Apogee Subwoofe AE-112s2 Product Dimensions

SECTION A-A
22.563
[573.10]
44.750 [1136.65]
30.000
[762.00]
A

FRONT VIEW

NOTE: DIMENSIONS ARE IN INCHES & [MILLIMETERS]
15.000
[381.00]
A
R
AE-12s2 SUBWOOFER
14.000 [355.60]

NUTPLATE

2 EACH SIDE
NOT TO SCALE
INFORMATION CONTAINED
IN THIS DOCUMENT IS
THE SOLE PROPERTY
SCALE DRAWN
OF APOGEE SOUND 1/5
INTERNATIONAL, LLC.
REPRODUCTION OF ALL REVISED
OR ANY PART OF THIS PRODUCT
DOCUMENT WITHOUT
NUMBER: SIZE
WRITTEN CONSENT
FROM APOGEE
SOUND INTERNATIONAL, 100-8500
LLC. IS PROHIBITED.
R
AE-12 SUBWOOFER S2
SERIAL NO. 0 0 0 0 0 0
------
MADE IN USA

CONNECTOR PANEL

TM
WWE 9/1/99
DRAWING N0. REVISION
D
AE12s2 SUBWOOFER
A
ZAE-12
