Richard Solo ME001 Instruction Manual

ME001 RichardSolo 24000 mAh 4-USB Solar Power Bank
INSTRUCTION MANUAL
Thank you for purchasing the RichardSolo 24000 mAh 4-USB Solar Power Bank. Please read these instructions
before operation and save for future reference.
Battery Layout
Power button
1
4 charge capacity indicator LEDs (blue)
2
Solar charge indicator LED (green)
3
2 USB output ports (QC 3.0; USB 9V/2A)
4
2 USB output ports (QC 3.0; USB 9V/2A)
5
4
6
7
12
5
10
11
For best results
Completely charge solar power bank by cable from AC power outlet. Charge from solar only as needed.
See details below.
Charge 24000 mAh 4-USB Solar Power Bank by cable
1 Connect micro-USB charge cable (12) to Micro-USB IN port (7).
2 Alternately, connect Type C charge cable (not included) to Type C IN port (6).
3 Connect/charge via any powered USB port. Use USB/AC adapter (not included) for faster results.
Four LEDs (2) flash in 25% increments and remain solid when corresponding capacity is reached.
4
Note: LEDs may not provide an accurate reading while battery is recharging. For optimum performance,
make sure all LEDs have stopped flashing and remain solid to ensure full charge capacity. Total recharge time
using USB/AC wall adapter and micro-USB connection (0% - 100%) = about 13 hours. Total recharge time
using USB/AC wall adapter and type C connection (0% - 100%) = about 7-9 hours.
Type C input port (12V 1.5A/9V 2A max - 18W)
6
Micro-USB input port (9V/2A)
7
Solar charge panel
8
3-way flashlight / SOS / Strobe LEDs
9
Directional compass
10
Carry strap
11
USB/micro-USB charge
12
cable (not shown)
Charge 24000 mAh 4-USB
Solar Power Bank by
solar panel
In daylight or lighted areas, power bank solar
charge indicator LED (3) glows green when solar
panel (8) receives light.
Note: Depending on weather conditions, solar
charging requires about 85 hours to fully recharge
power bank from 0% — 100%. For best results, fully
charge by cable method and use solar only as needed
to maintain charge capacity or topping off as a
backup feature when away from power outlets.
2
3
1
8
9
