8000 mAh 2-Port Power Bank with LED Lamp
INSTRUCTION MANUAL
Thank you for purchasing the RichardSolo 8000 mAh 2-Port Power Bank with LED Lamp. Please read these instructions
before operation and save for future reference.
8
10
6
Charge 8000 2-Port Power Bank with
LED Lamp:
Connect any USB/micro-USB cable to micro-USB IN port (2).
1
Or use attached USB charge cable (6).
2
Connect/charge via any powered USB port. Use USB/AC
3
adapter (not included) for faster results.
4
Four LEDs (5) flash in 25% increments and remain solid when
corresponding capacity is reached.
*Note: LEDs may not provide an accurate reading while battery is
recharging. For optimum performance, make sure all LEDs have
stopped flashing and remain solid to ensure full charge capacity.
Total recharge time from 0% - 100% = about 10 hours.
No tandem charge — battery does not recharge itself and another
device simultaneously..
Charge device using included charge
cable:
Connect attached micro-USB charge cable (7) to any
1
micro-USB device.
2
For Apple Lightning devices, use included 8-pin connector
adapter (8).
Press power button (4) to begin charging. Monitor charge status
3
via screen icon on your device.
To stop charging, remove cable from your device.
4
9
5
4
1
OUT1 - USB output
1
port 1 (5V 1A)
IN - Micro-USB input
2
port (5V 1A)
OUT2 - USB output
3
port 2 (5V 2.1A)
Power button
4
4 LED charge capacity
5
indicators (25%, 50%,
75%, 100%)
Charge device using your own charge cable:
Connect USB charge cable included with your own device to Port 1 or
1
Port 3 on Power Bank.
2
Press power button (4) to begin charging. Monitor charge status via screen
icon on your device.
Use Port 1 for iPhone, iPod, iPad Mini, smartphones, and smaller 1A devices.
3
4
Use Port 3 for iPad and larger 2.1A devices or smaller 1A devices.
5
To stop charging, remove cable from your device.
*Note: Power Bank LEDs remain lit while device is charging and show
remaining battery capacity. When device is full or charge cable is removed,
Power Bank shuts off within 10-20 seconds.
Check remaining
charge capacity:
Tap/release power button (4) to
check remaining power bank
charge capacity: 1 LED flashing =
less than 25%; 1 LED solid = about
25%; 2 LEDs = about 50%; 3 LEDs
= about 75%; 4 LEDs = about
75-100%
7
2
3
USB charge cable
6
Micro-USB charge cable
7
8
Micro-USB/Lightning
8-pin adapter located behind
micro-USB cable (7)
LED lamp
9
10
Built-in stand with
non-slip mat
Specifications:
Capacity: 8000 mAh
Cell Type: Li-polymer battery
Input: DC 5V 1A
Port 1 Output: DC 5V 1A
Port 3 Output: DC 5V 2.1A
Size: 5.75" x 2.75" x 1.0"
(14.6 x 6.9 x 2.54 cm)
Weight: 10.6 oz. (300.5 gr)
