Permobil ROHO Smart Check Setup Manual page 2

ROHO
1. Perform a Hard Reset.
®
2. Place the ROHO Sensory Ready Cushion on the chair with the air cells
facing up. Place the nozzle of the pump over the inflation valve and
overinflate the cushion until it begins to arch. Pinch the rubber nozzle of
the hand pump and turn to close the inflation valve completely. Remove
pump.
3. Transfer individual to chair and then perform a hand check as
follows:
a. Slide your hand between the cushion and the
individual. Lift the leg slightly and feel for the lowest
bony prominence and then lower the leg to a sitting
position.
b. Open the inflation valve to remove air, keeping your hand
beneath the individual's lowest bony prominence.
c. Release air until you can slightly move your fingertips,
as per Proper Cushion Inflation Setting.
Close the inflation valve.
d. Attach Smart Check to cushion. Press the green
Check Button, you will see either red light
illuminate. DO NOT add or remove air.
e. Press and hold the Setup Button for 4 seconds
until the green light illuminates, indicating your
preferred cushion inflation setting has been saved.
ROHO
Single Compartment
Hybrid Elite®
The world's best personal electronic cushion security device!
With Smart Check® by ROHO®, you have ROHO's industry leading skin protection plus you get real time feedback to
ensure proper cushion inflation range with the push of a button.
®
Smart Check
Optional Setup
½ " - 1 "
®
Sensor Ready
Single Compartment
High Profile Sensor Ready®
®
Set-Up Guide
Proper cushion inflation setting
½ " - 1 " ( 1.5 cm - 2.5 cm)
®
Cushions
Check Instructions
How to Perform a Check
1. Individual sits in usual sitting
position.
2. Press the green Check Button.
3. Refer to table below..
Status /
Light Action
Causes
The cushion is
within saved No further action required
inflation range
Weight maybe Perform a weight shift, then
unevenly distribute press Check Button again
The quick
Check connection and press
disconnect is not
the Check Button again
securely attached
Open inflation valve and add
more air with the hand
The cushion needs
pump. Close inflation valve
more air
and press Check Button
again. Repeat as needed
The cushion or
quick disconnect
See User Manual
on the cushion has
a slow leak
Open inflation valve and
The cushion has
remove air from the cushion
too much air
until green light illuminates
Single Compartment
Mid Profile Sensor Ready®
