- Page 1 MP135M User Manual Thank you for using our DSPPA public address system. Please read this User Manual carefully to make better use of this equipment. G u a n g z h o u D S P PA A u d i o C o . , L t d .
- Page 2 This page is left blank for users’ notes...
- Page 3 About the instructions The instructions are used from the development completion date of the Integrated MIC with built-in-amplifier MP135M. The instructions include product introduction, precautions for use, instructions for system connection, instructions for product use, and technical indicators of the product and other contents of the Integrated MIC with built-in-amplifier. Prior to connection, installation and use, the user shall carefully read the instructions, and conduct operation according to indication in the instructions.
- Page 4 Public Address System Co n te n ts I Product description ............................... 1 1.1 About MP135M ............................1 1.2 Features ................................ 1 II Introduction of functions ............................. 2 2.1 Front panel ..............................2 2.2 Rear panel ..............................3 III Connection Diagram ............................4 Specification ................................
-
Page 5: I Product Description
I Product description 1.1 About MP135M MP135M is an integrated MIC with built-in amplifier. The product is packed with two ceiling speakers. It has multiple audio sources, such as MP3, micro SD card, USB, recording and Bluetooth input. The functions include echo, microphone priority and removing the original voice of songs, etc. It supports intelligent real-time detection of load impedance. -
Page 6: Introduction Of Functions
Public Address System II Introduction of functions 2.1 Front panel to fast backward music. Display Play / Pause key Audio source selection key Press to play and pause the music. Long Press to select audio sources, such as MP3, press to turn on and off the voice prompts Bluetooth (BT), LINE (AUX). - Page 7 Public Address System 15 MIC Echo control 18 Gooseneck MIC 1 power switch 16 MIC volume control 19 MIC 2 input 17 Power switch 2.2 Rear panel AUX output, also named line input AUX input, also named line auxiliary output 5V power output, only used for charging USB 4-16 Ω...
-
Page 8: Connection Diagram
Public Address System III Connection Diagram... -
Page 9: Specification
Public Address System Specification Specification of MP135M set 380mm× 300mm× 240mm Size of one set Gross weight of one set Specification of amplifier 4-16Ω Output power 30 W 500 ± 50 mv AUX Input Sensitivity ≥ 85 d B Freq. Response 80 Hz- 16 KHz (±3 d B) -
Page 10: Safety Precautions
Public Address System Safety Precautions 1. Safety Precautions Please do NOT connect this device to the power source, before the system is correctly wired. It is important to ensure that input voltage to the device is the same as required voltage of the device, otherwise the device may be damaged. - Page 11 Therefore, it is required to place the power socket at the position convenient for swap operation of the power cord. Guangzhou DSPPA Audio Co., Ltd.
