Supported Color Formats

When the Color button is pressed on the VideoForge PRO, the following color
encoding formats are available for selection:
RGB Limited (16-235) - HDTV SMPTE Range – Movies are viewed and
produced within this range.
1. RGB Limited 8-bit
2. RGB Limited 10-bit
3. RGB Limited 12-bit
RGB Full (0-255) - Generally reserved for PC monitors, since PCs use full range
RGB.
4. RGB Full 8-bit
5. RGB Full 10-bit
6. RGB Full 12-bit
YCbCr 4:2:0 (16-235) - ½ color H. resolution, ½ color V. resolution.
7. YCbCr 4:2:0 8-bit
8. YCbCr 4:2:0 10-bit
9. YCbCr 4:2:0 12-bit
YCbCr 4:2:2 (16-235) - ½ color H. resolution, full color V. resolution.
10. YCbCr 4:2:2 8-bit
11. YCbCr 4:2:2 10-bit
12. YCbCr 4:2:2 12-bit
YCbCr 4:4:4 (16-235) - full color horizontal & vertical resolution; no chroma
subsampling.
13. YCbCr 4:4:4 8-bit
14. YCbCr 4:4:4 10-bit
15. YCbCr 4:4:4 12-bit
YCbCr 4:2:0 and YCbCr 4:2:2 are the color encoding formats output from
most consumer video sources (e.g. Blu-ray players, cable and satellite set top
boxes). The new 4K/60 Hz timing is standardized with YCbCr 4:2:0.
