2. Reassemble hanger clamps to handle sections
using whichever set of holes best holds bag taut.
Using lower holes in hanger clamps tighten bag
assembly and upper holes in hanger clamps
loosen bag assembly.
Note: Under normal use, bag materials are
subject to deterioration and wear.
Check grass bag often and replace
when necessary with an original
equipment replacement bag. A
weakened or inferior bag may let
objects pass through, causing injury.
POTENTIAL HAZARD
Keep hands, sticks or other objects out of
grass chute while blade is turning.
WHAT CAN HAPPEN
Thrown objects or blade contact can cause
serious injury.
HOW TO AVOID THE HAZARD
Always stop engine when emptying grass
bag and disconnect spark plug wire before
cleaning a clogged chute, bag tunnel or
underside of mower housing.
3. Reconnect spark plug wire.

Mulch Plate

POTENTIAL HAZARD
An uncovered discharge opening will allow
objects to be thrown in operator's or
bystander's direction. Also, contact with
blade could occur.
WHAT CAN HAPPEN
Thrown objects or blade contact can cause
serious injury.
HOW TO AVOID THE HAZARD
Never operate mower unless cover plate,
mulch plate or grass chute and catcher are
installed.
1. Stop engine and disconnect spark plug wire
(Fig. 41) before installing or removing mulch
plate.
2. Insert mulch plate into housing opening
(Fig. 48).
Figure 48
1. Mulch plate
Accessories
1
1123
