Summary of Contents for Gorenje Starck NRKI512ST
- Page 1 DETAILED INSTRUCTIONS FOR USE OF UPRIGHT REFRIGERATOR AND FREEZER www.gorenje.com www.gorenje.com...
- Page 2 We thank you for the confidence you have shown by purchasing our appliance. We wish you find a lot of pleasure in its use. The appliance is intended solely for household use. Refrigerator freezer (hereinafter: the appliance) consists of two parts: the upper part is the refrigerator and the lower part is the freezer.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION IMPORTANT NOTES AND WARNINGS ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES APPLIANCE APPLIANCE DESCRIPTION DESCRIPTION 10 INSTALLATION AND CONNECTION 11 OPERATING THE APPLIANCE 15 APPLIANCE INTERIOR EQUIPMENT 17 RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE STORING AND 18 STORING FOOD IN THE REFRIGERATOR FREEZING FOOD 19 STORING FOOD IN THE FRESHZONE DRAWER... -
Page 4: Important Notes And Warnings
IMPORTANT NOTES AND WARNINGS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 5 Before connecting the appliance to the power mains, let the appliance rest in a vertical position for approximately 2 hours. This will reduce the possibility of operation faults due to the effect of transport on the cooling system. The appliance must be connected to the power mains and grounded in compliance with the effective standards and regulations.
- Page 6 If LED lighting does not work, call a service technician. Do not attempt a repair of the LED lighting yourself, as there is danger of contact with high voltage! To protect the environment, take the obsolete appliance to an authorized home appliance collection center. Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment.
- Page 7 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of thisproduct.
-
Page 8: Advice For Saving Power With Refrigeration Appliances
ADVICE FOR SAVING POWER WITH REFRIGERATION APPLIANCES • Install the appliance as specifi ed in the instruction manual. • Do not open the door more often than necessary. • Occasionally make sure air circulation underneath the appliance is unobstructed. • Condenser unit on the rear wall should be kept clean (see chapter Cleaning the appliance). -
Page 9: Appliance Description
APPLIANCE DESCRIPTION A Refrigerator Control panel 2 Fan 3 Pull-out glass shelf (height-adjustable) 4 Pull-out glass shelf – short 5 LED lighting of refrigerator interior 6 FreshZone pan 7 Fruit and vegetable bin 8 Refrigerator door pans (options: deep, shallow) 9 Door bottle rack with safety holder B Freezer... -
Page 10: Installation And Connection
INSTALLATION AND CONNECTION SELECTING THE ROOM • Install the appliance in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is in the interval specifi ed in the table. The appliance class is indicated on the rating plate / label with the basic information on the appliance. Class Ambient temperature SN (subnormal) -
Page 11: Operating The Appliance
OPERATING THE APPLIANCE A Freezer temperature key Refrigerator on/off key B Freezer temperature digital display: displays Signal light: on when the refrigerator is temperature in the range from -16°C to -24°C operating C Super freeze on/off key K Extra cooling power on/off key D Signal light: on when super freeze is activated L Signal light: on when super extra cooling E Appliance on/off key (refrigerator and... - Page 12 SWITCHING THE APPLIANCE ON/OFF To switch on the appliance for the first time, connect the plug to a mains socket. The displays will indicate dashes to inform you that the refrigerator and the freezer are off. • To switch on the appliance, press the E key and hold it for 3 seconds.
- Page 13 OTHER SETTINGS Continuous acoustic signal - open refrigerator door alarm If the refrigerator door is open for more than one minute, a continuous acoustic signal is activated ant the signal light H will light up. The acoustic alarm will go off when the door is closed or when the alarm is acknowledged with the G key.
- Page 14 Extra cooling power (refrigerator boost) Press the K key to activate the extra cooling power (refrigerator boost). Signal light L will light up. In this case, the fan is operating as well, but only when refrigerator door is closed. After six hours, the function is deactivated and the settings will return to the most recent values.
-
Page 15: Appliance Interior Equipment
APPLIANCE INTERIOR EQUIPMENT SHELF • The shelves may be adjusted tu suit your preferences using the guides in the refrigerator interior. • Each shelf is fi tted with a locking device at the back, which prevents it from being pulled out unintentionally. If you wish to pull out a shelf (to move to another position or for cleaning), please proceed as follows:... - Page 16 INTERIOR SIDE OF THE REFRIGERATOR DOOR Mounted on the refrigerator door are compartments (shelves or bins) intended fro storing cheese, butter, eggs, yoghurt and other smaller packages, tubes, cans, etc. There is a bottle shelf at the lower end of the door. •...
-
Page 17: Recommended Distribution Of Food In The Appliance
RECOMMENDED DISTRIBUTION OF FOOD IN THE APPLIANCE Sections of the refrigerator: - upper part: canned food, bread, wine, pastry etc. - middle part: dairy products, ready-made meals, desserts, soft drinks, beer, cooked food, etc. - Fresh bin: - meat, meat produce, delicatessen; - Fruit and vegetable bin: fresh fruit, vegetables, salads, root vegetables, potatoes, onions, garlic, tomatoes, tropical fruit, sauerkraut, turnips etc. -
Page 18: Storing Food In The Refrigerator
STORING FOOD IN THE REFRIGERATOR IMPORTANT WARNINGS REGARDING FOOD STORAGE Correct use of the appliance, appropriate packaging, maintaining the right temperature, and observing the food hygiene standards has a decisive impact on the quality of food storage. Observe the expiry dates for the food, specified on the packaging. -
Page 19: Storing Food In The Freshzone Drawer
STORING FOOD IN THE FRESHZONE DRAWER In the FreshZone compartment, food stays fresh longer than in a conventional refrigerator, retaining more flavour and nutrients. Decay and loss of mass are slowed down; therefore, fruit and vegetables remain fresh and natural longer. For optimum performance, the drawer should be fully closed. -
Page 20: Freezing And Storing Frozen Food
FREEZING AND STORING FROZEN FOOD FREEZING PROCESS Maximum amount of fresh food that may be inserted at once is specified on the appliance rating plate. If the amount of food to be frozen exceeds the indicated amount, the quality of freezing will be inferior;... -
Page 21: Important Warnings On Freezing Fresh Food
IMPORTANT WARNINGS ON FREEZING FRESH FOOD Only freeze the food that is suitable for freezing in the freezer. Make sure the food you freeze is of high quality and fresh. Choose appropriate packaging and use the packaging correctly. Packaging should not be permeable to humidity; it should be airtight to prevent the food from drying out and loss of vitamins. -
Page 22: Frozen Food Storage Time
FROZEN FOOD STORAGE TIME Recommended storage time in the freezer Type of food Time fruit, beef from 10 to 12 months vegetables, veal, poultry from 8 to 10 months Venison from 6 to 8 months Pork from 4 to 6 months minced meat 4 months bread, pastry, ready-to-eat meals, lean... -
Page 23: Defrosting The Appliance
DEFROSTING THE APPLIANCE AUTOMATIC DEFROSTING OF THE REFRIGERATOR Refrigerator needs no special defrosting procedure, because ice deposited at the inner back wall is defrosted automatically. Ice deposited on the inner back wall during the compressor operation is defrosted when the compressor stops operating, and condensed water drops are drained through the outlet in the inner back wall into the drain pan situated above the compressor where it evaporates. -
Page 24: Cleaning The Appliance
CLEANING THE APPLIANCE Before cleaning, unplug the appliance from the power mains – switch off the appliance (see chapter Switching the Appliance On/Off) and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners that contain abrasive substances, acids, or solvents are not suitable for cleaning as they may damage the surface. -
Page 25: Troubleshooting
TROUBLESHOOTING Fault: Cause/Remedy Appliance is connected • Make sure there is voltage in the power outlet and that to the power mains but it the appliance is switched on. does not work. Cooling system operates • Too high environment temperature. continuously for a long •... - Page 26 Fault: Cause/Remedy LED lighting does not • If LED lighting does not work, call a service technician. work: • Do not attempt a repair of the LED lighting yourself, as there is danger of contact with high voltage! Error code indicated on the •...
-
Page 27: Information About Appliance Noise
WE RESERVE THE RIGHT TO MAKE CHANGES THAT DO NOT AFFECT THE FUNCTIONALITY OF THE APPLIANCE. Instructions for use of the appliance can also be found on our website at www.gorenje. com / < http://www.gorenje.com />... - Page 28 COMBI 54_STARCK en (08-15)
