PT15-SDI-TM / PT17-SDI-TM
Talent Monitor Add On Kit for PT4500-SDI / PT4700-SDI
What's Included
1 x Teleprompter Monitor
1 x Power Adapter with Cable
1 x VESA Monitor Mount
1 x 15mm Rod Adapter
1 x Mounting Knob
4 x 10mm Screws
4 x 15mm Screws
2 x Large Screws
4 x Riser Washers
1 x Adjustable Plate
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
because we're filmmakers too

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT15-SDI-TM and is the answer not in the manual?

Questions and answers

Summary of Contents for Ikan PT15-SDI-TM

  • Page 1 Quick Start Guide PT15-SDI-TM / PT17-SDI-TM Talent Monitor Add On Kit for PT4500-SDI / PT4700-SDI What’s Included 1 x Teleprompter Monitor 1 x Power Adapter with Cable 1 x VESA Monitor Mount 1 x 15mm Rod Adapter 1 x Mounting Knob...
  • Page 2 Assembly Steps Setting Up the Talent Monitor Using the shorter 4 x 10mm Screws, attach the VESA Monitor Mount. Make sure that the long end of the VESA Monitor Mount is pointing in the direction of the power button like the image above. Use the Mounting Knob to tighten the 15mm Rod Adapter to the VESA Monitor Mount. Setting Up the Teleprompter Monitor (Monitor from the PT4500-SDI/PT4700-SDI) If the mounting brackets where previously installed on the teleprompter monitor, remove those screws.
  • Page 3 Attaching the Talent Monitor After both the talent monitor and teleprompter monitor are set up, slide the talent monitor on to the PT4500-SDI/PT4700-SDI. *WARNING* We recommend at least 1 inch of rod should be left inside the teleprompter base. because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
  • Page 4 Shipping Dimensions 15 x 12 x 4 in. Shipping Weight 6 lbs Optional Accessories Some other products that work well with this item available from Ikan include: PT4500-SDI 15” High Bright Beam Splitter Teleprompter ( 3G-SDI, VGA, HDMI PT4700-SDI 17” High Bright Beam Splitter Teleprompter ( 3G-SDI, VGA, HDMI because we’re filmmakers too...
  • Page 5 Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2020 Ikan International. All rights reserved. because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
