Table 1005 - FreeFlight 2101 I/O PLUS Component Maintenance Manual With Illustrated Parts List

2101 I/O Plus Display Components Maintenance Manual
FIG. PART
ITEM NUMBER
2 10 83480-SA02
10A 83480-SA05
15 83981
20 16572
25 84061-00
30 84065
35 84064
40 84063
45 84072
45A 14297
45B 14297-00
50 80298
55 84066
60 84068
65 84067
70 84062-00-E
Page 1014
The document reference is online, please check the correspondence between the online documentation and the printed version.
For use on 83480 and 82550 faceplates ONLY
AIRLINE
STOCKNO.
Table 1005: 83480 / 82250 Faceplate Parts
Use or disclosure of information on this page is subject to the
restrictions of the Proprietary Notice on page TITLE-2 of this document.
NOMENCLATURE
1234567
.BEZEL ADDY BLK I/O PLUS
.BEZEL ASSY GRY I/O PLUS
KNOB
DUAL KNOB
RUBBER KEYPADS
KEY PLUNGER
STAINLESS DOME
GOLD DOME
ROTARY SWITCH ENCODER
(PREFERRED PART)
ROTARY SWITCH ENCODER
(ALTERNATE PART)
ROTARY SWITCH ENCODER
(ALTERNATE PART)
ON / OFF SWITCH
#4 PAN HEAD SS PH NYLOK
#4 FLAT HEAD 82° SS PH NYLOK
#2 FLAT HEAD 82° SS PH NYLOK
PCB ASSY W/HEATSINK
UNIT
EEF PER
CODE ASSY
A 1
B 1
1
1
1
9
9
9
1
1
1
1
3
1
1
1
Revision B
March 15, 2009
