub account or log out.
Page 380 Search To search for movies or videos (Steps 7 and 8). My Page Displays your My Video Bookmarks, Likes/Shares (if you have a Facebook or Twitter account registered in Smart Hub), and lets you establish certain Preferences. Return Return to the previous menu.
Page 381 Using Function and Coloured Buttons on a Movie's Data Page Login Logout To log in to your Smart Hub account or log out. Bookmark Unbookmark To bookmark a movie or video or to remove the bookmark. When you bookmark, Bookmark appears on the left side of the screen.
Page 382 movies or videos are listed on My Page. Search To search for movies or videos (Steps 7 and 8). Home To go to the My Video Home screen. My Page Displays your My Video Bookmarks, Likes/Shares (if you have a Facebook or Twitter account registered in...
Page 383 Smart Hub), and lets you establish certain Preferences. Return Return to the previous page or menu. Using the Your Video Genre Tab When you start Your Video, the Your Video screen displays the Search tab. You can also display the Genres tab which sorts movies and videos by genre.
Page 384 1. On the Your Video Search tab, move the highlight to the bottom of the screen, and then select Genres. The Genres tab appears. 2. On the Genres tab, select either Movies TV show on the left side of the screen 3.
Page 385 screen with the movies or TV shows in the genre you selected. 4. Highlight a movie or TV show and then select it. The Data screen for that movie or TV show appears. Using the Function and Coloured Buttons on a Genre Movie or TV Show List Screen Login Logout...
Page 386 or log out. Genres To re-display the Genres tab. Search To search for movies or videos. Sort To sort movies or videos by Ratings, Year, or Title. My Page Displays your My Video Bookmarks, Likes/Shares (if you have a Facebook...
Page 387 or Twitter account registered in Smart Hub), and lets you establish certain Preferences. Return Return to the previous page or menu. Using My Page My Page displays your My Video Bookmarks, Likes/Shares (if you have a Facebook or Twitter account registered in Smart Hub), and lets you establish...
Page 388 certain Preferences. When the T Page icon is displayed at the bottom of a screen, select or press T Tools. My Page appears displaying your bookmarked movies and videos. Select a bookmarked movie or video, access your Likes/Shares, or view or change your Preferences.
Page 389 Login Logout To log in to your Smart Hub account or log out. Search To search for movies or videos. Home To go to the My Video Home screen. Return Return to the previous page or menu.
Page 390 Family Story ™ Family Story Family Story feature allows you to share photos, messages, and events with your family. Create Group If you are starting Family Story the first time, you can create a family group and invite members to join. Invite Members After creating a group, you can invite...
Page 391 the family members who you want to share your family's photos and events with to join. Join Group If you were invited to join a family group by a family member, you can select Join Group to enjoy Family Story services.
Page 392 To create a family group, follow these steps: 1. On the Smart Hub screen, select Family Story. The Family Story screen appears. 2. Select Create Group. The Create and invite pop-up appears. 3. Select OK. The Family Story agreement appears. Read the agreement, and then select Agree.
Page 393 It is required to agree with the terms prior to using Family Story. 4. Enter a Group Name, Your Name, and Your Phone Number without dashes using your remote. If you want to add a group image, select an image box. (An external device containing photos must be connected to your TV via USB.) * Fields marked with an asterisk...
Page 394 5. When done, select Done. The group creation is completed. If you want to invite members to your group, select Invite Members. If you want to go your Family Story, select Go to Family Story. If you selected Invite Members, go to Step 4 in the procedure below.
Page 395 1. From the starting menu in Family Story, open the Tools menu using your remote, and then select Group Members. The Group Members screen appears. 2. Select Invite Members. The Invite pop-up appears. 3. Select OK. The Invite Members screen appears. 4.
Page 396 Done. 6. Select Phone number or Samsung account ID. The keypad screen re- appears. 7. Enter the prospective member's phone number or Samsung account ID using your remote. When finished, select on the bottom of the...
Page 397 keyboard, and then select Done. If you want to add more prospective members, select Member, and repeat Steps 4 through 7. 8. When finished adding members, select Done. The Member Invitation Completed screen appears. 9. If invited by phone number, 4-digit invite code will be generated and the code needs to be shared with...
Page 398 If invited by Samsung account, the member will be notified about the invitation via e-mail. Select to finish. To join a group using the received invite code, follow these steps: 1. Start Family Story and accept the terms.
Page 399 Invite Code. If you were invited by Samsung account, please select Samsung Account. 3. If joining by Samsung Account, a list of invitations from your family groups will be displayed. Select Accept to join.
Page 400 your phone number using your remote. When done, select Done. Then you will see a list of invitations from your family groups. Select Accept to join. You can select Deny if you don't want to join the inviting group. Enter the 4-digit invite code shared by your family member, and then select Deny...
Page 401 Creating an Album You can upload pictures from a USB device and create a picture album which other group members can view and add to. To create a picture album, follow these steps: 1. Attach a USB device containing the pictures you want to upload to the...
Page 402 picture album to your TV. 2. Log into your Smart Hub account, and then start Family Story. 3. Highlight and select the "create album" icon on the left side of the Family Story screen or select Create using your remote. The Create screen appears.
Page 403 5. Highlight and select the USB device. The device opens, displaying either folders or picture files. 6. If picture files are displayed, highlight and select each file you want to upload. A check appears on each file. 7. If folders are displayed, highlight and select the folder that contains the pictures you want to upload.
Page 404 A check appears on each file. Your can highlight and select the Select All button on the right side if you want to select all displayed pictures. 8. When finished, highlight and select the OK button on the right side. The Create screen re-appears displaying some or all the photos you want to upload.
Page 405 upload queue, select Tools. In the Tools menu, select Delete Photos. Either highlight and select individual photos or select Delete All. When done, select the Delete button on the bottom of the page. A pop-up appears asking whether you want to delete the photos. Select Yes.
Page 406 photos are uploaded, and then the Story of the Day screen appears, displaying the photos. 10. Select R Return. The Cover Story (Main Family Story) screen appears displaying the photos. The Cover Story screen runs a continuous slide show of photos you uploaded.
Page 407 Deleting a Picture To delete a picture, follow these steps: 1. On the Cover Story screen, highlight and select the strip of photos on the bottom left. The Story of the Day screen appears. 2. Highlight and select the photo you want to delete.
Page 408 4. In the Tools menu, select Delete. A message appears asking if you want to delete the photo. 5. Select OK. The picture is deleted. Editing a Picture The Edit function lets you add a memo to a picture or add the picture to an event.
Page 409 1. On the Cover Story screen, highlight and select the strip of photos on the bottom left. The Story of the Day screen appears. 2. Highlight and select the photo you want to edit. 3. Select T Tools. 4. In the Tools menu, select Edit.
Page 410 Memo screen and keyboard appear. 6. To add the picture to an event, highlight and select Find event. Events list screen appears. Use the left and right arrow buttons to change the month. Use the up and down arrow buttons to select an event.
Page 411 bottom of the screen. Creating a Memo You can create a memo that all group members can see. To create a memo, follow these steps: 1. Log into your Smart Hub account, and then start Family Story. 2. Highlight and select the "create memo"...
Page 412 the Family Story screen or select Create using your remote. The Create screen appears. 3. On the Memo tab, highlight and select the "enter Memo" area. The Enter memo screen and keyboard appear. 4. Use your remote to highlight and select letters.
Page 413 letters. 5. When done, select on the on screen keyboard, press on the standard remote, or press the touch pad on the Touch Control. If you are using a physical keyboard, press the Enter key on the key board. The Create screen re-appears displaying the memo.
Page 414 again. The Enter memo screen and key board re-appear. 6. Highlight and select the Done button on the bottom of the screen. The Story of the Day screen appears displaying the memo. 7. Select R Return to go back to the main Family Story screen.
Page 415 To delete a memo, follow these steps: 1. On the Cover Story screen, highlight and select the memos on the right side of the screen. The Story of the Day screen appears. 2. Highlight and select the memo you want to delete. 3.
Page 416 5. Select OK. The memo is deleted. Editing a Memo To edit a memo, follow these steps: 1. On the Cover Story screen, highlight and select the memos on the right side of the screen. The Story of the Day screen appears. 2.
Page 417 3. Select T Tools. 4. In the Tools menu, select Edit. The Edit screen appears. 6. Highlight and select the Edit field. The Memo screen and keyboard appears. Edit the memo, and then press Enter when done. 7. The Edit screen re-appears. Highlight and select Done on the bottom of the...
Page 418 Creating an Event You can create a record of an event, such as a birthday party or a wedding, with pictures, that all group members can see. You can also create a record for a future event. To create an event, follow these steps: 1.
Page 419 2. Log into your Smart Hub account, and then start Family Story. 3. Highlight and select the "create event" display on the right side of the Family Story screen or select Create using your remote. The Create screen appears. 4. On the Event tab, highlight and select Event title...
Page 420 select letters. If you have a USB or Bluetooth keyboard attached to the TV, use the keyboard to type in letters. 6. When done, select on the on screen keyboard, press on the standard remote, or press the touch pad on the Touch Control. If you are using a physical keyboard, press ENTER on the keyboard.
Page 421 Event Title screen with your remote. The Event Tab reappears. 8. User your remote to highlight and select the "Enter Description" field. The Enter Description screen and keyboard appear. 9. Enter a description of the event the same way you entered the Event Title in Step 5.
Page 422 screen in Steps 6 and 7. 10. Highlight and select the From field. Time Settings screen appears. Use the up and down arrow buttons on your remote to change the values in each field. Use the left and right arrow buttons to move from field to field.
Page 423 From time in Step 10. 12. To define the Event Type, highlight and select the Change button. The Event Type list appears. 13. Use the up and down arrow buttons on your remote to select an event type. When done, press or press the touch pad on the Touch Control.
Page 424 appears. 15. Highlight and select the USB device. The device opens, displaying either folders or picture files. 16. If picture files are displayed, highlight and select each file you want to upload. A check appears on each file. 17. If folders are displayed, highlight and select the folder that contains the pictures you want to upload.
Page 425 select each file you want to upload. A check appears on each file. Your can highlight and select the Select All button on the right side if you want to select all displayed pictures. 18. When finished, highlight and select button on the right side.
Page 426 To delete a photo from the upload queue, select Tools. In the Tools menu, select Delete Photos. Either highlight and select individual photos or select Delete All. When done, select the Delete button on the bottom of the page. A pop-up appears asking whether you want to delete the photos.
Page 427 and selecting all photos, highlight and select the Done button at the bottom of the Event Tab. Family Story uploads the photos you selected and then displays the Story of the Day screen. 20. Select R Return to go back to the main Family Story screen.
Page 428 To delete an event, follow these steps: 1. On the Cover Story screen, highlight and select the events on the bottom right side of the screen. The Story of the Day screen appears. 2. Highlight and select the event you want to delete.
Page 429 5. Select OK. The event is deleted. Editing an Event To edit an event, follow these steps: 1. On the Cover Story screen, highlight and select the events on the bottom right side of the screen. The Story of the Day screen appears. 2.
Page 430 3. Select T Tools. 4. In the Tools menu, select Edit. The Edit screen appears. 5. Edit the elements in the event in the same fashion you first entered them. 6. To remove a photo, highlight the photo, and then Select T Tools. 7.
Page 431 9. Highlight and select Delete. A message appears asking if you want to delet the photos. Select Yes. 10. When finished editing, highlight and select Done at the bottom of the page. Functions on the Cover Story (Main) Screen On the Cover Story screen, you can launch a slide show, display individual...
Page 432 Launching a Slide Show 1. On the Cover Story screen, highlight and select the large Slide Show area. This is the portion of the screen that displays constantly changing pictures. The slide show starts. The slide show controls are displayed momentarily, then disappear.
Page 433 3. To view individual pictures, stop the slide show, and then press the left or right arrow button on your remote. 4. To change the speed of the slide † … show, select the button. 5. To end the slide show, select R Return.
Page 434 the bottom left. The Story of the screen appears displaying the individual photos. 2. Highlight and select a photo. The individual photo is displayed. To add a comment about the photo, highlight and select the Comment button or select . The Comment screen and keyboard appear.
Page 435 the picture, highlight and select the picture. The slide show begins. To watch a slide show together with another member of your group, select . This function lets you and another member of your group watch the same slide show on your own TVs, even if you are thousands of miles apart.
Page 436 1. On the Cover Story screen, highlight and select the memos displayed on the right side. The Story of the screen appears displaying the individual memos. 2. Highlight and select a memo. The individual memo is displayed. To add a comment about the memo, highlight and select the Add Comment button or select...
Page 437 appear. Viewing Individual Events 1. On the Cover Story screen, highlight and select the events displayed on the right side. The Story of the screen appears displaying the individual events. 2. Highlight and select an event. The individual event is displayed. To add a comment about the...
Page 438 event, highlight and select the Comment button or select . The Comment screen and keyboard appear. To watch a slide show of the pictures saved in the event, highlight and select the pictures at the bottom left of the screen. The slide show begins. The Tools Menu Functions Tools Menu appears on most of...
Page 439 the Family Story screens. This section provides a run down of all the Tools Menu functions by screen. Tools Menu Functions on the Cover Story Screen Group Members: Lists the current group members and the current prospective members with invitations. groups: Lists the groups you are a member of.
Page 440 Settings: Lets you edit your profile information and set whether your group will allow new content, new members, new invitations, and issue event reminders. Logout: Logs you out of Family Story and your Smart Hub account. Returns you to the Smart Hub screen.
Page 441 Updates: Lets you know if there is an update for the Family Story application, and lets you download and install it. Tools Menu Functions on the Story of the Day Screen Filter: Lets you select what to view on the Story of the Day screen by category: All, Album, Memo, Event.
Page 442 Members, groups, Settings, Logout, Updates - are the same functions as the Cover Story screen functions. Other Functions on the Story of the Day Screen The Story of the Day screen also has a date filter function on the bottom of the screen.
Page 443 the Day screen by Date created Date Uploaded by highlighting and then selecting the Date created/Date Uploaded slider button. You can also quickly move to the month certain items occurred or were uploaded by selecting a highlighted number on the monthly number bar. You can also select a year, and then a month.
Page 444 uploaded or occurred in that month.
Page 445 Fitness ™ Fitness Fitness application provided by Smart Hub lets you track and manage a fitness and exercise programme you create. To use Fitness, you should be logged in the Smart Hub. Read these notes before exercising... Please warm-up or stretch before...
Page 446 exercising. Stop exercising immediately if you feel pain, or dizzy, exhausted, or short of breath. Create Your Profile When you start Fitness for the first time, you should create your own profile. On the Fitness screen, select Create your profile. A pop-up message appears.
Page 447 Personal Trainer/Create Profile screen appears. 1. To go to next step, press the right arrow button on your standard remote or sweep a finger to the right on the Smart Touch Control. The Name pop-up appears. 2. Select First Name. The Username screen and keyboard appear.
Page 448 screen and keyboard re- appear. Enter your last name. When done, Select OK. 4. Press the right arrow button on your standard remote or sweep a finger to the right on the Smart Touch Control. The Gender pop-up appears. 5. Highlight and select your gender. When you select our gender, you will see a black dot appear in your selection.
Page 449 6. Press the right arrow button on your standard remote or sweep a finger to the right on the Smart Touch Control until the Date pop-up appears. 7. Enter your birth date using your remote. It will be used to personalize some parameters for you.
Page 450 9. Select your preferred units. The selected units will be applied throughout the Fitness app. Move to the right again. The Height pop-up appears. 10. Enter your height. This will be used to calculate your body mass index (BMI). Move to the right again. The Weight pop-up appears.
Page 451 (BMI). Move to the right again. The application calculates your BMI. 12. The creation of your profile is finished. The TV displays your profile information and BMI. To start the Fitness app, select Enjoy Fitness. Using Fitness with categories Exercise Provides information on your exercise goal, current status and recommended...
Page 452 contents. Progress Provide information on your basic body profile, exercise progress, achievement of your goals, etc. Edit Edit lets you change or adjust your fitness goals. Selecting Exercise Programmes Fitness displays a number of exercise...
Page 453 Each of these videos and programmes must be downloaded from Samsung Apps. Videos labeled VOD (Video on Demand) are part of a group of free exercise videos. We suggest you download those first.
Page 454 A message appears asking you if you want to go to Samsung apps. 2. Select Yes. The Samsung Apps screen appears. This may take a few minutes. 3. If this is the first time you have download a VOD programme or...
Page 455 VOD exercise videos. 4. Follow the directions on the screen to download the VOD video app. 5. After the video app has been RETURN R downloaded, press several times to go back to the Fitness screen. 6. You can now select and play any of the VOD videos.
Page 456 calculates the number of calories you have burned, base on the video.
Page 457 Kids ™ Kids The Smart Hubs Kids app provides a quick app launcher and a recommended list of kids and education-related applications and contents your kids can start easily and quickly. It also provides management tools that let you control what your kids can view in the app and how long they can watch.
Page 458 Using Kids with categories Playground Displays recommended contents and applications. When you select an application or content, the TV executes the application or contents immediately. You can add up to 40 items to the recommended list. See "My choice" in this section. You can edit the contents list.
Page 459 "My choice" in this section. Most of the content must be downloaded from Samsung apps. To download, follow the directions on the screen. When the download is RETURN R complete, press repeatedly until the Kids app reappears. Start the contents or app by highlighting and then selecting it.
Page 460 stickers your kids received. Also, it can be share with your Family Story. Your kids can receive the sticker through these methods: – By User (parent) : You can present a sticker using the Present Stickers function in the Parents menu.
Page 461 Creating a Sticker Book 1. If you want to create a new Sticker Book, select Sticker Book on the top of the screen, and then Create a New Sticker Book at the bottom of the screen. The Create New Sticker Book screen appears.
Page 462 When done, select Next. 4. Check the created sticker book. If you want to change a name, select Edit. If you want to change a colour, select Back. 5. When done, select Done. A new Sticker Book is created. You can create a new sticker book. Maximum number of books is 10.
Page 463 Sticker. Only ten new sticker types are displayed in New Sticker at one time. Browse all Displays the kids or education-related applications list and all contents list. When you select an application or contents, if the application or contents has not been installed on the TV, the TV displays the corresponding download screen from...
Page 464 Samsung Apps screen. To use Browse All, follow these steps: 1. On the Browse all screen, select a character. The contents for that character appears on the right. 2. Select the kind of contents you want. Videos: Displays the video contents of the corresponding character.
Page 465 Stories: Displays the e-book contents of the corresponding character. 3. The detailed information screen for the selected contents appears. You can play the contents, share the contents with your Family Story, add the contents to choice, and give the contents a rating. If you were purchased already, you can play the contents.
Page 466 Samsung Apps. Parents Lets you edit the Playground, give stickers to your kids, check usage time, and set the watching limit alarm. My choice You can add or delete contents in the Playground. The Playground displays the added contents only.
Page 467 Playground, follow these steps: 1. On the Parents screen, select choice. The My choice screen appears. My choice contains content you added through the Browse all screen. 2. Select contents you want to add or delete in the list. A pop-up message appears.
Page 468 4. The selected contents is added or deleted. Present Stickers When your kids do a good job today, you can present a sticker to them. To present a sticker to your kids, follow these steps: 1. On the Parents screen, select Present Stickers.
Page 469 appears. 2. Select a sticker you want to present. A pop-up message appears. 3. Select Yes. 4. Select a sticker book you want to put the sticker into, and then select Present. If you want to check a sticker book, select Check Now.
Page 470 5. The sticker is placed in the sticker book you selected. History Lets you check how long your kids have used the app through a graph. Also, lets yo check how long your kids have used each video or content item. Change a date or content title using your remote.
Page 471 Lets you set how long your kids can watch. When the time is up, the alarm window appears. To set the time your kis can watch, follow these steps: 1. On the Parents screen, select Alarm. The Set Alarm screen appears.
Page 472 set.
Page 473 Web Browser ™ Web Browser (May not be available, depending on your country.) Using this function provided by the Smart Hub, you can surf the Internet on your TV. 1. On the Smart Hub screen, select Browser. The Web Browser screen appears.
Page 474 on a PC. Using the coloured and function buttons with the Web Browser Control Panel Shows or hides the control panel at the top of the screen. Link Browsing Pointer Browsing You can change the cursor to Link Browsing mode or Pointer Browsing mode.
Page 475 use a pointer to select items on the screen in the same way you use a pointer on a computer. In Link Browsing mode, you move a blue rectangle from link to link on the screen by pressing the directional keys on your remote.
Page 476 you cannot use the remote to select items in the Tools Menu. Pointer Browsing Mode, you can use the arrow keys on your remote to move the pointer. Turns on or off. With on, you can watch TV while using the Browser.
Page 477 Control Panel: Shows or hides the control panel in the top of the screen. Link Browsing Pointer Browsing: You can change the cursor to Link Browsing mode or Pointer Browsing mode. PIP: Turns on or off. Settings: Lets you select where the PIP window is displayed on the screen and which sound source the TV plays, sound from the main screen (the...
Page 478 (the PIP window). Add to Bookmark: Add the current page to your Bookmarks. Enable Grabbing Disable Grabbing: You can move a current web page in the direction you choose. To move a web page, select a page, and then move it in the direction you wish using your remote.
Page 479 Scroll up/down You can scroll the page up or down. Return Close the Browser. Using the Control Panel with Web Browser Web Browser has a series of icons across the top of the screen which provide a number of useful functions. With these icons, you can easily use the Browser.
Page 480 described below, starting with the icon on the far left of the screen. Back Moves to the previous web page. If there is no previous web page, this icon will not work. Forward Moves to the next web page. If there is no next web page, this icon will not work.
Page 481 Refreshes the current page or stops the current connection from loading. Home Page Goes to the URL you specified as you’re the home page. Zoom You can select a zoom level of 50%, 75%, 100%, 125%, 150%, 200%, 300% Fit to screen.
Page 482 or select a favourite page to visit from the bookmark list. You can also sort by Date, Name, or Times Visited. To sort, select the Sort. When you select Enter URL, you can enter in a new URL address directly using your remote or mouse and bookmark it.
Page 483 page from bookmark list. By clicking the Text/Image button in the upper right of the screen, you can toggle the Bookmarks list between text descriptions of bookmarked pages and images of the bookmarked pages. The Bookmarks screen can also display your Browsing History and the Windows list which contains a list of the browser windows that are currently active.
Page 484 Using the Tools menu with Bookmark Delete All Delete all bookmark lists. Add to Bookmark Bookmarks the current page. Import bookmarks You can import a bookmark file saved on another device such as a Export bookmarks...
Page 485 You can export a bookmark file from your TV to another device connected to your TV. History Displays the History screen. You can select a web page to visit in the History list. You can also sort by Date, Name, Times Visited.
Page 486 highlight a page, the Options button appear on the right. In the Options pop-up, you can delete the selected page from the history list or add the selected page to bookmark. If you want to delete all entries in the history lists, open the Tools menu...
Page 487 up appears. Using your remote, you can enter a new URL directly. Windows List Displays list or images of open windows (the Windows List). You can open window from the list (using Open new window), select and access a window in the list, select and close a window in the list, or close all windows.
Page 488 Image button in the upper right of the screen, you can toggle the Windows list between text descriptions of open windows and images of the open windows. Using the Tools menu with Windows List Open new window Open a new web browser window. The new web browser page...
Page 489 automatically displays the home page. Close all windows Close all the currently opened windows listed in Windows List. After closing all windows, the TV opens a new web browser window automatically. The new web browser window automatically displays the home page. Search...
Page 490 Lets you search the web. When you access the Search entry field, the Search screen appears. To search the web by word input, follow these steps: 1. On the Search screen, select the search engine. 2. Select Enter search keyword.. The keyboard screen appears.
Page 491 as the keyword using your mouse or remote. The TV searches using the keyword and search engine you selected. Share Share the current web page with your Family Story. Options You can configure the Web Browser settings.
Page 492 Configuring the Web Browser Using Options Move the cursor to the top of the screen, and then select the Options icon. Reading Tool Provides an easy-to-read page by enlarging the main text. Reading Tools is not available for all pages. Approved Sites Allows to restrict your children’s access to inappropriate web pages.
Page 493 Therefore, this function allows access of only the registered web sites. Every time you access the Approved Sites, the PIN screen appears. The first time you access Approved Sites, enter the default PIN, 0-0-0-0 using the numbers keypad on your remote. You can change the PIN using the Reset password for Approved Sites...
Page 494 Approved Sites function on or off. Reset password for Approved Sites.: Change the Approved Sites password. Add current site: Lets you add the currently displayed web site to the Approved Sites list. Manage Approved Sites: Lets you key in URLs to add to the Approved Sites List and delete sites from the Approved...
Page 495 have not added any sites to the Approved Sites list, you will not be able to access any Internet sites. Private Browsing Enable or disable the Privacy mode. When the Privacy mode is enabled, the browser does not retain the URLs of sites you visit.
Page 496 front of the URL at the top of the screen. To disable Private Browsing, select it again when Private Browsing enabled. PIP Settings Lets you configure the function. Position: Select a position for the PIP sub-picture. Sound: Select the audio source you will hear - Main or Sub - when PIP is on.
Page 497 You can configure Web Browser options. Set as homepage: You can set the home page. – Most visited: Set the most frequently visited URL as the home page. – Current Page: Sets the current page as the home page. – Bookmarks: Sets the bookmarks URL as the home page.
Page 498 of the page you want for your home page. The keyboard works like a cell phone texting keyboard. Pop-up blocking Setting: Turns the Pop-up Block on or off. Ad Block Settings: You can determine whether to block advertisements and select the URLs for which advertisements are blocked.
Page 499 – Block current page: Adds the current page to the blocked list. – Manage blocked sites: You can add a website for which advertisements will be blocked by directly keying in the URL, or you can delete a website from the list. General: You can delete your personal information.
Page 500 – Delete browsing data: Deletes Internet access information such as cookies. – Reset Settings: Reset all web browser settings to the factory defaults. – Hide Menu: Turns the control panel auto-hide on or off. If you select on, the control panel on the top will be hidden and only appear when you move the pointer to the top of the...
Page 501 screen. Encoding: You can set the Encoding setting for web pages to Automatic or Manual. – Auto select: Turns automatic Encoding for web pages on or off. The browser selects the appropriate encoding format automatically. – Settings: Select an encoding format from a list of encoding formats manually.
Page 502 pages. Pointer: You can set the speed of the cursor when the cursor is set to Pointer Mode. – Pointer Speed: Select a pointer speed. Browser Information: Displays the version and copyright information for Browser.
Page 503 Skype ™ Skype Skype created a little piece of software that makes communicating with people around the world easy and fun. With Skype you can say hello or share a laugh with anyone, anywhere. And if both of you are on Skype, it’s free. Communicate with people around the world! For more information, download the...
Page 504 Skype user’s manual from “www. samsung.com.” [Legal Statement] Due to the various capabilities of products featuring the Samsung Smart Hub - Content Service, as well as limitations in the available content, certain features, applications, and services may not be available on all...
Page 505 Some features on Smart Hub may also require additional peripheral devices or membership fees that are sold separately. Please visit http://www.samsung.com for more information on specific device information and content availability. The services and availability of content through Smart Hub are subject to change from time to time without prior notice.
Page 506 SMART Interaction Using this function, you can access and control menu options and functions using speech, motions or face recognition. INFORMATION BOOKLET DISCLAIMER Facial Recognition Log-in In order for Face recognition function, a thumbnail image of your face will be stored in your TV for...
Page 507 logging-in purposes. Logging into the Smart Hub using Face recognition may be less secure than using an ID and password. TV Camera Usage Before using the TV Camera, you should be aware that under some circumstances and under certain legal conditions your use misuse of the TV Camera can result in legal liability for you.
Page 508 that you will not use the camera (i) in locations where cameras are generally prohibited (such as bathrooms, locker rooms or changing rooms), (ii) in any manner that will result in an invasion of a person’s privacy or (iii) in violation of any applicable laws, regulations or statutes.
Page 509 can use a TV camera after adjust a camera angle. When you don't want to use a TV camera, we recommend to use after a camera lens fixes to upwards. In this case, Face recognition Motion control functions is not available. Voice Control Menu System...
Page 510 Lets you access and control menu options and functions using speech. For accurated voice recognition, refer to the Standard Voice Command list at the Samsung web site (www. & Downloads). Voice Control function can be affected recognition by unclear...
Page 511 surrounding noise. To use Voice Control, you must pronounce words and phrases clearly and correctly in the language you selected in Voice Language. Ambient noise may cause Voice Control to malfunction. (Appropriate surrounding noise: Below 40dB) Your TV can "hear" your voice commands in two ways: –...
Page 512 Recognition) We are recommended using Voice Control function within about 4M with your TV. You can check the usable distance by using Voice Control Environment Test (System Voice and motion control Voice Control Voice Control Environment Test). – Using the VOICE ˜...
Page 513 Proximity Recognition) When you use the TV's microphone, the words may not be recognized because of ambient noise. If this VOICE ˜ occurs, try using the button on Smart Touch Control. The TV will be able to recognize a voice command more easily.
Page 514 Voice Control (System Voice and motion control Voice Control). Say a voice command to proper volume into the microphone of your remote within 10 – 30 cm. If voice level is too small or large, voice command may not be recognized. If a menu option or function is not supported by the Voice Control...
Page 515 Motion control, raise your hand while opening it toward the screen, hold it for a moment and then wave it 3~4 time to the left and right. Motion control starts. If the Motion control starts, the cursor is displayed at the centre of the screen and the Motion guide bar size...
Page 516 off. VOICE ˜ button on your remote is always activated. Voice Language Select the recognition language you want to use. Trigger words You can select the Trigger words that start the Voice Control function. Alternatively you can turn on your TV using the Trigger words Voice Control...
Page 517 function is set to On. – If the Trigger words is set to Hi TV, Hi TV Power – If the Trigger words is set to Smart TV, say Smart TV Power Voice command bar size Set the Voice command bar size mode Minimum or Full.
Page 518 Voice Sensitivity You can configure the sensitivity of Voice recognition. – Howling: Select howling levels. – Recognition responsiveness: Select the responsiveness level of Voice recognition. Voice Control Environment Test You can test the amount of ambient noise level detected by the TV microphone.
Page 519 – Noise Test: This test checks the amount of ambient noise detected by the TV microphone. Too much ambient noise will prevent Voice Command from functioning. To run, select Next using your remote. The test start and takes a few seconds. Please keep as quiet as possible during the test.
Page 520 picked up by the TV microphone will disrupt Voice Command. To run, select Start using your remote. The test start and takes a few seconds. Please keep as quiet as possible during the test. Available only when Speaker Select is set to Speaker.
Page 521 Select Start using your remote. After the test starts, say the test words listed in the instructions as loudly and clearly as you can. If the test is not successful, select Retest, and then say the words loudly and clearly again. To use the Voice Control function, follow these steps: Voice Control...
Page 522 TV may be turned on automatically by effect of the ambient environment. 1. Say a Trigger words that you selected into the microphone embedded in the TV or press the VOICE ˜ button on your Smart Touch Control. The TV displays the Voice command bar size.
Page 523 2. Say a word or phrase listed in the Voice command bar size. If you use VOICE ˜ button on your remote, release the button. Pronounce the word or phrase clearly and correctly in the language you selected in Voice Language.
Page 524 To exit the Voice Control mode, Trigger words or "Cancel" using the TV's microphone or RETURN R press the button. Using the Voice Text Input Mode 1. Say a "Search All" while in the Voice Control mode. When you use a QWERTY keypad screen, you can use the Voice...
Page 525 words that you selected into the microphone embedded in the TV or press and hold the VOICE ˜ button on your Smart Touch Control. You cannot use it for some UIs such as URL input boxes. 2. Say the word or phrase you wish to search for.
Page 526 vary based on the language spoken. Motion control Menu System Voice and motion control Motion control Enable or disable Motion control function. Lets you control your TV by moving the TV cursor using specific gestures. Motion control function can be affected recognition by motion...
Page 527 posture, or ambient brightness conditions. Some applications may not support Motion control. You may experience physical fatigue when you use the Motion control a long time. To use the Motion control, please avoid direct sunlight. We are recommended using Motion control function within about 1.5M...
Page 528 ~ 4M with your TV. TV Camera's recognition range may differ depending on the angle of camera or other conditions. You can check the recognition ragne of TV camera by using Motion control environment test (System Voice and motion control Motion control Motion control environment...
Page 529 off. Motion guide bar size Set the Motion guide bar size mode to Minimum or Full. Motion control environment test Lets you test the brightness of room and the camera angle. – Brightness Test: This test checks to see if your room is bright enough Motion control to work properly.
Page 530 test start takes only a few seconds. (Appropriate ambient brightness: 50 – 500 Lux) Do not illuminating a sunlight or lights directly into the camera lens. Make sure that the camera lens is not cloaked by an object. – Camera Angle Test: On the Camera Angle Test...
Page 531 the screen. Move yourself into the rectangle by adjusting the camera or moving yourself in front of the camera. If you are not within the rectangle position, the test may not work properly. After aligning your body with the TV, raise your hand while opening it toward the screen, hold it for a moment and then wave it 3~4 times to the left and right.
Page 532 To use the Gesture Control function, follow these steps: 1. To use the Motion control , raise your hand while opening it toward the screen, hold it for a moment and then wave it 3~4 time to the left and right.
Page 533 2. Control the TV using your hands. For the useable gestures, see below. Note that the Motion control function closes if your hands go out of the camera range. While using Motion control, if you use the other device (i.e. remote control, keyboard, etc.) Motion control...
Page 534 gesture Access Motion control – Action : Spreads your hand in the direction of the camera, and shake it three or four times from a side to side. Pointing Navigation Moves the cursor to the position you want. – Action : Spread your hand and guide the cursor to position you want.
Page 535 Selects an item or executes a command that is indicated by the cursor or is highlighted. – Action : Clench your fists. When you are viewing a page, you can use the action to move the page in the direction you want. To move a page, clench your fist, keep it clenched, and then move it in the direction you want the page to...
Page 536 move. Note that not all pages can be moved.. Back Return to the previous menu. – Action : Spread your hand and rotate it counterclockwise. Channel / Volume Control Changes the channel or adjusts the volume. If you use the Motion control function while watching a channel,...
Page 537 the channel / volume control screen appears. – Action : Use the Pointing Navigation to move the cursor to the channel or volume controller, and then uses the motion to adjust the channel or volume. If you use the motion once, it has the same effect as pressing a button on your remote.
Page 538 effect as pressing and holding a button on your remote. Scroll Scroll the page in the direction you want. For example, suppose that you want to scroll down. Some applications may not support this function. 1. Move the cursor to the bottom of the screen (page scroll zone) using the Pointing Navigation motion.
Page 539 2. Move the cursor to the centre of the screen using the Pointing Navigation action. 3. The page will move down. Face recognition ™ Tools Settings Account Manager Face recognition Enable or disable face recognition function. Lets you register your face in your Samsung account. Also, you can...
Page 540 Samsung account using Face recognition function without inputting your account ID or password. You can register your face with only one account. To register your face with your Samsung account, follow these steps: To use this function, you must log into Smart Hub.
Page 541 To create your Samsung account, refer to “Creating an Account” in Smart Hub. 1. On the Smart Hub screen, open the Tools menu using your remote and then select Settings. 2. Select Account Manager. The Account Manager screen appears.
Page 542 Face recognition fails, select Retry, and then try again. 5. When done, your face is now registered in your Samsung account. The Continue to Register Service window appears. If you want to register service later, select OK. You can register...
Page 543 Smart menu (Tools Settings Account Manager Link to other accounts). To log in to your Samsung account using Face recognition, follow these steps: If you use Face recognition to log into Smart Hub, it may be less secure...
Page 544 1. With the Smart Hub screen displayed, select using your remote. The Samsung Account screen appears. 2. Select Face Recognition Mode. The Face recognition screen appears. To return to the Samsung Account screen, select Password mode. 3. The TV starts Face recognition.
Page 545 A red-square indicates an unregistered face. If the TV fails to recognize your face, try again. 4. The TV logs you into your Samsung account automatically. If the TV recognizes two or more the Samsung account list appears.
Page 546 Samsung account. Follow steps 4 through 5 in the “To register your face to your Samsung account, follow these steps:” procedure above. If you have no account, you can create one. For more detailed information, refer to “Creating an...
Page 547 Specification for SMART Interaction Voice Control Wake On Voice Environmental and Management Condition Evaluation Item Evaluation Criteria Surrounding Noise ~ 40dB Distance Required Voice Level 60 dB or higher Angle TV Volume(dB) Step 0 Supported languages may differ depending Supported Languages 16 languages on the model or Go to Photos List...
Page 548 Magic Word Environmental and Management Condition Evaluation Item Evaluation Criteria Surrounding Noise ~ 40dB Distance Required Voice Level 60 dB or higher Angle TV Volume(dB) Step 10 Supported languages may differ depending Supported Languages 16 languages on the model or Go to Photos List setting.
Page 549 TV Volume(dB) Step 5 Supported languages may differ depending Supported Languages 16 languages on the model or Go to Photos List setting. To view all commands list of desired language, refer to the Guide at the Samsung web site (www.samsung.com...
Page 550 Motion control Conditions for Recognition Environmental and Management Condition Evaluation Item Evaluation Criteria Operating Speed Slow / Fast Distance Environment Horizontal Angle [Illumination] Background White or Grey Vertical Angle Recognition...
Page 551 Face recognition Conditions for Recognition Environmental and Management Condition Evaluation Item Evaluation Criteria White, Yellow, Black, Skin Colour Distance Indian, Hispanic Environment Horizontal Angle [Illumination] Background White or Grey Vertical Angle Recognition Response Time 8 sec (for 5 persons)
Page 552 Smart Touch Control Touch Environmental and Management Condition Evaluation Item Evaluation Criteria Within 300 msec. Distance 30cm (Connected State) Response Time Within 1.5 sec. (Disconnected State) Vertical Angle Horizontal Angle...
Page 553 Server Voice Environmental and Management Condition Evaluation Item Evaluation Criteria Voice Recognition Surrounding Noise Distance Remote Control Operating Distance Required Voice Level 60 dB or higher TV Volume (dB) Step 50 Supported Languages 16 languages Response Time ~ 5 sec...
Page 554 Hot Keys Environmental and Management Condition Evaluation Item Evaluation Criteria Connected State 30cm Distance Disconnected State (IR) Vertical Angle Horizontal Angle...
Page 555 Pairing Environmental and Management Condition Evaluation Item Evaluation Criteria Distance 30cm 30cm Distance Angle The operation should Environment not be effected. Angle Response Time 1min.
Page 556 Panel Key Usability Environmental and Management Condition Evaluation Item Evaluation Criteria Temperature/Humidity 50% ~ 75% TV Camera Internal...
Page 557 Environmental and Management Condition Evaluation Item Evaluation Criteria Surrounding Noise ~ 40dB Distance (AF Operation) Environment [Illumination] Temperature/Humidity Angle (AF Operation) External...
Page 558 Environmental and Management Condition Evaluation Item Evaluation Criteria Surrounding Noise Distance (AF Operation) Environment [Illumination] Temperature/Humidity Angle (AF Operation)
Page 559 AllShare Play ™ AllShare Play View or play photos, music, and movie files located on a USB Mass Storage Class (MSC) device, a PC, or a DLNA device (a cell phone, for example) on your TV. To view content on a USB device, you must plug the device into a USB port on the TV.
Page 560 recommend using a USB HDD that has a power adapter. To play content located on your PC or on a DLNA compatible cell phone, you must connect your PC and the TV to your network and download and install the AllShare network software on your PC.
Page 561 Connecting a USB Device 1. Turn on your TV. 2. Connect a USB device containing photo, music and/or movie files to the USB port on the TV. 3. When a USB device is connected to the TV, the New device connected.
Page 562 The TV may display the files on the USB device automatically if it is the only device connected. 4. The AllShare Play Music, Photos, or Videos screen appears. If the USB device has folders, the TV displays a list of folders. Highlight and then select a folder.
Page 563 view or play. To select a different Content Type or Device Type, press the RETURN R button repeatedly until AllShare Play main screen appears. For more information about playing back files, see the section of this manual starting with "Controlling Video Playback".
Page 564 Disconnecting a USB Device Method 1: Using the SOURCE s button. SOURCE s 1. Press the button or select a Standard Remote Control Source for Smart Touch Control 2. Select a desired USB device, and TOOLS T then press the button Standard Remote Control for Smart...
Page 565 3. Select Safely Remove USB Device, and then wait until the selected USB device is disconnected. You can remove a USB device from the TV. Method 2: Using the AllShare Play home screen. ™ 1. Go to AllShare Play home screen. ( AllShare Play) 2.
Page 566 or press the Standard Remote Control Touch Pad for Smart Touch Control 3. Select a desired USB device, and TOOLS T then press the button Standard Remote Control for Smart button. The Tools menu Touch Control appears. 4. Select Safely Remove USB Device, and then wait until the selected USB device is disconnected.
Page 567 To remove a USB device from the TV, we recommend use Safely Remove USB Device function. Read this information before using AllShare Play with a USB device. Restrictions and Cautions Before connecting your device to the TV, please back up your files ensure against file damage or data loss.
Page 568 SAMSUNG is not responsible for any data file damage or data loss. Connect a USB HDD to the dedicated USB (HDD 5V 1.0A) port. Do not disconnect a USB device while it is being read by the TV. If you connect a USB device with a...
Page 569 TV is not recognized, the files on the device are corrupted, or a file in the list is not played, connect the USB device to a PC, format the device, re-copy the files to the device, and then try playing again. If a file you deleted from the PC is still found when you run Smart...
Page 570 If your PC cannot construct a functional database of saved files on a USB device because there is no free space on the USB device, you may not be able to view any new files you have added, even though you have saved these files to the USB device.
Page 571 and audio devices may not be compatible with this TV. AllShare Play supports only USB Mass Storage Class (MSC) devices. MSC is a Mass Storage Class Bulk- Only Transport device. Examples of MSC include Thumb drives, Flash Card Readers, and USB HDD (USB HUB are not supported).
Page 572 More than 3TB USB HDD is not supported. If more than 2 PTP devices are connected, you can only use one at a time. If more than two MSC devices are connected, some of the devices may not be recognized. A USB device that requires high power (more than 500mA or 5V) may not be supported.
Page 573 If the TV has no input during the time set in Auto Protection Time, the Screensaver will run. The power-saving mode of some external hard disk drives may be released automatically when you connect them to the TV. File system and formats The USB function might not work properly with unlicensed multimedia...
Page 574 files. MTP (Media Transfer Protocol) is not supported. The file system supports FAT16, FAT32, and NTFS. AllShare Play supports only the Sequential jpeg format. It does not support the Progressive jpeg format. The higher the resolution of the image, the longer it takes to display on the screen.
Page 575 The maximum supported JPEG resolution is 15360 X 8640 pixels. If a file is corrupted or the TV does not support the file type, the Supported File Format. message appears. If the files are sorted by Folder view, the TV can display the names of up to 1000 files in each folder.
Page 576 over approximately 8000, some files and folders may not appear and some folders may be unopen able. The TV cannot play MP3 files with DRM that have been downloaded from a for pay site. Digital Rights Management (DRM) is a technology that supports the creation, distribution, and management of digital content in an integrated...
Page 577 protecting the rights and interests of content providers, preventing illegal copying of contents, and managing billings and settlements. Even if a file you want to play is encoded in a supported format, an error message may appear due to a sub container or profile problem.
Page 578 videos located on your PC through a network connection using AllShare Play. For more information on how to configure your TV and connect it to your network, refer to “Setting up the Network” in this manual. To view content located on your PC, you must have connected your TV and your PC to your LAN and downloaded and installed AllShare...
Page 579 PC Software on your PC. We recommend you locate both your TV and PC in the same network subnet. IP addresses have four parts, separated by periods (111.222.333.444). If your TV and PC are in the same subnet, the first 3 parts of the TV IP address and the PC IP address (111.222.333) will be the same and only the last part (the...
Page 580 The following AllShare Play functions are not supported when you are playing media from a PC connected through a network: Background Music Background Music Setting functions. Sorting files by preference in the Photos, Music, and Videos folders. – The † (REW) or … (FF) function while a movie is playing.
Page 581 Additional Notes DivX DRM is not supported. Set your PC firewall programme so that AllShare PC Software is a permitted programme. Depending on the Internet server, when you use AllShare Play through a network connection: – The sorting method may vary. –...
Page 582 – The Resume function, which resumes playing of a video, may not be supported. – The Resume function does not support multiple users. (It memorizes only the point where the most recent user stopped playing a video.) – The search function may not work depending on the content information.
Page 583 You may experience file stuttering while playing a video in AllShare Play through a network connection. You can play the content in the Web storage on TV. Follow the instructions below: – Enter the AllShare Play service on TV Select a content type of Music, Photo, and Video Select SugarSync...
Page 584 can upload PC contents to the Web stroage (SugarSync). However, you can use the TV to play the content in the PC only where the uploading path is Web Archive - AllShare Play - Music / Photos / Videos – You can also use the TV to play the content in a AllShare Play - enabled...
Page 585 com website, you will see how you can upload the content on your PC to the Web storage (SugarSync).
Page 586 Using the AllShare Play AllShare Play enables you to enjoy the following services. You need to log in to your Samsung account to use web storage or social services. AllShare Play can play various contents in three ways: – Using USB Device: You can play videos, photos, or music from a connected USB device.
Page 587 play various contents from devices connected to your home network or web storage. – Using Social Services: You can play some content from social services such as Family Story, Facebook or Picasa. Before using Facebook or Picasa, it should be installed in the Smart Hub. To use SugarSync, Facebook, or Picasa, you should log in...
Page 588 "Configuring the Smart Hub with Settings" in the Smart Hub section. To use Family Story, you should log in to your Samsung account. Before using Family Story, you should join a group at least one more.
Page 589 You can transfer a desired content to other device connected to the TV. Contents Type Supported transfer device DLNA, SugarSync, Family Story, Picasa, Facebook Camera DLNA DLNA SugarSync Family Story Picasa Facebook Mobile device...
Page 590 My list AllShare Play) ™ AllShare Play My list Using this function, you can access content easily and quickly. Recently played Displays a list of recently played video, photo or music files. If you have a file you want to play again, use this list. When you play a file from the Recently played list, and the USB...
Page 591 is not found, the "Unable to find the file." message appears. Recently played list can have up to 48 files. The files are arranged so that the most currently played files are at the top of the list. Recently played files located on a mobile phone may not play.
Page 592 device or your PC. If you have a newly updated file you want to play, use this category. Playlist Displays the Playlist files saved on the USB device or your PC. If you want to play a playlist, select the playlist. The selected playlist plays immediately.
Page 593 You can only add one type of content to a single playlist. For example, you can only add music files to a playlist that includes music files. Creating a Playlist 1. On the AllShare Play main screen, select Videos, Photos, or Music the left side of the screen.
Page 594 highlight and select the device that has the files you want in the playlist. AllShare Play displays the folders and/or files on the device. 3. If AllShare Play is displaying folders, highlight and select the folder that contains the files you want. If it is only displaying files, go to Step 4.
Page 595 6. Highlight and select a file you want to add. The mark appears in the check box. 7. Repeat Step 6 to select additional files. To select all the files in the list, select Select All. To cancel a selection, select the file again. 8.
Page 596 playlist.. screen appears. 10. Enter playlist name using your remote or accept the default name. 11. When finished, Select Done. The new playlist is created. The Added pop- up appears. 12. Select Play to play now or play later. To add music files a playlist, follow these steps:...
Page 597 1. On the AllShare Play main screen, select Videos, Photos, or Music the left side of the screen. You must select the kind of content that is already in the playlist. For example, if you want to add files to a music playlist, you must select Music.
Page 598 AllShare Play displays the folders and/or files on the device. 3. If AllShare Play is displaying folders, highlight and select the folder that contains the files you want. If it is only displaying files, go to Step 4. 4. Highlight a file, and then open the Tools menu using your remote.
Page 599 check box. 7. Repeat Step 6 to select additional files. To select all the files in the list, select Select All. To cancel a selection, select the file again. 8. When done, select Add. The Add to Playlist screen appears. 9.
Page 600 10. Select Play to play now or play later. To play your playlist, refer to "Playing the Playlist" in My list section. To delete one or more files in the Playlist, follow these steps: 1. On the AllShare Play main screen, select list.
Page 601 the screen, highlight the playlist you want to edit. 3. Open the Tools menu using your remote, and then select Edit playlist. Edit playlist screen appears. 4. Select a file you want to delete. The mark appears in the check box. 5.
Page 602 selection, select the file again. 6. When done, select Remove. A pop- up message appears. 7. Select Yes. The selected file(s) has been removed from the playlist.
Page 603 Videos AllShare Play) ™ AllShare Play Videos You can play video files saved on USB device and/or your PC. For more information about the subtitle formats and codec formats, refer to "Supported Subtitle and AllShare Play file formats" in the Other Information section.
Page 604 1. On the AllShare Play screen, select Videos. 2. Highlight and select the device you want to play. 3. If AllShare Play displays folders, highlight and select the folder that contains the file you want, then go to Step 4. If AllShare Play displays files only, go directly to Step 4.
Page 605 If you stop the video while it is playing, you can play the video later from the point where you stopped it. The file name appears on the top of the screen with the video's playing time. If video time information is unknown, the playing time and progress bar are not displayed.
Page 606 Video playback control buttons † , … Each time you select † or … using your remote, the playback speed change as follows. ( † 1 / † 2 / † 3 / … 1 / … 2 / … 3) / Slide a Standard remote control finger to the left or right...
Page 607 Pause the scene. – For Slow Motion: In pause mode, select … . Each time you select … using your remote, the playback speed is reduced in this order „ 1/8 / „ 1/4 / „ 1/2. The playback speed is displayed in the upper left corner.
Page 608 using your remote, a new frame will be appear. To return to normal speed playback, select using your remote. The product does not play sound in Step mode or Slow Motion. Slow Motion and Step Mode operate only in the forward direction.
Page 609 Using the Tools menu with Videos On the file list screen, you can use the following these options: – View Lets you sort the file list by one of four sort criteria. – Play selection Lets you select one or more files to play immediately.
Page 610 Smart Hub. – Login Logout You can login to or logout of your Samsung account. – Add to Playlist Lets you create playlists. When you create playlists, you can play a series of videos that you want to watch easily and quickly.
Page 611 – Go to playlist Moves to the Playlist screen. – Information Displays detailed information about the selected file. During playback, you can use the following options on the Tools menu: – Go to Videos List Stops the video and takes you to the file list screen.
Page 612 You can restart a video file from the beginning. – Scene Search You can use the Scene Search function during playback to view or start a movie from the scene of your choice. If the index information in the file damaged or the file does not support indexing, you will not be able to use the Scene Search...
Page 613 function. – Title Search You can search the video using the left and right arrow keys or input a playing time directly using your remote. – Time Search Search the video or input the play time directly using your remote. –...
Page 614 all the files on the play list screen repeatedly. – Picture Size Lets you adjust the picture size to your preference. – Picture Mode You can change the Picture Mode. – Sound Mode You can change the Sound Mode. – Audio Language You can watch to the video in one of...
Page 615 supported languages. The function is enabled only when you play stream- type files which support multiple audio formats. – Subtitle Lets you view with language subtitles. You can select a specific language if the subtitle file contains multiple languages. – Subtitle Settings Displays the Subtitle...
Page 616 can select subtitle options such as colour and transparency. – Information Displays detailed information about the selected file. The functions available on the Tools menu at one time depend on the characteristics of the video you are playing. All functions are not necessarily available for all videos.
Page 617 Using the View function with Video Files When you use the AllShare Play function with your Web storage rather than a USB device, View is not supported. 1. To sort files in the file lists, select using your remote. The View screen appears.
Page 618 in alphabetical order. To view the file names and thumbnails, select a folder. Title Sorts and displays the files by title in Symbol / Number / Alphabet / Special order. Latest Date Sorts and displays files by the latest create date. Earliest Date...
Page 619 Sorts and displays files by the earliest create date. Send your video files Lets you send your video files to your Web storage or other devices. To use Send, you must be logged in Smart Hub. 1. To send video files in the file list, open the Tools menu using your...
Page 620 2. Select a video file you want to send. mark appears in the check box. 3. Repeat Step 2 to select additional tracks. To select all the files in the list, select Select All. To cancel a selection, select the file again. 4.
Page 621 send, and then select Send. 6. From these steps, please follow the instructions on the screen.
Page 622 Photos AllShare Play) ™ AllShare Play Photos Viewing a photo (or slide show) For more information about the supported image formats, refer to "Supported Subtitle and AllShare Play file formats" in the Other Information section. 1. On the AllShare Play screen, select Photos.
Page 623 2. On the right side of the screen, select the device that has the photos you want to view. 3. If AllShare Play displays folders, select the folder that contains the photos you want, then go to Step 4. If AllShare Play displays photo thumbnails, go directly to Step 4.
Page 624 press the button. Standard / To change a photo remote control manually, slide a finger to left or right on the Touch Pad. Smart Touch Control During the slide show, all files in the file list are displayed in order, starting from the file you selected.
Page 625 same device. If you select the wrong background music, you cannot change the music until the BGM has finished loading. Photo playback control buttons † / … The slide show speed change as follow (Slow, Normal, Fast). The speed is displayed in the upper right...
Page 626 of the screen. l , r / Slide Standard remote control finger to left or right Smart Touch Control Go to the previous or next photo. Return to the file list screen. Start the slide show. Pause the slide show.
Page 627 Using the Tools menu with Photos To use the Tools menu with photos, you must first highlight a photo file on the file list screen. After you have highlighted a photo on the file list screen, you can use the following options in the Tools menu: –...
Page 628 – Play selection Lets you select one or more files to play immediately. – Send Lets you send your photo files to your Web storage, Social Services or other devices. To use Send, you must be logged in to Smart Hub.
Page 629 Samsung account. – Add to Playlist Lets you create playlists. When you create playlists, you can play a series of photos easily and quickly. – Go to playlist Moves to the Playlist screen. – Information Displays detailed information about the selected file.
Page 630 the following options: – Go to Photos List Moves to the file list screen. – Start Slide Show Stop Slide Show You can start or stop a slide show. Alternatively, select to start a slide show or to stop a slide show using your remote.
Page 631 select † or … using your remote. – Slide Show Effect You can set various slide show effects. – Background Music On Background Music Off You can turn on or turn off background music. – Background Music Setting You can set and select background music when watching a photo file or...
Page 632 slide show. – Picture Mode You can change the Picture Mode. – Sound Mode You can change the Sound Mode. Available only when Background Music is set to on. – Zoom You can zoom into images in full screen mode. –...
Page 633 You can rotate images. – Information Displays detailed information about the selected file. Using the View function with Photo Files When you use the AllShare Play function with Family Story, Facebook, or Picasa rather than a USB device, View is not supported. 1.
Page 634 using your remote. The View screen appears. 2. Select sort criteria. Folder view Displays the folders on the device in alphabetical order. To view the file names and thumbnails, select a folder. Title Sorts and displays the files by title in Symbol / Number / Alphabet /...
Page 635 Special order. Latest Date Sorts and displays files by the latest create date. Earliest Date Sorts and displays files by the earliest create date. Monthly Sorts and shows photo files by month.
Page 636 Send your photos Lets you send your photo files to your Web storage, Social Services or other devices. To use Send, you must be logged in Smart Hub. 1. For example, suppose that you want to send with your Family Story.
Page 637 Send. 3. Select a photo file you want to send. mark appears in the check box on the left. 4. Repeat Step 3 to select additional tracks. To select all the files in the list, select Select All. To cancel a selection, select the file again.
Page 638 6. Choose the destination device to send to. 7. Choose the family group to share with. A pop-up window appears. 8. Enter a message to send to the family group you selected. In the QWERTY keyboard screen is displayed, you can use a keyboard connected to the TV to enter the message.
Page 639 Music AllShare Play) ™ AllShare Play Music Playing Music For more information about the supported music file formats, refer to "Supported Subtitle and AllShare Play file formats" in the Other Information section. 1. On the AllShare Play screen, press the arrow button to select Music.
Page 640 2. Select the device that contains the files you want to play. 3. If AllShare Play displays folders, highlight and select the folder that contains the music files you want, then go to Step 4. If AllShare displays only files, go directly to Step 4.
Page 641 using your remote. To move to the next page, select using your remote. When the music is playing, you can fast forward or fast rewind † … the music file by selecting using your remote. If the sound is abnormal when you play MP3 files, adjust the Equaliser in the...
Page 642 sound problem.) Music playback control buttons During playback, you can use additional functions at the bottom right of the screen. Play Pause You can start or pause a music file. Alternatively, you can select using your remote. Repeat Mode...
Page 643 You can play one or all the music files shown in the file list repeatedly. Shuffle Mode You can play the music files sequentially or randomly. Sound Mode You can change the Sound Mode. Using the Tools menu with Music To use the Tools menu with Music, you must first highlight a music file...
Page 644 on the file list screen. After you have highlighted a music file on the file list screen, you can use the following options in the Tools menu: – View You can sort the file list by one of four sort criteria. –...
Page 645 Smart Hub. – Login Logout You can login to or logout of your Samsung account. – Add to Playlist Lets you create playlists. When you create playlists, you can play a group of music files easily and quickly.
Page 646 – Go to playlist Moves to the Playlist screen. – Encoding You can select an encoding format from the encoding format list. – Information Displays detailed information about the selected file. Using Play Selection with music files 1. Highlight a music file in the file list.
Page 647 2. Open the Tools menu using your remote, and then select Play selection. 3. Select the track you want to add. A mark appears in the check box on the left. 4. Repeat Step 3 to select additional files. To select all the files in the list, select Select All.
Page 648 5. Select Play. The selected music files play. Using View with Music files When you use the AllShare Play function with your Web storage rather than a USB device, View is not supported. 1. To sort files in the file lists, select using your remote.
Page 649 2. Select sort criteria you want. Folder view Displays the folders on the device in alphabetical order. To view the file names and thumbnails, select a folder. Title Sorts and displays the files by title in Symbol / Number / Alphabet / Special order.
Page 650 Sorts the music files by artist in alphabetical order. Album Sorts the music files by album in alphabetical order. Genre Sorts the music files by the genre. Send your music files Lets you send your music files to your Web storage, or other devices.
Page 651 To use the Send Function, you must be logged in to Smart Hub. 1. To send music files in the file list, open the Tools menu using your remote, and then select Send. 2. Select a music file you want to send. mark appears in the check box.
Page 652 select Select All. To cancel a selection, select the file again. 4. When done, select Send. The Send screen appears. 5. Choose the destination device to send, and then select Send. 6. From these steps, please follow the instructions on the screen.
Page 653 Recorded TV AllShare Play) ™ AllShare Play Recorded TV To use the recording or Timeshift function, the connected USB device must be available for recording. Device format is recommended to use USB HDD. During the Device formatting, do not disconnect the device while formatting is in progress.
Page 654 Before formatting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss. To record a current broadcasting programme Allows you to record a programme currently being broadcasted.
Page 655 Set the current time first to use this function. 1. When you record a broadcast programme, select using your remote. A pop up window will appear. We recommend using a USB HDD with at least 5,400 rpm, but a USB HDD of RAID type is not supported.
Page 656 record until it completes the Device Performance Test. 2. Select Length to set up the recording time, and then select OK. Playing Recorded TV Programme 1. On the AllShare Play screen, select Recorded 2. Select the device you want to play. 3.
Page 657 To move a previous page, select using your remote. To move a µ next page, select 4. Select The selected file is displayed on the top with its playing time. Playback control button with Recorded TV † , … Each time select † , … your remote, the †...
Page 658 † † † † † † 7 / … 1 / … 2 / … 3 / … 4 / … 5 / … 6 / … 7 ) / Slide to left Standard remote control or right direction Smart Touch Control Jump to backward or forward from current position.
Page 659 reduced to „ 1/8 / „ 1/4 / „ 1/2. – In pause mode, select using your remote. Each time the function is selected, a new frame will be appear. To return to normal speed playback, select using your remote. The product does not play sound in stop mode.
Page 660 Using the Tools menu with Recorded TV On the file list screen, you can use the following these options: – Play Current Group Will play the contents of the selected groups. – View You can sort the file list by selecting sort criteria you want.
Page 661 You can play by selecting the desired music file in the file list. – Delete Deletes the file from the list. – Add to Playlist Lets you make your own playlist. When you use the playlist, you can play music you want to listen easily and quickly.
Page 662 – Lock/Unlock To enable or disable the lock. – Device Management On the device can scan and format. The following functions are available only in selected content item. – Rename Change the name of the content. – Information Displays detailed information about the selected file.
Page 663 During playback, you can use the following these options: – Go to Recorded List Moves to the file list screen. – Play from the beginning You can restart a video file from the beginning. – Title Search You can move directly to another title.
Page 664 Search the video or input the play time directly using your remote. – Repeat Mode You can play movie files repeatedly. – Picture Size You can adjust the picture size to your preference. – Picture Mode You can change the Picture Mode.
Page 665 – Information Displays detailed information about the selected file.
Page 666 Timeshift Using the Timeshift function If you missed a live broadcast, you can see from the recorded broadcast using this feature. 1. When you watch a broadcast programme, select using your remote to start the Timeshift function. 2. If you want to stop the Timeshift...
Page 667 function, select using your remote. Timeshift mode operates for a maximum of 90 minutes. Timeshift function is not supported for analogue channels. Timeshift functions are disabled for channels locked with Channel Lock. Before using the Timeshift and a record function...
Page 668 Recorded videos are DRM (digital rights management) protected and cannot be played on a PC or other TVs. Note that files saved on the TV cannot be used after the main board is changed. NOTE We recommend using a USB HDD with at least 5,400 rpm, but a USB HDD of RAID type is not supported.
Page 669 Timeshift function may differ depending on picture quality and the free space on the hard disk drive. USB memory stick is not compatible. When the Timeshift is used to the gunwales, the pause may be cancelled. If the 5% free memory space limit of the USB storage device is reached, the current recording process will be closed.
Page 670 the PVR (Personal Video Recorder) function and a device that supports the HDMI-CEC feature, recording by the PVR function takes precedence. If the USB device has failed the Device Performance Test, the USB device must go through the Device Format Device Performance Test again before you record with the...
Page 671 completed the Device Performance Test. If you attempt the recording or Timeshift function with a device that did not have the Device Performance Test, the function will not start. If any function that turns off the TV (Sleep Timer, Timer, etc.) is set for a time that conflicts with recording, the TV will be turned off once the recording is complete.
Page 672 For the Schedule Recording operation, the USB device requires 1.5GB of free space. Schedule Recording function requires 100MB of free space on the USB device. If the free space of the USB device decreases to less than 50MB while Schedule Recording is operating, Schedule Recording function is...
Page 673 When both the Schedule Recording Timeshift functions are running, and the free space on the USB device decreases to less than 500MB, only Schedule Recording function is automatically terminated. Timeshift function continues even after changing the digital channel and users can watch past programs using the saved Timeshift data.
Page 674 Timeshift function is not supported (application execution, input signal switching, analogue channel change, etc.), the Timeshift data are not saved. If the TV enters a state where the Timeshift function is not supported (application execution, input signal switching, analogue channel change, etc.) while the Timeshift function is...
Page 675 without an additional message being displayed. If a user tunes to a digital channel, the suspended Timeshift function resumes automatically.
Page 676 (such as your PC) by controlling them on the TV via the network. For more information, visit “www.samsung.com” or contact the Samsung call centre. Mobile devices may need additional software...
Page 677 For details, refer to each device’s user’s guide. If your Samsung TV connects to a non-Samsung DLNA server, a compatibility issue may occur during video playback. By connecting your Samsung TV to a network via AllShare Play, you can use Samsung’s original functions as...
Page 678 (DivX, MP4, 3GP, AVI, ASF, MKV, etc.) – Video thumbnail feature – Bookmark function (to resume video playback) – Auto-chaptering (scene navigation) – Digital content management – Compatibility with various subtitle formats (SRT, SMI, SUB, TXT, TTXT)
Page 679 – Search with file names – And many others To use the original DLNA functions of Samsung fully, it is recommended that you use the AllShare Play software provided in your TV. AllShare Settings Menu Network AllShare Settings Shows a list of mobile phones or...
Page 680 up to use AllShare Settings with this AllShare Settings function is available in all devices which support DLNA DMC. Allowed / Denied: Allows / Blocks the devices. Delete: Deletes the devices from the list. This function only deletes the name of the device from the list.
Page 681 deleted device is turned on or tries to connect to the TV, it may appear on the list again. To play the media contents of the devices connected to DLNA function, follow these steps: 1. On the AllShare Play screen, select the kind of content you want to play: Videos, Photos, Music.
Page 682 select DLNA. The TV displays the list of devices connected using the DLNA function. 3. Select a device. AllShare displays the accessible files or folders on the device. 4. Select a file in the file list. The selected file will play. Playing media contents saved on DLNA devices...
Page 683 1. Connect the mobile phone or other devices which support AllShare Play function. 2. Play media contents on the device. A popup screen appears on the bottom of your TV. 3. Select Allow to accept the connected device. The media contents of the device can now play on your TV.
Page 684 An alarm window appears informing you that media contents (videos, photos, music) sent from a mobile phone will be displayed on your TV. The contents are played automatically 3 seconds after the alarm window appears. – If you close the alarm window using your remote when the alarm window appears, the media contents are not played.
Page 685 The first time a device accesses your TV through the media function, a warning pop up window appears. Select Allow. This permits the phone to access the TV freely and use the Media function to play content. To turn off media contents transmissions from a mobile phone, set the device to Denied...
Page 686 Contents may not play on your TV depending on their resolution and format. Some buttons may not work depending on the type of media content. Using the mobile device, you can control the media play. For details, refer to each device’s user’s guide.
Page 687 Using the MHL function You can enjoy videos, photos and music files on your TV when you connect it to a mobile device that supports Mobile High-Definition Link (MHL) function. To use the MHL function, you need an MHL-certified mobile device. You can check if your mobile device is MHL certified on the device manufacturer's website.
Page 688 of MHL-certified devices, visit the official MHL website (http://www. mhlconsortium.org). To use the MHL function, follow these steps: 1. With an MHL-dedicated cable, connect the USB port of the mobile device and the HDMI IN 3 (MHL) port of the TV. You can also connect the HDTV...
Page 689 adapter. 2. Select Source using your remote. Source screen appears. 3. Select HDMI3. 4. Play the file. To use the MHL function, you must upgrade the software to the latest version. When you use an MHL cable, only the HDMI IN 3 (MHL) port of the TV supports the MHL function.
Page 690 This product is officially MHL- certified. If you encounter any problem when using the MHL function, please contact the manufacturer of the mobile device. Some mobile devices (products) may not support the function depending on the performance or the function of the device.
Page 691 quality may seem degraded. When you use an MHL-dedicated cable, you can charge the connected mobile device even if the TV is in standby state. The TV remote control supports the following buttons: for Standard Remote Control (Menu navigation) † …...
Page 692 (Move to previous menu) for Smart Touch Control Menu navigation : Slide your finger in the Touch Pad from one side to the other. Press the button in the top centre of Touch Pad. The TV displays these control functions: –...
Page 693 Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an...
Page 694 You can only control Anynet+ devices using the TV’s remote control, not the buttons on the TV. The TV remote control may not work under certain conditions. If this occurs, reselect the Anynet+ device. The Anynet+ functions do not operate with other manufacturers’ products.
Page 695 refer to the device’s user manual. You must connect an Anynet+ device using an HDMI cable. Some HDMI cables may not support Anynet+ functions. Anynet+ works when the AV device supporting Anynet+ is in the standby or on status. Anynet+ supports up to 12 AV devices in total.
Page 696 type. However, you can connect only one Anynet+ Home Theatre. To connect an Anynet+ Home Theatre, connect the Home Theatre to the TV using an HDMI cable then: – To hear sound from the Home Theatre’s front, left and right speakers and the subwoofer only, connect a digital optical cable between the DIGITAL AUDIO OUT...
Page 697 (OPTICAL) port on your TV and the Digital Audio Input on the Home Theatre. – To hear 5.1 channel audio, connect HDMI cables to your Anynet+ DVD player, satellite box, etc. Then, connect the DIGITAL AUDIO OUT (OPTICAL) port on your DVD player, Satellite Box, etc.
Page 698 Anynet+ (HDMI-CEC) Menu Anynet+ (HDMI-CEC) The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV. View TV Change from Anynet+ mode to TV broadcast mode. Device List Shows the Anynet+ device list.
Page 699 (device_name) Menu Shows the menu of the connected device. E.g. if a DVD player is connected, the disc menu of the DVD player will appear. (device_name) Tools Shows the Tools menu of the connected device. E.g. if a DVD player is connected, the Tools menu of the DVD player will appear.
Page 700 menu may not be available. (device_name) Title Menu Shows the title menu of the disc in the connected device. E.g. If a DVD player is connected, the title menu of the movie in the DVD player will appear. Depending on the device, this menu may not be available.
Page 701 Setting up Anynet+ (HDMI-CEC) Anynet+ (HDMI-CEC) To use the Anynet+ Function, Anynet+ (HDMI-CEC) must be set to On. When the Anynet+ (HDMI-CEC) function is disabled, all the Anynet+ related operations are deactivated Auto Turn Off Set an Anynet+ Device to turn off automatically when the TV is turned...
Page 702 off. Auto Turn Off is set to Yes, running external devices will turn off at the same time as the TV powers off. May not be enabled depending on the device. Receiver You can listen to sound through a receiver (i.e. Home Theatre) instead of the TV Speaker.
Page 703 Switching between Anynet+ Devices 1. Open the Tools menu using your remote, and then select Anynet+ (HDMI-CEC). 2. Select Device List. The Device List screen appears. If you cannot find a device you want, select Refresh to refresh the list. 3.
Page 704 the switch to the selected device is completed. Device List menu appears only when you set Anynet+ (HDMI-CEC) in the System menu. Switching to the selected device may take up to 2 minutes. You cannot cancel the switching operation while switching is in progress.
Page 705 If you have selected an Anynet+ device using the Source function, you cannot use the Anynet+ function. Make sure to switch to an Anynet+ device using the Device List function. Listening through a Receiver You can listen to sound from the TV through a receiver (i.e.
Page 706 sound through a receiver, go to Receiver screen (System Anynet+ (HDMI- CEC) Receiver). Then select Receiver and set to On. If your receiver supports audio only, it may not appear in the device list. The receiver will work when you have properly connected the optical in jack of the receiver to the DIGITAL AUDIO OUT (OPTICAL)
Page 707 port of the TV. When the receiver (i.e. Home Theatre) is set to on, you can hear sound output from the TV’ s Optical jack. When the TV is displaying a DTV (air) signal, the TV will send out 5.1 channel sound to the receiver.
Page 708 only 2 channel sounds from the receiver. Using the ARC function You can listen to sound from the TV through a receiver connected using an HDMI cable without connecting a separate optical cable. To listen to sound through a receiver using the ARC function, go to Receiver screen...
Page 709 Then select Receiver and set to On. To use the ARC function, a receiver which supports the HDMI-CEC and ARC features must be connected to the HDMI IN 2 (ARC) port. To disable the ARC function, set the Receiver to Off. Even if the TV transmits the ARC signal continuously, the receiver will be blocked from receiving the signal.
Page 710 Troubleshooting Menu Support Self Diagnosis Troubleshooting To view a list of all troubleshooting items, go to e-Manual home screen (Menu Support e-Manual Other Information) or press the SUPPORT button, and then search a desired item by selecting a chapter. When you use a SMART Interaction function, check whether the...
Page 711 Voice and motion control) Voice Control function can be affected recognition by unclear pronunciation, voice level, or surrounding noise. For accurate voice recognition, refer to the Standard Voice Command list at the Samsung web site (http://www.samsung.com). Voice Control performance may vary...
Page 712 depending on the language. Motion control function can be affected recognition by brightness of room and brightness of recognized face. Alternatively, recognition rate of Motion control may differ depending on the TV camera's angle or the operating speed. Therefore, we recommend to adjust a ambient brightness and TV camera's angle before using Motion...
Page 713 If you have other questions, call Samsung customer Service or visit "http://www.samsung.com".
Page 714 Picture Quality (Troubleshooting) First, perform the Picture Test and to see if your TV is properly displaying the test image. (Go to Menu Support Self Diagnosis Picture Test) If the test image is properly displayed, the poor picture may be caused by the source or signal.
Page 715 did in the store. If you have an analogue cable / set top box, upgrade to a digital set top box. Use HDMI or Component cables to deliver HD (high definition) picture quality. Many HD channels are up scaled from SD(Standard Definition) contents.
Page 716 Antenna connection: Try HD stations after performing Auto Tuning. Adjust the Cable/Set top box video output resolution to 1080i or 720p. Make sure you are watching the TV at the minimum recommended distance based on the size and definition of the signal. The picture is distorted: macro block error, small block, dots, pixelization...
Page 717 The compression of video contents may cause picture distortion especially in fast moving pictures such as those in sports and action movies. A weak or bad quality signal can cause picture distortion. This is not a TV issue. Mobile phones used close to the TV (cca up to 1m) may cause noise in the picture on analogue TV.
Page 718 Colour is wrong or missing. If you’re using a component connection, make sure the component cables are connected to the correct jacks. Incorrect or loose connections may cause colour problems or a blank screen. There is poor colour or brightness. Adjust the Picture options in the TV...
Page 719 menu (go to Picture mode / Colour Brightness / Sharpness) Adjust the Energy Saving option in the TV menu (go to Menu System Eco Solution Energy Saving) Try resetting the picture to view the default picture settings (go to Menu Picture Reset Picture)
Page 720 If the Picture Size is set to Screen Fit, change it to 16:9. Change cable / satellite box resolution. The picture is black and white. If you are using an AV composite input, connect the video cable (yellow) to the Green jack of component on the TV.
Page 721 When changing channels, the picture freezes or is distorted or delayed. If the TV is connected to a cable box, try to reset the box. (Disconnect and then reconnect the AC cord and wait until the cable box reboots. It may take up to 20 minutes.) Set the output resolution of the cable box to 1080i or 720p.
Page 722 Sound Quality (Troubleshooting) First, perform the Sound Test determine if your TV audio is operating properly. (Go to Menu Support Self Diagnosis Sound Test) If the audio is OK, the sound problem may caused by the source or signal. There is no sound or the sound is too low at maximum volume.
Page 723 device (Cable/Sat Box, DVD, Blu-ray etc.) connected to your TV. The picture is good but there is no sound. Set the Speaker Select option to Speaker in the Sound menu. If you are using an external device, make sure the audio cables are connected to the correct audio input jacks on the TV.
Page 724 check the device’s audio output option (ex. you may need to change your cable box’s audio option to HDMI if you have the box connected to your TV using an HDMI cable.) If you are using a DVI to HDMI cable, a separate audio cable is required.
Page 725 disconnecting, and then reconnecting device’s power cable. The speakers are making an inappropriate noise. Check the cable connections. Make sure a video cable is not connected to an audio input. For antenna or cable connections, check the signal strength. Low signal level may cause sound distortion.
Page 726 Perform a Sound Test. (Support Self Diagnosis Sound Test)
Page 727 No Picture / No Video (Troubleshooting) The TV won’t turn on. Make sure the AC power cord is securely plugged in to the wall outlet and the TV. Make sure the wall outlet is working. The TV turns off automatically. Ensure the Sleep Timer is set to...
Page 728 If your PC is connected to the TV, check your PC power settings. Make sure the AC power cord is plugged in securely to the wall outlet and the TV. When watching TV from an antenna or cable connection, the TV will turn off after 10~15 minutes if there is no signal.
Page 729 Check cable connections (remove and reconnect all cables connected to the TV and external devices). Set your external device’s (Cable / Set top Box, DVD, Blu-ray etc) video outputs to match the connections to the TV input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input on the TV.
Page 730 are powered on. Be sure to select the TV’s correct source by select Source using your remote.
Page 731 Aerial(Air / Cable) Connection (Troubleshooting) The TV is not receiving all channels. Make sure the Antenna cable is connected securely. Please try Setup to add available channels to the channel list. Go Menu System Setup wait for all available channels to be stored.
Page 732 Verify the Antenna is positioned correctly. The picture is distorted: macro block error, small block, dots, pixelization. The compression of video contents may cause picture distortion, especially with fast moving pictures such as those in sports and action movies. A weak signal can cause picture...
Page 733 distortion. This is not a TV problem.
Page 734 PC Connection (Troubleshooting) A “Mode Not Supported” message appears. Set your PC’s output resolution so it matches the resolution supported by the TV. The video is OK but there is no audio. If you are using an HDMI connection, check the audio output setting on your PC.
Page 735 Network Connection (Troubleshooting) The wireless network connection failed. Make sure the TV is connected to a wireless IP sharer (router).
Page 736 Recording / Timeshift (Troubleshooting) The USB device is not recognized or a Device Format, Checking Device or Device Performance Test fails. See the manual for the USB device to check that the USB device supports recording. If the USB device has a lock, ensure it is off.
Page 737 formatted when connected to the PC. Connect the USB to the TV and format it. (Formatting may fail intermittently.) If a Device Performance Test formatting failed, it means that there is a problem with the USB hardware or the performance of the USB hardware is too low.
Page 738 device that has been working well. If the USB device has a lock, ensure it is off. Recover the USB device using the recovery function in Checking Device. The recording function does not work. Check that a USB device is connected.
Page 739 recordable digital channel. If the signal is weak or does not exist, the recording function will automatically be closed. The TV will not record if the USB device has no free memory space. Check that this is not the case. Timeshift Mode does not work.
Page 740 Radio channels and analogue broadcasts are not supported. Data broadcast channels are not supported. If the signal is weak or does not exist, the Timeshift Mode function will automatically be closed. Timeshift Mode cannot be performed if the USB device has no free memory space.
Page 741 USB memory stick is not supported. Please use the USB HDD type. A message indicates a performance test failure, and the recording and Timeshift Mode functions do not work. These problems may occur if you use a low-performance USB device that does not support recording.
Page 742 of RAID type is not supported. A scheduled recording has failed. A scheduled recording is disabled for certain operations (formatting, performance test, error checking, deleting) that access the file system of a USB device. If there is no USB device connected, the TV will not record even if the scheduled time is reached.
Page 743 The TV will not record if the USB device has no free memory space. Check that this is not the case. If you record a channel locked with Programme Rating Lock, the PIN input window will appear when you try to play back the recording. Several recording devices are connected but the TV stopped recording.
Page 744 connected and the device set as Default Recording Device has no free memory space, the recording function will be closed. Attempt recording again. The device with the most free memory space will automatically be set as Default Recording Device and the TV will start recording.
Page 745 Others (Troubleshooting) The picture won’t display in full screen. HD channels will have black bars on either side of the screen when displaying up scaled SD (4:3) contents. Black bars will appear on the top and bottom of the screen when you watch movies that have aspect ratios different from your TV.
Page 746 The cable/set top box remote control doesn’t turn the TV on or off, or adjust the volume. Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/Set user manual for the SAMSUNG TV code.
Page 747 A “Mode Not Supported” message appears. Check the supported resolution of the TV, and adjust the external device’s output resolution accordingly. Refer to the resolution settings in the User manual. There is a plastic smell from the TV. This smell is normal and will dissipate in a short time...
Page 748 The TV Signal Information is unavailable in the Self Diagnosis menu. This function is only available with digital channels from an Antenna / RF/Coax connection. The TV is tilted to the side. Remove the base stand from the TV and reassemble the stand.
Page 749 There are difficulties assembling the stand base. Make sure the TV is placed on a flat surface. It is necessary to use magnetized screw driver if you cannot remove the screws from the The channel menu is greyed out. (Unavailable) Channel menu is only available...
Page 750 when you select the TV source. Your settings are lost after 30 minutes or every time the TV is turned off. If the TV is in the Store Demo mode, it will reset audio and picture settings every 30 minutes. Change the settings from Store Demo mode...
Page 751 System Setup. You have intermittent loss of audio or video. Check the cable connections and reconnect them. Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the cables are flexible enough for long term use. If mounting the TV to the wall, we...
Page 752 recommend using cables with 90 degree connectors. You see small particles when you look closely at the edge of the frame of the TV. This is part of the product’s design and is not a defect. The PIP menu is not available. functionality is only available when you are using a HDMI or...
Page 753 components source. You turned the TV off 45 minutes ago, and it turned on again. It is normal. The TV operates the OTA (Over The Aerial) function itself to upgrade firmware downloaded whilst your watching TV. There are recurrent picture/ sound issues. Check and change the signal/source.
Page 754 To prevent this, use felt pads on any surface of the TV that comes in direct contact with furniture. You can keep your TV as optimum condition to upgrade the latest firmware on web site (samsung.com Support Downloads) by USB.
Page 755 POP (TV’s internal banner ad) appears on the screen. Select Home Use under Setup mode. For details, refer to the Setup Feature. The Plasma TV is making humming noise. Plasma TVs typically make for PDP TV a soft humming sound. This is normal. It’s caused by the electrical charges that are used to create the images on...
Page 756 the screen. If the humming sound is loud, you may have set the brightness on the TV too high. Try setting the brightness lower. You can also have loud humming if the back of your Plasma TV is too close to a wall or other hard surface.
Page 757 Image Retention (Burn In) Issue. To minimize the possibility for PDP TV of screen burn, this unit is equipped with Pixel Shift screen burn reduction technology. Pixel Shift lets you set the picture so it moves slightly up and down (Vertical Line) and side to side (Horizontal Dot).
Page 758 Anynet+ (HDMI-CEC) (Troubleshooting) Anynet+ does not work. Check if the device is an Anynet+ device. The Anynet+ system supports Anynet+ devices only. You can connect only one receiver (home theatre). Check if the Anynet+ device power cord is properly connected. Check the Anynet+ device’s Video/...
Page 759 Audio/HDMI cable connections. Check whether Anynet+ (HDMI-CEC) set to in the Anynet+ setup menu. Check whether the TV remote control is in TV mode. Check whether the remote control is Anynet+ compatible. Anynet+ doesn’t work in certain situations. (Searching channels, operating Smart Hub or Setup, etc.)
Page 760 reconnected the HDMI cable, please make sure to search devices again or turn your TV off and on again. I want to start Anynet+. Check if the Anynet+ device is properly connected to the TV and check if the Anynet+ (HDMI-CEC) is set to On.
Page 761 remote and then select Anynet+ (HDMI- CEC). Then select a menu you want. I want to exit Anynet+. Select View TV in the Anynet+ menu. Go to the Source screen using your remote and select a non- Anynet+ device. The message Connecting to Anynet+ device ...
Page 762 You cannot use the remote control when you are configuring Anynet+ or switching to a view mode. Use the remote control after the TV has completed Anynet+ configuration or has finished switching to Anynet+. The Anynet+ device does not play. You cannot use the play function when Setup is in progress.
Page 763 The connected device is not displayed. Check whether or not the device supports Anynet+ functions. Check whether or not the HDMI cable is properly connected. Check whether Anynet+ (HDMI-CEC) set to On. (Menu System Anynet+ (HDMI-CEC)) Search Anynet+ devices again. Anynet+ requires an HDMI connection.
Page 764 your TV with an HDMI cable. Some HDMI cables may not support Anynet+ functions. If the connection is terminated because there has been a power failure or the HDMI cable has been disconnected, please repeat the device scan. The TV sound is not output through the receiver.
Page 765 and the receiver. The ARC function enables digital output of sound using the HDMI IN 2(ARC) port and can only be operated when the TV is connected to an audio receiver that supports the ARC function.
Page 766 AllShare Play (Troubleshooting) This file may not be playable properly. This may appear because of the high bit rate of the content. Content generally will play but could experience some playability issue.
Page 767 Smart Hub (Troubleshooting) Some application contents only appear in English. How can I change the language? The Application content language may be different from the application user interface language. The ability to change the language depends on the service provider. Some application services do not work.
Page 768 Check with the service provider. Refer to the help website for application service provider information. When a network error occurs, I can only use the setting menu. If network connection doesn’t work, your service might be limited, as all functions except the setting menu need to be connect to the internet.
Page 769 Web Browser (Troubleshooting) 1. To open Browser, select Browser Smart Hub. Unlike a PC, the Web Browser may be displayed differently. 2. The Web Browser is not compatible with Java applications. 3. When you attempt to download a file, and the file could not be saved, an error message will appear.
Page 770 websites or to web browsers operated by certain businesses. 5. Playback of Flash video may be restricted. 6. E-commerce, for purchasing products online, is not supported. 7. Scrolling a web page that allows only part (and not all) of the page to be scrolled may cause corrupted characters.
Page 771 9. Some options cannot be accessed Link Browsing mode. (To access such options, switch to Pointer Browsing mode.) 10. Some text may appear corrupted because the number of supported fonts is limited. 11. The response to a command on the remote or the screen display may be delayed temporarily if a web page is currently loading.
Page 772 12. Copy and Paste are not supported. 13. When writing emails or posting messages, some functions (Such as changing the size or colours.) may not be supported. 14. The number of bookmarks and logs that can be saved is limited. 15.
Page 773 16. The web browsing speed depends on the network conditions. 17. PIP will automatically be deactivated if a video is played in the browser. Videos may not commence playback after PIP interruption and a possible refresh for the page may be required. 18.
Page 774 21. If you import the bookmark file to a Computer from the TV, the bookmark file will be saved in “Samsung Smart TV Bookmark” folder. 22. If the time is not set in the menu...
Page 775 (Menu System Time Clock), the history information may not be saved. 23. Visited web site history is saved in chronological order and will be removed from the list by oldest page accessed. 24. Some video or audio content may not play during Flash playback depending on the video/audio codec supported.
Page 776 25. A sudden change in the picture brightness inside the video window may affect the brightness of the surrounding stationary picture. PDP TV...
Page 777 Using the Smart Touch Control Improved user convenience has been provided so that you can switch the channel and adjust the volume with just your fingertips while focusing on the TV screen. In addition, the built-in touch pad removes the need for a mouse when you change the menu settings and search for something on the Internet.
Page 778 : Turns the TV on and off. : Adjusts the Volume. < > : Changes channels.
Page 779 RETURN R : Returns to the previous menu. VOICE ˜ : Lets you access the Voice Control function. When you press the button, the TV displays the command list. You can speak using the microphone embedded in your remote. For more detailed information about the Voice Control function,...
Page 780 NUMBER š : Displays the Number button screen. You can select a number using the Touch Pad. ™ : Brings up the Smart Hub applications. See e-Manual chapter Advanced Features Smart Hub. To exit an application that is running ™ easily, press the button.
Page 781 to Sleep mode automatically. To wake up the Smart Touch Control, press the Touch Pad. If you use the integrated remote control for a BD home theater some functions may be unavailable. Therefore, using Anynet+ is recommended. Initial Pairing After you have run the Initial Setup on your TV, you should connect your...
Page 782 Smart Touch Control to your TV. 1. Point the Smart Touch Control toward the TV's IR Blaster and press any key on the Smart Touch Control. 2. The connection icon appears at the bottom left of the screen and the Smart Touch Control is automatically connected to the TV.
Page 783 a pin or the tip of an unbent paper clip. The Smart Touch Control will be initialized. Smart Touch Control PAIRING Reset button. Calibrating the Touch Pad To calibrate the touch pad on the Smart Touch Control, follow these steps: NUMBER š...
Page 784 2. When done, all the LEDs on the top of the Smart Touch Control blink twice simultaneously. While calibrating, don't touch the touch pad. If the touch pad looses accuracy, recalibrate the touch pad by repeating Steps 1 and 2. Using the Touch Pad To display the shortcut functions list on the...
Page 785 ‹ bottom of the screen, press the button at the bottom of the touch pad. This list includes Menu, Source, List, other functions. To display the colour and playing control functions on the top of the screen, press button on the top of the touch pad.
Page 786 Rest your finger on the touch pad, and then slide it from one side to the other, from top to bottom, or bottom to top. To move the Highlight continuously, flick your finger across the touch pad from right to left, left to right, top to bottom, or bottom to top.
Page 787 To Select an item Press the Touch Pad. To Open the History screen Š Press the button on the left side of...
Page 788 the Touch Pad. A list of recently used functions appears. You can select a function again using the Touch Pad easily and quickly. To Open the Tools menu Press the button on the right side of the Touch Pad. Quickly select...
Page 789 frequently used functions. To Open the colour, playing control and exit functions. To display the colour, exit and play control functions on the top of the screen, press the button on the top of the touch pad.
Page 790 e : Close all menus shown on the screen. To Open the Shortcut Functions Screen. ‹ Press the button in the bottom centre of the Touch Pad. You can select ( m ), a desired function (e.g. Menu...
Page 791 ( s ), ( ` ), etc.) easily. Source Info Using the Mute function – If you press and hold the Touch Pad, it has same effect as pressing the MUTE M button on your remote. – However, if you press and hold the touch pad when using Browser, the Touch Pad switches to the Scroll...
Page 792 Pad again, the Scroll mode switches general mode. – Press the Touch Pad or RETURN R button to return to the general mode. To Enter a channel number using the Smart Touch Control 1. While watching a broadcast, press NUMBER š button on the Smart Touch Control.
Page 793 2. Using the touch pad, highlight a number, and then press the touch pad. The TV displays a list of channels that start with the number you selected. 3. Using the touch pad, highlight the channel in the list you want, and then press the touch pad.
Page 794 the touch pad immediately after, the TV displays the list of memorised channels. Select a channel by moving or flicking your finger up or down, and then pressing the touch pad. Using the Smart Touch Control with IR Blaster When you connect IR Blaster to your...
Page 795 TV, you can control connected external devices through your TV using the Smart Touch Control. IR Blaster Pairing 1. Turn the IR Blaster on, and if the LED blinks, connect the IR Blaster to the 2. Briefly point the IR Blaster toward the IR sensor of the TV and press the PAIRING button at the bottom.
Page 796 3. The connection icons appear on the bottom left of the screen, and the TV connects to IR Blaster automatically. If the connection process failed, please turn off and on the IR Blaster, try again from step 2. To set an Universal Remote Control after pairing an IR Blaster, select Yes.
Page 797 must be located nearby with external devices connected to the TV. Note that it should be no obstacle between the external device's IR receiver and an IR Blaster. Install the IR Blaster within 50 cm and 45 degrees of the up, down, left and right directions of the IR sensor of the external device.
Page 798 IR Blaster sends an IR signal into a corresponding external device. Setting up the Universal Remote Control Lets you control a Set-Top-Box (STB) or a BD player or both connected to the TV using your Smart Touch Control. After you connect the device to the TV, the Smart Touch Control can control the navigation, number, and other keys needed to operate and control the...
Page 799 device. The Universal Remote Control can adjust TV's volume, but STB's volume cannot be adjusted. Watch STB after adjusting STB's volume to appropriate level. Depending on the version of an application, the Universal remote setup instructions may differ. In this case, please follow the instructions on the screen.
Page 800 To connect an external device to your Smart Touch Control, follow these steps: 1. Select Add a device to control, and then press the touch pad. 2. Select an external device from the connected devices, and then press the touch pad. 3.
Page 801 touch pad. Make sure that the selected device is on. If it is turned off, turn the power on and press Refresh. 4. Select Search brands, and then press the Touch Pad. A keyboard and an entry field appear. Enter the first few letters of the brand name of your device using the Smart Touch Control, and then select...
Page 802 that appears below the entry field, select the brand name of your device, and then press the touch pad. If you want to search the brand of STB (Set-Top box), you can search the STB by using the brand name or a cable provider. 5.
Page 803 name of your device using the Smart Touch Control, and then select Done at the bottom of the keyboard. In the list that appears below the entry field, select the model name of your device, and then press the touch pad. If the search for model name does not work properly, search with a part of the model name or use the...
Page 804 6. Select Download, and then press the touch pad. Download the configuration data for the IR Blaster in the same way. 7. When all the settings are complete, select the Complete button and press the touch pad. To reset IR Blaster and Smart Touch ‹...
Page 805 Using the Search for Recommended Model Code 1. In the Search model name step in the integrated remote control setup, select the Recommended and press the touch pad. 2. Select Download to download the recommended model code. 3. Point the Smart Touch Control forward to the TV's IR sensor and...
Page 806 press the touch pad to test if the device works. 4. If the downloaded recommended model code does not work, repeat the steps from step 3. When you use the BD home theatre by using Universal Remote, some buttons may not be supported. In this case, we recommend to use Anynet+ (HDMI-CEC) function.
Page 807 LED Indicator Statuses on the Touch Control Watch TV (The TV + STB LEDs are lit.) You can control the TV and Set-top box using the universal remote. (Press the Volume button to adjust the TV volume, press the channel button to change the STB channels, etc.) Watch Movie (The TV + BD Player LEDs are lit.)
Page 808 You can control the TV and BD player using the universal remote. (Press the Volume button to adjust the TV volume, press the TOOLS button to open the BD players option menu, etc.) TV (TV LED is lit.) You can only control the TV using the universal remote.
Page 809 Supported Subtitle and AllShare Play file formats Subtitle External – MPEG-4 timed text (.ttxt) – SAMI (.smi) – SubRip (.srt) – SubViewer (.sub) – Micro (.sub or .txt)
Page 810 – SubStation Alpha (.ssa) – Advanced SubStation Alpha (.ass) – Powerdivx (.psb) Internal – Xsub Container: AVI – SubStation Alpha Container: MKV – Advanced SubStation Alpha Container: MKV...
Page 811 – SubRip Container: MKV – MPEG-4 timed text Container: MP4 Supported image resolutions File Extension Type Resolution *.jpg JPEG 15360 x 8640 *.jpeg *.png 1920 x 1080 *.bmp 1920 x 1080 *.mpo 15360 x 8640...
Page 812 Supported music file formats File Extension Type Codec Comments *.mp3 MPEG1 Audio Layer 3 *.m4a *.mpa MPEG4 *.aac *.ac3 The Seek (jump) function is not *.flac FLAC FLAC supported. Supports up to 2 channel *.ogg Vorbis Supports up to 2 channel WMA 10 Pro supports up to 5.1 *.wma channel.
Page 813 type. File Frame rate Bit rate Container Video Codec Resolution Audio Codec Extension (fps) (Mbps) DIVX 3.11/4.x/5.x/6.x *.avi *.mkv MPEG4 SP/ASP *.asf *.wmv H.264 BP/MP/HP *.mp4 *.mov LPCM 1920 x *.3gp ADMPCM(IMA, Motion JPEG 1080 *.vro *.mpg Window Media 6 – 30 *.mpeg HE-AAC Video v9...
Page 814 Video content will not play, or not play correctly, if there is an error in the content or the container. Sound or video may not work if the contents have a standard bit rate/ frame rate above the compatible Frame/sec listed in the table above. If the Index Table is in error, the Seek (Jump) function is not supported.
Page 815 played smoothly. The menu may take longer to appear if the video’s bit rate exceeds 10Mbps. Some USB/digital camera devices may not be compatible with the player. Video decoder Supports up to H.264, Level 4.1 H.264 FMO / ASO / RS, VC1 SP / MP /...
Page 816 AP L4 and AVCHD are not supported. For all Video codecs except MVC, VP8, VP6: – Below 1280 x 720: 60 frame max – Above 1280 x 720: 30 frame max – GMC 2 over is not supported. Supports only SVAF Top/Bottom and Side by Side.
Page 817 WMA 10 Pro supports up to 5.1 channel. WMA lossless audio is not supported. RealAudio 10 lossless is not supported. QCELP, AMR NB/WB are not supported. If Vorbis is only in Webm container, supports up to 2 channel.
Page 818 Teletext Feature (Depending on the country) The index page of the Teletext service gives you information on how to use the Service. For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed.
Page 819 control. Teletext on / mix / off : Activates the Teletext mode for the current channel. Press the button twice to overlap the Teletext mode with the current broadcasting screen. Press it one more time to exit teletext. Store : Stores the Teletext pages. Size : Displays the teletext on the upper half of the screen in double-size.
Page 820 the screen, press it again. For normal display, press it once again. Hold : Holds the display at the current page, in the case that there are several secondary pages that follow automatically. To undo, press it again. Colour buttons ( red , green , yellow , blue ): If the FASTEXT system is used by the broadcasting company, the different topics on a Teletext page are colour-...
Page 821 buttons. Press the colour corresponding to the topic of your choice. A new colour coded page is displayed. Items can be selected in the same way. To display the previous or next page, select corresponding coloured button. Mode : Selects the Teletext mode (LIST / FLOF).If pressed during LIST mode, switches the mode to List save mode.
Page 822 (store) button. Sub-page : Displays the available sub- page. Page up : Displays the next Teletext page. Page down : Displays the previous Teletext page. Index : Displays the index (contents) page at any time while you are viewing Teletext. Reveal : Displays the hidden text...
Page 823 (answers to quiz games, for example). To display the normal screen, press it again. Cancel : Shrinks the Teletext display to overlap with the current broadcast. Typical Teletext page Part Contents Selected page number. Broadcasting channel identity. Current page number or search indications. Date and time.
Page 824 Anti-theft Kensington Lock <TV Rear> <Optional> A Kensington Lock is a device you can use to physically fix your TV in place when using it in a public place. You wrap the Kensington Lock’s cable...
Page 825 TV. The appearance and locking method may differ from the illustration below depending on the manufacturer. Refer to the manual provided with the Kensington Lock for additional information on proper use. The Kensington Lock is not supplied by Samsung.
Page 826 Please find a “ ” icon on the rear of the TV. The Kensington slot is beside the “ ” icon. To lock the product, follow these steps: 1. Wrap the Kensington Lock cable around a large, stationary object such as desk or chair. 2.
Page 827 3. Insert the locking device into the Kensington slot on the product. 4. Lock the lock. These are general instructions. For exact instructions, see the User manual supplied with the locking device. The locking device has to be purchased separately. The location of the Kensington slot may be different depending on the...
Page 828 TV model.
Page 829 Licence DivX Certified® to play DivX® video up to HD 1080p, including premium content. DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under licence. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation.
Page 830 Manufactured under licence from DTS Licensing Limited. DTS, the Symbol, and DTS and the Symbol together are Rights Reserved. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
