Apogee Subwoofer AE-SB Product Dimensions

21.000
[533.40]
30.000 [762.00]
A
22.500
[571.50]
A

FRONT VIEW

NOTE: DIMENSIONS ARE IN INCHES & [MILLIMETERS]
14.938 [379.43]
9.500
[241.30]

STAND SUPPORT FITTING

19.500
[495.29]
TM
1.500 [38.10]
AE-SB SUBWOOFER

SECTION A-A

NOT TO SCALE
INFORMATION CONTAINED
IN THIS DOCUMENT IS
THE SOLE PROPERTY
OF APOGEE SOUND SCALE 1/4 DRAWN
INTERNATIONAL, LLC.
REPRODUCTION OF ALL REVISED
OR ANY PART OF THIS
PRODUCT
DOCUMENT WITHOUT
NUMBER: SIZE
WRITTEN CONSENT
D
FROM APOGEE
SOUND INTERNATIONAL, 100-8200
LLC. IS PROHIBITED.
R
AE-SB SUBWOOFER
SERIAL NO. 0 0 0 0 0 0 ------
MADE IN USA

CONNECTOR PANEL

TM
WWE 9/29/99
DRAWING N0. REVISION
AE-SB SUBWOOFER
A
ZSB
