Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect yourself
and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in
personal injury and/or damage to product or property. Please retain instructions for future reference.
MAIN FEATURES
Digital torque value readout
+/- 2% accuracy clockwise
CW and CCW operation
Peak hold and track mode selectable
Buzzer and LED indicator for the pre-settable target torque
Engineering units(N-m, ft-lb, in-lb, kg-cm) selectable
Auto Sleep after about 5 minutes idle
Rechargeable batteries are compatible
NAMES AND FUNCTIONS OF PARTS
1.
Reversible Ratchet Head
2.
Direction Lever
3.
LCD Readout
4.
Buzzer
5.
Communication Port
6.
Button
7.
Battery Compartment
8.
Battery Cover
9.
Ratchet Driver
10. Anti-slip Handle
FORM NUMBER
Printed in xxxxxx
MM/YY
4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9
Digital Torque Wrench
11. LED Indicator
12. Torque Value
13. Unit(N-m,ft-lb,in-lb,kg-cm)
14. Peak/Track Mode
15. Power on/Clear Button
16. Unit/Setting Button
17. Up/Down Button
Advertisement
Table of Contents
Related Manuals for Westward 4RYL2
Summary of Contents for Westward 4RYL2
- Page 1 Operating Instructions and Parts Manual 4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9 Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property.
- Page 2 Westward Operating Instructions and Parts 4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9 Digital Torque Wrench SPECIFICATIONS Note: Square *1: The accuracy of the readout is guaranteed from Model drive Max. operation range 20% to 100% of maximum range + /- 1 increment.
- Page 3 Westward Operating Instructions and Parts 4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9 Digital Torque Wrench BEFORE USING THE WRENCH ACTIVATION DURING SLEEP MODE BATTERY INSTALLATION The wrench will auto sleep after about 5 minutes idle for power saving. Press to wake up the Remove the battery cover.
- Page 4 Westward Operating Instructions and Parts 4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9 Digital Torque Wrench SETUP STEP 2: SET TORQUE VALUE STEP 1: UNIT SELECTION Pre-setting Unit: N-m Pre-setting Torque Value Press Press Unit Selection: in-l Increase Max. Torque Value Press...
- Page 5 Westward Operating Instructions and Parts 4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9 Digital Torque Wrench STEP 3 : PEAK HOLD /TRACK MODE TRACK MODE OPERATION SELECTION START Track Mode (System initial) *Note 1 Long Press Setting Target Torque Apply Torque Set Peak/Track mode...
- Page 6 Westward Operating Instructions and Parts 4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9 Digital Torque Wrench PEAK HOLD MODE OPERATION START (System initial) *Note 1 Note: 1. If is appeared, that means this Setting Target Torque wrench has ever been applied more than 110% of the max.
- Page 7 Westward Operating Instructions and Parts 4RYL2, 4RYL3, 4RYL5, 4RYL6, 4RYL8, 4RYL9 Digital Torque Wrench MAINTENANCE AND STORAGE BATTERY MAINTENANCE When the wrench is not used for an extended ATTENTION: period of time, remove the battery. One-year periodic recalibration is Keep a spare battery on hand when going on a necessary to maintain accuracy.
