Apogee Powered Subwoofer APL-12 Product Dimensions

44.750 [1136.65]
24.250 [615.95]
22.562 [573.07]
44.750 [1136.65]
30.000 [762.00]
FRONT VIEW
NOTES: UNLESS OTHERWISE SPECIFIED
1. OPTIONAL TRIM IS NOT SHOWN.
2. DIMENSIONS ARE IN INCHES & [MILLIMETERS].
9.000 [228.60]
APL-12 POWERED SUBWOOFER
MAST FITTING
(RIGGING POINTS ON SIDE)
TM
SECTION VIEW
120 VAC APL-12 SUBWOOFER
SERIAL NO. 0 --------- 0 0 0 0 0 0 0 0
POWER BREAKERS MADE IN USA
CAUTION
MAY BE PRESENT HAZARDOUS VOLTAGE
INSIDE. NO USER
REFER SERVICE TO SERVICABLE PARTS.
QUALIFIED PERSONNEL
5.000
[127.00]
NOT TO SCALE
INFORMATION CONTAINED
IN THIS DOCUMENT IS
THE SOLE PROPERTY
SCALE DRAWN
OF APOGEE SOUND 1/6
WWE 2/20/02
INTERNATIONAL, LLC.
REPRODUCTION OF ALL
REVISED
OR ANY PART OF THIS PRODUCT
DOCUMENT WITHOUT
NUMBER: DRAWING N0.
SIZE
WRITTEN CONSENT
D
FROM APOGEE
ZAPL12
SOUND INTERNATIONAL, 105-0200
LLC. IS PROHIBITED.
TM
CONNECTOR PANEL
STATUS ÿ REV INPUT LOOP THRU HI-PASS
LIMIT PIN 2+
SIGNAL
SLEEP
POWER PIN 3+
TM
REVISION
APL-12 POWERED
A
SUBWOOFER
