- Page 1 Quick Start Guide of All-in-One Network Video Recorder All-in-One Network Video Recorder Quick Start Guide UD.6L0202B2085A01...
-
Page 2: Table Of Contents
Quick Start Guide of All-in-One Network Video Recorder TABLE OF CONTENTS NVR Pre-Installation ............................6 NVR Installation .............................. 6 Sitting on the Horizontal Plane ........................6 Fixing in the Vertical Plane ........................8 Front View ..............................11 Rear View……………………………………………………………………………………………………...12 HDD Storage Calculation Chart ........................13 Menu Operation ............................. - Page 3 (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated, Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.
- Page 4 All-in-One Network Video Recorder Quick Start Guide Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 5 All-in-One Network Video Recorder Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected.
- Page 6 All-in-One Network Video Recorder Quick Start Guide Preventive and Cautionary Tips Before connecting and operating your device, please be advised of the following tips: • Ensure unit is installed in a well-ventilated, dust-free environment. • Unit is designed for indoor use only. •...
-
Page 7: Nvr Pre-Installation
All-in-One Network Video Recorder Quick Start Guide Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to the model: DS-7600NI-E1/A. NVR Pre-Installation The NVR is highly advanced surveillance equipment that should be installed with care. Please take into consideration the following precautionary steps before installation of the NVR. - Page 8 All-in-One Network Video Recorder Quick Start Guide Lay the device on a horizontal plane. You can adjust the visual angle by holding the pedestal and move the displayer forwards and backwards. As shown below, the adjustable angle is [-20, 5].
-
Page 9: Fixing In The Vertical Plane
All-in-One Network Video Recorder Quick Start Guide Fixing in the Vertical Plane Before you start: Prepare the needed tools: Drill, M5 expansion screw, M4 screw and screwdriver. Steps: Separate the bracket into two parts by holding the both parts of the bracket and moving the part 1 downwards. As shown below. - Page 10 All-in-One Network Video Recorder Quick Start Guide Put the part 1 in the wall and use a drill to bore four holes of 8 mm in the wall, according to the four screw holes in the part1. Insert four M5 expansion screws into the four screw holes in part 1. Fix the part 1 in the wall by using the screwdriver to tight the screws.
- Page 11 All-in-One Network Video Recorder Quick Start Guide Connect the part 2 and the displayer by using a screwdriver to tight the screws. Hold the combination of part 2 and displayer and move the combination from top to down to combine it with part 1 again.
-
Page 12: Front View
All-in-One Network Video Recorder Quick Start Guide Front View Icon Description Press it to switch input source. In main menu interface, press it to select and enter a sub-menu. In sub-menu interface, press it to exit the sub-menu. In main menu interface, press it to positioning the cursor to the next item In sub-menu interface, press it to increase the value of a certain item. -
Page 13: Rear View
All-in-One Network Video Recorder Quick Start Guide Rear View Name Description AOUT-VGA Audio output interface for NVR VGA signal. VGA OUT Video output interface for NVR VGA signal. Network interface. Universal Serial Bus (USB) interface for external USB device. AIN-VGA Audio input interface for NVR VGA signal. -
Page 14: Hdd Storage Calculation Chart
All-in-One Network Video Recorder Quick Start Guide HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K... -
Page 15: Menu Operation
All-in-One Network Video Recorder Quick Start Guide Menu Operation Menu Structure Menu Advertising Playback Export Record Camera Maintenance Shutdown Manual Configuration Search People Files Import Normal Normal Record Schedule Camera General System Info Logout General Counting Advertising Event Heat Map Network Shutdown Event... -
Page 16: Setting The Admin Password
All-in-One Network Video Recorder Quick Start Guide Turn off the power switch on the rear panel when the attention pops up. Setting the Admin Password Purpose: For the first-time access, you need to activate the device by setting an admin password. No operation is allowed before activation. -
Page 17: Login And Logout
All-in-One Network Video Recorder Quick Start Guide Login and Logout User Login Purpose: If NVR has logged out, you must login the device before operating the menu and other functions. Steps: Select the User Name in the dropdown list. Input Password. Click OK to log in. -
Page 18: Live View
All-in-One Network Video Recorder Quick Start Guide Live View Some icons are provided on screen in Live View mode to indicate different camera status. These icons include: Live View Icons In the live view mode, there are icons at the upper-right corner of the screen for each channel, showing the status of the record and alarm in the channel, so that you can find problems as soon as possible. - Page 19 All-in-One Network Video Recorder Quick Start Guide The online cameras with same network segment will be displayed in the camera list. Click the button to add the camera. The added camera is marked in white while the camera has not been added is marked in yellow. Explanation of the icons Icon Explanation...
-
Page 20: Recording
All-in-One Network Video Recorder Quick Start Guide camera to be added. Click Add to add the camera. (For the encoders with multiple channels only) check the checkbox of Channel No. in the pop-up window, as shown in the following figure, and click OK to finish adding. Recording Purpose: Two kinds of record types are introduced in the following section, including Instant Record and All-day Record. - Page 21 All-in-One Network Video Recorder Quick Start Guide Option 2: Steps: In live view mode, right-click a channel. Click to select Playback from the menu. Under multi-screen live view, record files of the selected channel will be played back. Under multi-screen live view, record files of the selected channel will be played back. Playback management.
-
Page 22: Backup
All-in-One Network Video Recorder Quick Start Guide Backup Recorded files can be backed up to external backup devices, such as USB flash drives and a DVD writer. Before you start: Connect the backup device to the USB interface. Steps: Enter Video Export interface. Menu >... -
Page 23: Advertising
All-in-One Network Video Recorder Quick Start Guide Advertising The device provides you with a function of previewing advertising files. Insert a USB storage device into the device and start previewing advertising files, then the advertising files in USB storage device will be previewed. Before you start: Convert the advertising files to supported format via Format Converter. -
Page 24: Accessing By Web Browser
All-in-One Network Video Recorder Quick Start Guide Accessing by Web Browser Logging in You can get access to the device via web browser. You may use one of the following listed web browsers: Internet Explorer 6.0, Internet Explorer 7.0, Internet Explorer 8.0, Internet Explorer 9.0, Internet Explorer 10.0, Apple Safari, Mozilla Firefox, and Google Chrome. -
Page 25: Live View
All-in-One Network Video Recorder Quick Start Guide You may have to close the web browser to finish the installation of the plug-in. Live View The live view interface appears by default when you log in the device. Interface Introduction Name Description Displays the list of channels and the playing and recording status of each channel. -
Page 26: Recording
All-in-One Network Video Recorder Quick Start Guide Start/Stop all live view Start/Stop two-way Audio Capture pictures in the live view Adjust volume mode Start/Stop all recording Enable/Disable digital zoom Previous/Next page Full screen Select different stream type for live view by clicking the icon : live view in main stream;... -
Page 27: Playback
All-in-One Network Video Recorder Quick Start Guide If you want to configure the all-day recording, please check the All Day checkbox. If you want to record in different time sections, check the Customize checkbox. Set the Start Time and End Time. Up to 8 segments can be configured and each segment cannot be overlapped. - Page 28 All-in-One Network Video Recorder Quick Start Guide Playback Status Displays the playback status, including channel number and playback speed. Calendar You can select the date to play. Start Playback Steps: Click Playback on the menu bar to enter playback interface. Click the camera from the device list for playback.
- Page 29 All-in-One Network Video Recorder Quick Start Guide...
