Using an External Antenna with the 170wl Radio Card
Installation Procedure
N o t e
6
Extension Cable
(Variable Length)
Antenna
Pigtail
4.
Remove the rubber tab from the end of the radio card.
5.
Connect the adapter cable to the radio card.
6.
Reconnect power to the access point.
Before enabling the radio with an external antenna attached, be sure to first
configure the access point's antenna mode and transmit power settings.
Access
Point 520wl
Radio Card
Adapter Cable
