Summary of Contents for MIMSAL MIMLED 600
- Page 1 INSTRUCTIONS FOR USE SUPPORTS AND STANDS FOR MIMLED 600 MIMLED 1000 VALID FROM MAY 2016...
- Page 2 INSTRUCTIONS FOR USE SUPPORTS AND STANDS...
-
Page 3: Table Of Contents
MIMLED 600 / MIMLED 1000 TABLE OF CONTENTS INFORMATION ON SAFE USE 1.1 Pictograph legend 1.1.1 Symbols used in the Operating Instructions 1.1.2 Other pictographs GENERAL SAFETY INSTRUCTIONS 2.1 Standards and guidelines 2.2 Speci c purpose 2.3 Improper use 2.4 Contraindication 2.5 Operation and storage conditions... -
Page 4: Information On Safe Use
OBSERVE MAXIMUM PAYLOAD: This warns against exceeding the approved maximum payload on the support arm system, an adaptation as well as using an end device other than MIMLED 600 or the MIMLED 1000 . AIR PRESSURE: This shows the allowed air pressure values from 500 hPa to 1060 hPa for transport and storage. -
Page 5: General Safety Instructions
The devices must not be loaded with additional weights in addition to the light body. CONTRAINDICATION • The support arm system should not be located in the vicinity of strong magnetic fi elds. Only lights of type MIMLED 600 and MIMLED 1000 may be con-nected to the support arm system. •... -
Page 6: Operation And Storage Conditions
INSTRUCTIONS FOR USE SUPPORTS AND STANDS USE OF THE LIGHTWEIGHT SUPPORT OPERATION AND STORAGE CONDITIONS Different environmental conditions apply for the operation of the device and its intermediate storage. ENVIRONMENTAL CONDITIONS FOR THE STORAGE AND TRANSPORT The following storage conditions apply for up to 15 weeks after the date of delivery: Ambient temperature: -25 °C to 70 °C Relative humidity (non-condensing):... -
Page 7: Components Of The Devices
Combination with medical devices: The spring arm is only to be equipped with end devices of the systems MIMLED 600 and MIMLED 1000 . For the information required for the operation of the light heads please refer to the appropriate instructions for use “Minor surgical lights MIMLED 600 and MIMLED 1000 ”. -
Page 8: Disposal
INSTRUCTIONS FOR USE SUPPORTS AND STANDS USE OF THE LIGHTWEIGHT SUPPORT WALL 800 mm up to 40 ° 180° up to 50 ° 360° terminal device 360° 720 mm MOBILE STAND 720 mm 60° up to 40° terminal device 360° 130 mm up to 50°... -
Page 9: Cleaning And Disinfection
MIMLED 600 / MIMLED 1000 CLEANING AND DISINFECTION CLEANING AND DISINFECTION GENERAL SAFETY INSTRUCTIONS WARNING – ELECTRIC SHOCK The devices can conduct power and is to be treated with caution during cleaning and disinfection. • If there is a mains cord, please disconnect it. -
Page 10: Inspection And Maintenance
Your supplier has been informed and trained regarding the scope and contents of the maintenance work. For the inspection and maintenance work of the light head please observe the Instructions for Use for “Minor surgical lights MIMLED 600 and MIMLED 1000 “. -
Page 11: Maintenance
MIMLED 600 / MIMLED 1000 MAINTENANCE MAINTENANCE NOTE – QUALIFICATION OF PERSONNEL Maintenance must be performed by a hospital technician (or comparably quali ed personnel). SETTING THE SPRING FORCE As with any technical component, springs are subject to natural wear. Thus the spring force can decrease after extended operation and must be readjusted. - Page 12 MAINTENANCE INSTRUCTIONS FOR USE SUPPORTS AND STANDS CAUTION: DESTRUCTION OF THE SPRING ARM If the brake screw is tightened too much, the spring arm will be destroyed. Only tighten the brake screw carefully under repeated monitoring of the braking force control. If the spring arm lowers –...
-
Page 13: Lubricate Locking Segment
MIMLED 600 / MIMLED 1000 DISMANTLING AND REASSEMBLY FOR SERVICING LUBRICATE LOCKING SEGMENT • Dismantle end device according to Section ”End device dismantling” • Check locking segment (see gure) for a minimum thickness of 1.5 mm and replace if necessary. -
Page 14: Install End Device
INSTRUCTIONS FOR USE SUPPORTS AND STANDS DISMANTLING AND REASSEMBLY FOR SERVICING DISMANTLE END DEVICE 1. Place spring arm in the top position. 2. Loosen and remove screw on plastic sleeve. 3. Rotate plastic sleeve 180° so that the locking segment is visible. 4. - Page 15 MIMLED 600 / MIMLED 1000 DISMANTLING AND REASSEMBLY FOR SERVICING INSTALL END DEVICE ON THE MOBILE STAND 1. Unplug mains plug and secure against reconnection. 2. Remove protective cap from the spring arm opening. WARNING – DANGER OF INJURY The spring arm which is pressed downwards can snap back up and cause injury.
-
Page 16: Equipotential Bonding Conductor
INSTRUCTIONS FOR USE SUPPORTS AND STANDS EQUIPOTENTIAL BONDING CONDUCTOR/REPLACEMENT OF FUSES EQUIPOTENTIAL BONDING CONDUCTOR An equipotential bonding cable is an additional conductor (accessory; not included in the scope of delivery), which establishes a direct connection between the electrical device and the potential equalising bus bar of the electrical installation. - Page 17 MIMLED 600 / MIMLED 1000 REPLACEMENT OF FUSES A. Replace the fuses on the mobile stand in accordance with the following operations: 1. Loosen cross-head 5. Insert new fuse. screw but do not remove. 2. Loosen clamping 6. Slide down clamping ring, seal and ring, seal and housing.
-
Page 18: Electrical And Other Technical Data
„small surgical lights“ entitled „Scope of delivery“ and „Mounting system and accessories“ in combination with devices than other than the MIMLED 600 and the MIMLED 1000 systems may lead to increased emission or decreased immunity of the device. -
Page 19: Transient Emissions
GUIDELINES AND MANUFACTURER‘S DECLARATION – ELECTROMAGNETIC EMISSIONS MIMLED 600 and MIMLED 1000 are intended for operation in the electromagnetic environment as specifi ed below. The customer or the user of MIMLED 600 and MIMLED 1000 should ensure that it is used in the specifi c environment. - Page 20 MIMLED 600 and MIMLED 1000 are intended for operation in the specifi ed electromag-netic environment specifi ed below. The customer or the user of MIMLED 600 and MIMLED 1000 should ensure that it is used in such an environment. Interference Compliance Electromagnetic environment –...
-
Page 21: Recommended Safety Distances Between Portable And Mobile Hf Telecommunication Devices And
If unusual performance charac-teristics are observed, additional measures may be required, such as, e.g. a modifi ed alignment or another location of MIMLED 600 and MIMLED 1000 . The eld strengths should be less than 3V/m over the frequency range of 150kHz to 80MHz. -
Page 22: Inspection Plan
INSPECTION PLAN HOLDING FIXTURE SYSTEM INSTRUCTIONS FOR USE SUPPORTS AND STANDS Revised: 1.0 valid from 10 Dec. 2013 INSPECTION PLAN HOLDING FIXTURE SYSTEM System data Supplier _______________________ Date of installation ______________________________ Serial number ______________________________ Series/Inventory number Operator ______________________________ Device location ______________________________ Important information •... - Page 23 MIMLED 600 / MIMLED 1000 INSPECTION PLAN HOLDING FIXTURE SYSTEM Con rmation of the inspections carried out The above listed work was performed including the necessary adjustment work and safety check: year year __________________ ___________________________________________ __________________ __________________________________________ Date Signature/stamp Date...
- Page 24 MIMSAL TRADE S.L. C/ Mollet 17, Pol. Ind. Palou Nord 08401 - GRANOLLERS (Barcelona) Telf. +34 930 139 860 mimsal@mimsal.com www.mimsal.com...
