Richard Solo JK002 Instruction Manual

8000 mAh Slim 2-Port Power Bank Backup Battery
INSTRUCTION MANUAL
Thank you for purchasing the RichardSolo 8000 mAh Slim 2-Port Power Bank. Please read these
instructions before operation and save for future reference.
1 6
2

Charge 8000 Slim 2-Port Power Bank:

Connect included USB/micro-USB cable
1
to Power Bank micro-USB input port (3).
Charge via any powered USB port.
2
Use AC/USB adapter (not included) for
faster results.
LEDs (6) flash in 25% increments and remain solid when
3
corresponding capacity* is reached.
*Note: LEDs may not provide an accurate reading while
battery is recharging. For optimum performance, make sure
all LEDs have stopped flashing and remain solid to ensure full
charge capacity. Total recharge time from 0% - 100% =
10-12 hours.

Check remaining charge capacity / Use LED flashlight:

Press power button (4) once to check remaining Power Bank charge capacity. 1 LED flashing = less than 25%; 1 LED solid = about 25%; 2 LEDs =
1
about 50%; 3 LEDs = about 75%; 4 LEDs = about 75-100%.
2 Press power button (4) twice to illuminate built-in LED flashlight (2). Press twice to switch off.

Specifications

Capacity: 8000 mAh
Cell Type: Li-ion battery
Input: DC 5V 1A
Port 1 Output: DC 5V 1A
Port 2 Output: DC 5V 2.1A
Size: 0.4" x 3.0" x 6.0"
Weight: 8.6 oz. (245 gr)

Package Contents

• 8000 mAh 2-Port Li-ion battery
• USB/micro-USB charge cable
• Instructions
Questions? Please email us at: RichardSoloHelp@gmail.com
5
3 4

USB Compatibility

Port 1 (1A): iPhone/iPod,
smartphones, MP3
players (standard charge)
Port 2 (2.1A): iPad/tablets + iPhone/
iPod, smartphones,
MP3 players

Safety Instructions

Read all instructions and warnings prior to using this product. Failure to read and follow these safety instructions could
result in fire, explosion, electrical shock or other hazard causing serious and/or fatal injury and/or property damage.
1) Do not modify, disassemble, open, drop,
crush, puncture or shred this product.
2) Do not expose this product to rain or
water.
1 USB output PORT 1 (5V 1A)
LED flashlight
2
Micro-USB input port (5V 1.5A)
3
Power button
4

Charge your device:

Connect USB charge cable included with your device to Port 1 or Port 2.
1
2 Press power button (4) to begin charging. Monitor charge status via screen
icon on your device.
3 Use Port 1 for iPhone, iPod, iPad Mini, smartphones, and smaller 1A devices.
4 Use Port 2 for iPad and larger 2.1A devices or smaller 1A devices.
5 To stop charging, remove cable from your device.
*Note: Power Bank LEDs remain lit while device is charging and show
remaining battery capacity. When no connection is detected for about 30
seconds, Power Bank shuts off. When device is fully charged, Power Bank will
trickle charge device until Power Bank is disconnected or completely
discharged.

Maintenance

1) Do not store in a depleted state as the battery power cells
can be damaged. Charge your Power Bank at least once
per month when not in use.
2) Keep the unit dry. Avoid damp conditions and corrosive
materials.
3) Do not clean with harsh chemicals, soaps or detergents.
3) Avoid excessive heat (open
flame, sunlight, etc.).
4) Keep away from high
voltage devices.
2301 Kerner Blvd. Suite C, San Rafael, CA 94901 USA
5 USB output PORT 2 (5V 2.1A)
4 LED charge capacity indicators
6
(25%, 50%, 75%, 100%)
5) This product is not a
toy — keep away from
children.
www.RichardSolo.com
