- Page 1 Outdoor Cooking Centres Operating and assembly instructions warranty details Model OCCCAB Cabinet and pedestal...
- Page 2 More than one million Australians enjoy using Kleenmaid appliances daily. Selected because of their unique design, outstanding performance, excellent quality and unquestionable reliability, each one is value-for-money, 100 per-cent guaranteed and at the top of its class.
-
Page 3: Table Of Contents
G E N E R A L I N F O R M A T FOR CUSTOMER REFERENCE TABLE OF CONTENTS (Record and file in a safe place) General Information Purchased from Pre-Assembly Date purchased Assembly Serial No. Maintenance Parts Diagram / List NOTE: Sales docket must be kept as proof of purchase date. -
Page 4: Assembly
Attach castor seats to side panels. NOTE: Castor seats are labelled for correct location L E F T S I D E Phillips flat-head screw " x " Qty: 4 Phillips flat-head screw " x " Qty: 4 Repeat for right side. Door magnets to front Attach side panels to bottom shelf. - Page 5 Attach the trolley bracket front and rear panel. Trolley bracket front. NOTE: Door magnets to bottom Rear panel Phillips-head screw " x " Qty: 12 Door hinge bracket, top left Flange nut " Door hinge bracket, top left Qty: 12 Insert the bottom door hinge pin into the lower door hinge bracket holes.
-
Page 6: Maintenance
DO NOT USE OVEN CLEANER TO CLEAN CLEANING EXTERIOR SURFACES THE STORAGE CABINET. SOME PROPRIETORY BARBECUE Before initial use and periodically thereafter we suggest you wash CLEANERS MAY AFFECT / DAMAGE your Storage Cabinet using a mild soap and warm water solution. SOME OF THE SURFACE COATINGS You can use a wash cloth or sponge for this process. -
Page 7: Parts Diagram / List
This diagram is provided to assist you identify parts if replacement is necessary. Contact the place of purchase or manufacture to enquire about parts, availability and/or service. Items included in the specification may differ from parts list, depending on region or specific dealer specification. -
Page 8: Description
Description Part # Table P0015101MA Control panel P02913101A Control panel bracket – left P03328039C Control panel bracket – right P03328040C Bowl panel – left P0072080DC Bowl panel – right P0072181DC Bowl panel – rear P0072575DC Slide set P01907006B Drawer decorative panel P01901009B Drawer handle P00213014B... - Page 11 Kleenmaid are not liable for any consequential damage incurred during de-installation and/or re-installation. 2. The appliance is delivered to the Kleenmaid service department or authorised service agent and freight charges both ways are paid by the owner. No liability is accepted for loss or damage during transit.
- Page 12 Drawings are not to scale. All information supplied is for general reference purposes only and is on the understanding that Kleenmaid Pty Limited will not be liable for any loss, liability or damage whatsoever arising as a result of reliance of such information.
