RC Groups SLICK-EPP Installation Instructions Manual

37.5-inch simulation
Hide thumbs

Advertisement

Table of Contents

37.5-inch simulation SLICK-EPP installation instructions
Thank you for purchasing our EPP model products (hereinafter referred to as
"aircraft"), in order to let you get perfect safety flying experience, please read
this instructions carefully before installation
Here we begin to introduce the installation instructions:
1: Please unpack the package to take out the aircraft, and confirm whether all
the accessories are completely before installation:
2: It is recommended to find a small plate or paper box to place all the parts
together before installation, to avoid any lost during the installation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLICK-EPP and is the answer not in the manual?

Questions and answers

Related Manuals for RC Groups SLICK-EPP

Summary of Contents for RC Groups SLICK-EPP

  • Page 1 37.5-inch simulation SLICK-EPP installation instructions Thank you for purchasing our EPP model products (hereinafter referred to as "aircraft"), in order to let you get perfect safety flying experience, please read this instructions carefully before installation Here we begin to introduce the installation instructions:...
  • Page 2 3: First, install the Triangle Control Horn, please see the picture carefully: .1) First, counter boring the Triangle Control Horn, all the Triangle Control Horns should be installed with quick-acting regulators in the penultimate hole, the quick-acting regulators should be installed in according with two directions, each 2 quick-acting regulators are installed in the left and right.
  • Page 3 .2) Measure the distances from left and right tips to each wing side respectively, and the distances from left and right tips to the tail, make sure the above distances are the same. .3) Fix position with 502 Glue, and then strengthen it with hot-melt adhesive .4) Install tail: cut the tail with art knife, and then insert the tail into the body of aircraft in the horizontal direction.
  • Page 4 .5) before fix the horizontal tail, please measure the distances same as fixing-wings, and adjust wing parallel lines.
  • Page 5 5: Installation of electronic equipment part .1) First, paste the mounting base of wing steering machine to the wings. .2) paste motor frame with 502 Glue, and then lock the motor and the electron speed regulator toghther. .3) paste the aileron with 502 glue (note never overbalance glue, the interior wing has regular foam, 502 glue will corrode it), and then fix the main landing gear with wood lock...
  • Page 6 6: Installation of tail wheel and control surface handspike. .1) Insert the metal wire into the carbon fiber socket buried by rudder (note that put the wood chip into steel wire of tail-wheel before the inserting), and then paste wood chips to the body of aircraft with 502 glue.
  • Page 7 .4) after position all control surfaces, please lock the handspike, and then cut off the redundant part 7: Installation of nose cover and wheels. .1) Take off the internal supports of nose cover. Then hang it to the baffle board on the body of aircraft. And then lock the airscrew.
  • Page 8 Fix the battery into the battery compartment with application of gum Velcro as the picture shown; besides, install auxiliary winglets at the wingtip according to user's interests. 11: Regarding to installation and commissioning of the center of gravity .1) focus settings: it can be debugging after the full sets of accessories are installed completely. .2) Center-of-gravity position: Please take note the wing surface, we print the center-of-gravity position on the wing surface when it leaves factory .3) Different battery, as the weight are different, the installation locations will be different.
