Page 2
本產品可以下列模式使用: This product can be used in the following modes: 新生兒模式 Infant Recline 嬰幼兒餐椅 Feeding Booster 固定於椅座 attached to chair 孩童用餐椅 Toddler Booster...
Page 5
5 years of age and up to 50 lbs •NEVER allow a child to push away (22.7kg). from table. •USE ONLY Swivi Seat™ toddler booster accessories with this product.
Page 6
Failure to follow these warnings and the assembly instructions could result in serious injury or death. •ALWAYS SECURE CHILD IN THE RESTRAINT UNTIL CHILD IS ABLE to get in and out of the feeding booster without help (about 2 1/2 years old), the child should be secured in the feeding booster seat at all times by the restraining system.
各部位名稱 Parts list 不同型號可能不包括下圖所示之配件,安裝前請檢查所有零 件,若有缺少、弄錯或者破損時,請與經銷商或者總公司連 絡。(請參閱封底「產品保證書」) This model may not include some features shown below. Check that you have all the parts for this model BEFORE assembling your product. If any parts are missing, call Customer Service. 所有型號 ALL MODELS 限定型號...
Page 8
輔助靠背 Backrest 將輔助靠背安裝於餐椅上 Insert seat back guides into seat base.
Page 9
將輔助靠背向後翻壓至固定卡槽內 Rotate seat back until it attaches to base. 喀擦! SNAP!
Page 10
座椅保護套 Seat Pad 將安全腰帶由座椅保護套導孔中 穿出 Pull waist straps through open- ings in seat pad. 將安全肩帶及安全股帶由座椅保 護套導孔中穿出 Pull shoulder straps and crotch strap through openings in seat pad. 將座椅保護套由座椅上方套入 Wrap seat pad over the top of the infant seat. 如圖所示,將座椅保護套固定於 座椅前側 Secure seat pad to front of infant seat as shown.
Page 11
新生兒守護墊 Body Support 如圖所示,將新生兒保護墊固定 於座椅上 Place body support on top of the seat pad. 將安全腰帶由新生兒保護墊導孔 中穿出 Pull waist straps through open- ings in body support. 將安全肩帶及安全股帶由新生兒 保護墊導孔中穿出 Pull shoulder straps and crotch strap through openings in body support.
Page 12
餐盤的使用方式 To Use Tray 按壓餐盤兩側之固定扣,將餐 盤卡進座椅側邊之餐盤卡榫內 Squeeze release levers on each side of tray, slide tray on seat, and snap into side tray locks. 喀擦! SNAP! 不使用時,請按壓餐盤兩側之 固定扣並將餐盤滑出 To release squeeze release levers on each side of tray and slide off. 或or 不使用時,請按下餐盤前方之...
Page 13
上層餐盤 Tray Cover 可使用洗碗機 Dishwasher safe. 將上層餐盤向下推至餐盤處來 安裝固定 Attach tray cover by pushing it down on the tray. 喀擦! SNAP! 不使用時,請由餐盤後方拉起 To remove pull up on the back of the tray.
Page 14
調整座椅角度 To Recline Seat 孩童乘坐時請勿調整座椅角度。 警告: 當座椅處於躺臥模式時,請務必移除餐盤。 DO NOT adjust the seat recline with the WARNING child in it. Tray must be removed when the seat is in the fully reclined position. 按壓座位前側之按鈕並向下推 或拉來調整座椅角度 Press button on front of seat and push down or pull up to adjust.
Page 15
旋轉座椅 To Recline Seat 警告: 孩童乘坐時請勿旋轉座椅。 WARNING DO NOT adjust the seat with the child in it. 將座椅兩側的把手向欲旋轉座 椅的方向拉 Locate one of the handles on the side of the booster and pull towards the direction you want to rotate the seat. 可旋轉3方向...
Page 16
安全固定裝置 To Secure Child 警告: 跌落危險:請務必使用安全帶。 WARNING Falling Hazard:Always use the seat belt. 5點式安全帶 5 Point Harness 移動安全帶環扣來調整安 全帶鬆緊 Use slide adjuster at shoulder and waist for tighter adjustment.
Page 17
3點式安全帶 3 Point Buckle 轉換為3點式安全帶 To convert to 3-pt harness 移動安全腰帶環扣來調整 安全帶鬆緊 Use slide adjuster at waist for further adjust- ment.
Page 18
需改變安全帶導孔位置時 ,請確認座椅保護套和椅 背的肩部安全帶導孔位置 相同 安全帶必須穿進導孔中, 甚至與肩同高或略高於肩 膀,請避免安全帶扭曲變 形 When changing harness strap slots, MAKE SURE harness straps are going through same slots in seat pad and seat back. The harness straps must go into slot that is even with or slightly above the shoulders.
Page 19
孩童用餐椅的使用方式 Using as Toddler Booster 解開椅座及椅背之卡榫。 Disconnect seat back from base. 自椅座上移除椅背及座椅保 護套。 Remove seat back and pad from seat base.
Page 21
請將本產品置於沒有扶手但 具靠背的椅子,並確認固定 帶沒有鉤住 Place feeding booster on a chair with no armrests and that has a back, ensuring that the straps are hanging freely. 或or 確認椅子上沒有多餘的椅墊 或墊子 Make sure that there are no extra seatpads or cushions on the chair that you are using with the booster.
Page 22
將下方固定帶繞過座椅並 固定,並拉動固定帶調節 來拉緊 左右移動來確認做已被牢 牢固定 Wrap bottom straps around base of seat and secure clip under the seat. Tighten by pulling on the loose straps. 喀擦! CHECK to make sure SNAP! feeding booster is secure- ly attached by moving from side to side. 將座椅向上拉動,以確認...
Page 23
從椅子上移除本產品 To Remove Feeding Booster from Chair 孩童乘坐時請勿將座椅自椅子上移除。 警告: 跌落危險:孩童乘坐時請勿移動或抬舉座椅 DO NOT remove feeding booster seat with WARNING the child in it. FALL HAZARD Never move or lift booster seat with child in it. 將椅座下方之固定扣打開 Unfasten clips on bottom of seat. 將固定餐椅背部的固定扣...
Page 24
從椅子上將座椅移除 Remove feeding booster 或or seat from chair. 將固定扣扣上,並拉緊 Attach straps to each other and pull strap to tighten to seat.
Page 26
僅可使用Graco之零件。 FROM TIME TO TIME CHECK YOUR BOOSTER for worn parts, loose screws, torn vinyl or stitching. Replace or repair the parts as needed. Use only Graco replacement parts. ‧清潔餐椅架時僅可使用家用肥皂和溫水,不得使用漂 白水或清潔劑。 TO CLEAN BOOSTER FRAME ,use only household soap and warm water.
WARRANTY RECORD 產品質量及維修記錄咭保證書 〈僅限香港地區使用〉 用戶姓名 購買商店 Name Point of Sales 地址 Address 電話 產品名稱 Product 產品型號 Model No. 購買日期 發票號碼 Date of Purchase Invoice No. 維修記錄 Maintenance Record WARRANTY 1. Please keep the purchase receipt as proof for warranty and repairing service. Please bring along with you the warranty record and purchase receipt when presenting the product for servicing.
