Whelen Engineering Company COYOTE Series Manual

ENGINEERING COMPANY, INC
Route 145, Winthrop Road
Chester, CT 06412-0684
TELEPHONE: (860) 526-9504
TOLL FREE: 1-800-637-4736

Description

The COYOTE™ Series of audible alerting devices
are ideally suited for industrial applications where
high quality, high output audible warning is required.
The COYOTE™ Remote Amplifier with Speaker is
a 30 watt audio amplifier designed to work with a
COYOTE™ Central Communication Device, or other
audio input The Remote Amplifier boosts the low
level input to a full 30 watt level. Model CDA30SAC
is equipped with a 30 watt speaker.
The Remote Amplifier is easy to install and easy to
wire. The output level may be adjusted by setting a
potentiometer from a very low test level to a full 30
watts out.
The Remote Amplifier is typically wall mounted.
The speaker may be rotated to the left or right to
direct the sound output. An optional wall bracket is
available which allows the unit to pivot down for
additional sound control.
© 1996 Whelen Engineering Company, Inc. Doc No. 04-0113158-00
December 2, 1996.
COYOTE SERIES
CDA30SAC, 115/220 VAC, 30W SPEAKER

SPECIFICATIONS

Voltage:
Standby Current:
Active Current:
Weight (w/speaker):
10"
10"
7"

DIMENSIONS

Installation

A COYOTE™ Remote Amplifier with Speaker
does not require any special tools or training to install
and operate, however, it must be installed and tested
in accordance with all local electrical codes and
regulations.
Doc No. 04-0113158-00
REMOTE AMPLIFIER
with SPEAKER
115/220 VAC, 50/60 Hz
.04 Amps, typical
.43 Amps, typical
10 lbs. (4.5 kg)
11-1/4"
16"
