Summary of Contents for KBL megasun 5600

  • Page 1 Operating Instructions...
  • Page 2 This documentation only covers products manufactured by KBL-Solarien AG. It must not be duplicated, photocopied, translated or stored without prior specifi c permission by KBL-Solarien AG. Duplication on electronic media or in machine-readable form, either in whole or in part, is also prohibited.

  • Page 3: Table Of Contents

    Resetting the operating hours of the tubes ... 30 Setting the timer function of the deco lighting ..30 O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 4: About These Instructions

    This manual describes units equipped with the maximum number of features. Keep this manual ready to hand at all times. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 5: Safety Notes

    Otherwise, both operating authorisation as well as warranty will become void. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 6: Transport

    Overturning load! Danger of being crushed by heavy parts of the equipment. • Wear safety shoes. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 7: Description Of The Unit

    Canopy Canopy pane ③ Base section Bed pane Air supply connector in the canopy Side pane O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 8: Connections

    ABB F 374 63/0,03A (KBL 3200077000) PE L1 L2 L3 N O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 9: Operation Using Different Audio Sources

    100 V audio system is connected. The connection must be carried out by trained ser- vice staff. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 10: Connecting The External Timer

    For further information, please refer to the chapters “Connections” and “Operation in service mode”. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 11: Aquacool And Aroma Connections

    Aroma box (inlet) Aroma box (outlets) ① Connector (liquid-level monitoring) Inlet (aquaCool medium) aquaCool compressed-air supply O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 12: Start-Up

    O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 13: Tanning Instructions

    UV radiation of sunlight or UV appliances can result in premature ageing of the skin and in a higher risk O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 14: Tanning Times

    The interval between two tanning sessions must be at least 48 hours. Max. number of tan- ning sessions year (=15 kJ/m O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 15 Max. number of tan- ning sessions year (=15 kJ/m  For tube set, see table “Technical data”. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 16 For tube set, see table “Technical data”.  Operation not permitted within the area of validity covered by EU standards! O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 17: Operation In Tanning Mode

    Back to previous/forward to next display Volume aquaCool: on/off/empty Facial Tanner/Shoulder Tanner on/off Body fan O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 18: Assuming The Tanning Position And Starting / Stopping The Tanning Session

    After the time given by the timer has elapsed, the session is terminated automatically, and the fan will run on for three minutes. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 19 If the system is running short of aquaCool liquid, the message “Aqua low” is displayed between sessions. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 20 Switching over is done by pressing the “+” or “–” buttons above the channel-selection symbol. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 21: Functions (Kbl/5)

    Tanning lamps, tubes and the ventilation are shut down in steps and switched off. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 22 IMPORTANT: Do not operate the shoulder tanner without lamp unit. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 23: Information For The Studio Operator

    This message is displayed as a result of: excessive temperature inside the tanning unit, or defective exhaust air fan. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 24: Standby/Service Mode

    If there is an error message pending, eliminate the fault fi rst and then reset the message by pressing the “Stop” button. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 25: Overview: Kbl5 Service Menu

    1 ( ) to reset the tube operating RESET h TUBE hours – tube hours 00003h TUBE O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 26: Overview: Kbl4 Service Menu

    – – entering PIN II PIN II menu level PIN II – PIN I (ACC) O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 27 (studio music) PULS push START STOP save your choice. – PIN 1 (operation info) O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 28 START querying software VERSION VERSION STOP information STOP – – PIN II (Easy Care) O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 29 STOP For further Informations STOP STOP please contact the service. – Pin II (functions On/Off C'M'A'B') O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 30: Information About Operation

    CPI-equipped units. These tube hours must be reset desired day. after each replacement of tubes. Press START to invoke and set the desired O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 31: Setting Date And Time

    Press the START button to save the settings and leave the menu by pressing STOP. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 32: Setting Aroma Characteristics

    9 (minus button). Save the settings with START and exit the menu by pressing the STOP button. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 33: Setting The Audio Music System

    Set the desired value by using the plus and minus buttons to the corresponding letters. Press START to save the settings and leave the O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 34 9 (minus button). Press the START button to save the settings and leave the menu by pressing STOP. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 35: Functions C'm'a'b

    Activate the function by pressing 4 (plus button) the operating hours of the tubes. or deactivate it by pressing 9 (minus button). O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 36: Download Information

    Press 5 (plus button) or 0 (minus button) to select (T.Display = OFF). TEST O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 37: Entering Pin Iii

    Level III is exclusively reserved for trained easyCare Select by pressing 5 (plus button) or service staff! O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 38: Maintenance And Cleaning

    Do not clean the large plastic parts with a dry cloth. This might scratch the surfaces! O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 39: Maintenance Intervals

    Air- after 500 - 600 When conditioning hours and check necessary unit the condensate pump. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 40 Use a microfi bre cloth and megaClean to clean the underside of the bed pane. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 41: Filter Panes

    (5). Then remove the pane in an upward movement towards the front (6). After cleaning the assembly is carried out in reverse order. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 42: Tubes, Facial And Shoulder Tanners

    Reset the operating hours counter of the tubes after attention to their centre retaining clamp ( fi gure 43.2) each replacement. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 43: Replacing The Sunlamps Of The Shoulder Tanner

    The light bulb and its base represent one single component. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 44 Figure 44.1: Undoing the screw of the outer covering O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 45: Dismantling The Tanning Lamps

    After the installation, the small glass pin in the middle of the light bulb must point towards the refl ector. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 46: Unit Lighting

    (or to the Mount the covers. left). Now you can replace the tube. Close the base pane. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 47: Filter Pads

    Open the bed pane and remove the fl uorescent tube to get access to the fi lter pad. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 48: Cooling And Exhaust Air

    Figure 48.3: Cold air for the canopy (assembly picture) Figure 48.4: Ambient air for the canopy O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 49: Air-Conditioning Unit

    Suffi cient airing and ventilation of the exceed the installation level by more than 25 cm. tanning studio must be ensured. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 50: Audio System With Mp3 Sound Box

    (see fi gure on next page). Figure 50.2: Installation underneath the bed pane O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 51: Recording To An Sd Card

    Unlatch the retaining bracket of the lid of the Aroma tin. Then you can 51.1 replace the tin. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 52 The assembly instructions are included with your spare parts delivery. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 53: Error Messages

    2. Contact your Customer Service. I2C Temperature sensor is faulty or E02:BUS:TMP Contact your Customer Service. disturbed. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 54: Service

    Service For all service-related questions, please contact your responsible specialist dealer. O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 55: Technical Data

    Exhaust-air socket Ø 300 -- 1600 mm (top) Minimum capacity (exhaust air): 2250 m Exhaust-air hose Ø 300 O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 56 N o m i n a l With air conditioning: 12070W -- without air conditioning: 10810W power O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 57 Bed: 18x MS UP R100 Longlife pwr. b CPI (1851 R 100W) Bed: 18x MS UP R160 Longlife pwr. b CPI (1852 R 160W) O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...

  • Page 58: Views

    Views 2360 mm O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 59 Remarks O p e r a t i n g I n s t r u c t i o n s | megaSun 5600...
  • Page 60 KBL-Solarien AG Ringstrasse 24-26 · 56307 Dernbach · Germany Telephone +49 (0) 26 89.94 26-0 · Fax +49 (0) 26 89.94 26-66 E-mail megaSun@kbl.de www.megaSun.de...
