- Page 1 Mr Steak 5 Burner Patio Grill Repair Parts Kit DESCRIPTION M6X12 Washers Corrugate pipe w/bracket Tool Required (Tools not included) DESCRIPTION Phillips Screwdriver 3/4'' wrench Brush and cup...
- Page 2 Step 1: Shut off gas. Disconnect regulator hose from Tank. Step 2:Remove Disconnect current hose and regulator (X) from gas tube under left front control panel using 3/4'' wrench.
- Page 3 Step 3:Re-connect x x 1 1 Connect current hose and regulator (x) to corrugate i e w/bracket (C) using 3/4'' wrench.
- Page 4 x x 1 1 Step 4:Re-install Connect corrugate i e (C) to gas tube. Tighten fitting with 3/4'' wrench.
- Page 5 Step 5:Attach bracket Attach corrugate i e bracket to left cart bottom ent slots with phillips screwdriver. 。 。...
- Page 6 Step 6:Re-Connect tank gauge to LP tank Step 7: Perform leak test Make soap+water solution and brush on all three (3) connections-see step 8...
- Page 7 Step 8 WARNING Before each use, check the LP supply hose for excessive abrasion, wear, or cuts. If any damage is found, call Customer Service to obtain a replacement supply hose. Always perform the Leak Test (listed below) before using your grill for the first time, if the cylinder has been changed, or if any gas supply components have been changed.
