Datamax I-Class Mark II Quick Start Manual page 3

Quick Start Guide
1
3
Rotate the Printhead
Latch and raise the
printhead
Slide the Roll Media
onto the Media Hub
Route the Media as
shown
Internal Media Loading
2
Rotate the Printhead Latch and
raise the printhead
Slide the ribbon onto Ribbon
Supply Hub
Route the Ribbon as shown
Wrap the ribbon around the
Ribbon Take-up Hub
Close the printhead and rotate the
*Optional
Ribbon Take-up Hub to remove
the slack in the ribbon
External Media Loading
