Instructions
Pulse™ Remote
Extender
For use with Pulse Fluid Management System Components only. The Pulse Extender
creates a supplementary Pulse Device Network. It connects to the Pulse HUB over the
facilities LAN.
Not approved for use in European explosive atmosphere locations.
For Indoor use only.
Part 25P363
.
Important Safety Instructions
Read all warnings and instructions in this
manual before using the equipment.
Save these instructions.
3A6943A
EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Graco Pulse 25P363
Summary of Contents for Graco Pulse 25P363
- Page 1 Instructions Pulse™ Remote Extender 3A6943A For use with Pulse Fluid Management System Components only. The Pulse Extender creates a supplementary Pulse Device Network. It connects to the Pulse HUB over the facilities LAN. Not approved for use in European explosive atmosphere locations. For Indoor use only.
-
Page 2: Component Identification
Pulse Remote Extender Overview Pulse Remote Extender Overview Component Identification The Pulse Remote Extender manages remotely deployed Pulse components. The components reside on a Personal Area Network (PAN) hosted by the Pulse Remote Extender. The Pulse Remote Extender sends component information to the Pulse HUB using a user supplied Local Area Network (LAN) connection (F . -
Page 3: Installation
Installation Installation Place the Pulse Remote Extender in the main part of the facility, located either high on a wall or on the ceiling. Install the Pulse Remote Extender on an unobstructed line of sight of any Meters, Pump Air Controls or Tank Level Monitors (F . -
Page 4: Operation
Operation Operation The Remote Extender is configured for Dynamic Host 3. Connect the power adapter to the Inlet Port. The Configuration Protocol (DHCP). On most networks, the other end of the power adapter is plugged into a Remote Extender automatically connects to the local 120-240VAC electrical outlet. -
Page 5: Troubleshooting
Troubleshooting Troubleshooting Problem Cause Solution Power LED is not lit Not being powered Verify the power supply is connected to a power source. Verify that the device is connected to a power source. Hardware Failure Disconnect power and reconnect. If problem persists, replace hardware. -
Page 6: Technical Specifications
Technical Specifications Technical Specifications Pulse Extender Metric Dimensions 3.0 x 3.0 x 3.0 in. 7.62 x 7.62 x 7.62 cm Weight 0.15 lb 0.07 kg Operating Voltage 5VDC Power Consumption Typical: 1.2 W, Max: 2.5 W 0° C to 40° C Operating Temperature 32°... -
Page 7: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. -
Page 8: Graco Information
For the latest information about Graco products, visit www.graco.com. For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call to identify the nearest distributor. Phone: 612-623-6928 or Toll Free: 1-800-533-9655, Fax: 612-378-3590 All written and visual data contained in this document reflects the latest product information available at the time of publication.
